8
decrease the aperture
1
Multimeter interface (Optional)
9
2
The power indicator: it lights green while the tester is powered on by the
0
adapter
2
The data accepted indicator: it lights red while the data is being received
1
2
The RS485/RS232 data transmission indicator: it lights red while the data is
2
being transmitted
2
The charge indicator: it lights red while the battery is being charged. As the
3
charging is complete, the indicator turns off automatically
Top interface
Left interface
Right interface
6
