Application:
Add an IP camera or other network device to the current network group, the new IP address must not be
occupied, otherwise it will result IP conflicts and stop the equipment normal working. Link monitor can
check if the new setting IP address is occupied.

3.3.18 Rapid IP Discovery

Connect the cable to tester's LAN port. Press
Click "Start "to search all IP address of connected equipments in whole network segment.
Click "Stop "to stop work.

3.3.19 PoE power / DC12V 2A and DC 5V 2A USB power output

When the tester is turned on, the DC12V and DC5V power output functions are automatically turned on.
If the IP tester is turned off, the 5VDC USB can still be used to power an external USB device.
To use the PoE Power Output function, click on the icon
"OFF".
to enter Rapid IP Discovery app.
and change the switch "ON" or
