4. Specifications

4.1 General Specifications

Model
Display
Network port
WIFI
H.265 Main stream test
IP discovery
Rapid ONVIF
Hik test tool
DH test tool
IP camera type
SDI video signal test
* (Optional)
CVI video signal test *
（Optional）
TVI video signal test
（Optional）
AHD video signal test *
（Optional）
Analog video test
Video level meter *
（Optional）
Zoom Image
Snapshot, Video record
and playback
IP Camera Tester【*】models Optional
New 4.3 inch IPS touch screen CCTV tester 960x540 resolution
10/100/1000M auto adjust, RJ45
Built in WIFI,speeds150M, allows you to connect to a wireless network and view IP
cameras
New hardware decoding,4K,H.265/H.264 camera image display by mainstream
testing
Auto-scan the whole network segment camera IP
Search camera quickly, auto log in and display image from the camera, activate
Hikvision camera
Activate Hikvision camera, display image from the camera, modify IP, user name
and password parameters etc
Dahua camera test, modify IP, user name and password parameters etc
ONVIF,ONVIF PTZ, Dahua IPC-HFW2100P, Hikvision DS-2CD864-E13, Samsung
SNZ-5200, Tiandy TD-NC9200S2, Kodak IPC120L, Honeywell HICC-2300T,
RTSP Viewer
1 channel SDI input（BNC interface）, resolution support : 720p 25/30/50/60,1080p
25/30/50/60,1080i 50/60
1 channel CVI input（BNC interface, resolution support 720p 25,30,50,60fps/ 1080p
25,30fps/2560x1440p 25fps,30fps
1 channel TVI input （ BNC interface） ,resolution support 720p 25,30,50,60fps/ 1080p
25,30fps /2048x1536p 18,25,30fps , 2560x1440p 15,25,30fps/ 2688x1520p 15fps ,
2592x1944p 12.5,20fps UTC control and call OSD menu
1 channel AHD input（BNC interface）,resolution support 720p 25,30fps / 1080p
25,30fps/2048x1536p 18,25,30fps , 2560x1440p 15,25,30fps/ 2592x1944p
12.5,20fps UTC control and call OSD menu
1 channel BNC Input & 1 channel BNC Output , NTSC/PAL (Auto adapt)
PEAK video signal level, SYNC signal level, COLOR BURST chroma level
measurement for cvbs camera.
Supports Analog and IP camera image zooming & movement
Capture current images and record live video as JPG file. Media player will view
photos and playback video
