3
Micro SD card moveable, comes with 8GB, supports up to 32GB
6
3
Audio input
7
3
HDMI output interface
8
3
Audio and earphone output
9
4
5V2A USB power output , as power bank
0
4
DC12V2A charging interface
1
4
PSE power sourcing equipment. Tests PoE voltage
2
4
PoE power supply output or LAN test port (Use to test PoE or non-PoE IP camera)
3

3. Operation

3.1 Installing the Battery

The tester has built-in lithium ion polymer rechargeable battery. The battery cable inside battery
cabin should be disconnected for safety during transportation!
Prior to the use of the instrument, the battery cables inside the battery cabin should be well
connected.
Pressing the key
Notice: Pls use the original adaptor and connected cable of the device!
continuously can power on or off the tester.
8
