Intellisystem IT-400-IPC Series User Manual page 122

Support 720x480P/60fps720x576P/60fps，1280x720P/25/30/ 50/60fps，
HDMI IN
1920x1080P/25/30/50/60fps，1920x1080I/50/60fps，800x600P/60fps，
*(Optional)
1024x768P/60fps，1280x1024P/60fps.
HDMI output 1 channel HDMI output, supports up to 1080p
12V/2A power output Output DC12V/2A power to camera
RJ45 cable TDR test and cable quality test, to test cable pair status, length,
RJ45 cable TDR test
attenuation reflectivity, impedance, skew and other parameter.
USB 5V power output 5V 2A power output only ,NO data
PoE power output 48V PoE power output, Max power 24W
Lite mode and normal model available. Under normal mode, you can change icons
Screen management
sequence and self-define the number of icons in each page
Self-define icons, desktop and application interface background, modify interface
Theme
sliding effect
Includes PoE power switch ,IP setting, WLAN switch , HDMI IN functions etc
Drop-down menu
screen lock, password lock screen or pattern lock
1 channel audio signal input and 1 channel audio signal output to connect
Audio test
headphones
Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30
PTZ control
protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc
Output one channel PAL/NTSC color bar video signal for testing monitor or video
Color bar generator
cable.(red, green ,blue, white and black color )
Test UTP cable connection status and display on the screen. Read the number on the
UTP Cable tester
screen
Captures and analyzes the command data from controlling device, also can send
Data monitor
hexadecimal
IP address scan, link scan, and Ping test. Quickly search the for IP camera's IP
Network test
address on your network
Cable tracer*
Find a connected cable from a bundle of cables using audio tones
（Optional）
PoE /PSE voltage test Measures PoE switch voltage and displays pin configuration
AC/DC Voltage, AC/DC current, Resistance, Capacitance, Data hold, Relative
Digital Multi-meter
measurement, Continuity testing. Testing speed: 3 times/ seconds, Data range
*(Optional)
-6600～+6600.
Optical power meter Calibrated Wavelength(nm) :850/1300/1310/1490/1550/1625nm
*(Optional) Power range(dBm) :-70～+10dBm
