Figure 2: Mounting locations
Callout
1
2
3
PG8HRDW8 and PG9HRDW8 IQ Hardwire PowerG Wired to Wireless Converter Installation Manual
Description
PC Link connection.
Note: Pin one is on the right. When you connect to the PC Link, make
sure that the PCB side of the PC Link connector aligns with the white
line on the module PCB, and use only the four pins on the right.
Wall tamper screw
Enrollment button
11
