Intellisystem IT-400-IPC Series User Manual page 12

2
RS485 Interface: RS485communication for the PTZ
4
2
RS232 Interface: RS232 communication for the PTZ"HD IN" , AHD /TVI/CVI Coaxial
5
interface (Optional )
2
DC12V2A power output , for provisional DC power supply
6
2
TDR cable test interface
7
2
LED lamp
8
2
SDI input (BNC interface) (Optional)
9
3
HDMI input
0
3
Video image signal output（BNC interface）/cable tracer interface (Optional)
1
3
Video image signal input（BNC interface）/ AHD,CVI and TVI input (BNC interface)
2
(Optional)
3
Optical power meter interface (Optional)
3
3
Visible red laser source emits Interface (Optional)
4
3
UTP cable port: UTP cable tester port/ Cable tracer port
5
