Enrolling the module

Before you enroll the module, ensure that all hardwired zones, PGM, AUX, and BELL are wired to the
module.
To enroll the module, complete the following steps:
1. Enable enrollment through panel programming. For more information, refer to the Qolsys
IQPanel2/IQPanel4 Installation Manual.
2. Press the Enroll button on the PCB and release when the LED lights solid orange.
3. Confirm the correct module ID in panel programming.
Note: The module ID is on the module label. It is a seven digit number that identifies the
device being enrolled. It has the format 460-XXXX.

Testing the module placement

To test the signal strength between the module and the alarm panel, complete the following steps:
Press the Enroll button on the module.
•
After the placement test is complete, the color of the LED indicates the signal strength. For more
information, see Table 11.
Table 11: Device signal strength
LED color
Three red flashes
Three orange flashes
Three green flashes
Note: For UL installations, only a strong signal strength is acceptable.
PG8HRDW8 and PG9HRDW8 IQ Hardwire PowerG Wired to Wireless Converter Installation Manual
Signal strength
Poor
Medium
Strong
