Application Diagram

Figure 1.
Analog RGB or component video output
Buffered loop-through connector — A buffered input loop-through delivers reshaped
and restored multi-rate SDI signals.
Bi-level or tri-level sync is available for component video output.
Internal test patterns for calibration and setup — Nine test patterns are available,
including a crop pattern, color bars, and grayscale.
Muting control — Provides video and audio output muting.
RS-232 configuration and control — An RS-232 serial port provides configuration and
USB configuration and control
control via SIS commands.
Front panel security lockout — Locks out all front panel functions except for input
Rack and furniture mountable 1U, half rack width metal enclosure
Internal universal power supply
supply provides worldwide power compatibility.
Extron
DVC 501 SD
SDI/HD-SDI to DVI and
RGB/YUV Converter
HD-SDI
HDTV Camera
Connection Diagram for a DVC 501 SD
