- Page 4 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align the headboard legs (#2R/L) to the holes of the headboard (#1). Make sure the HB legs (#2R/L) are placed correctly. Secure with bolts (#A). Prepare 2 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 5 Hook the side rails (#5) to the latch of the headboard (#1) and footboard (#4). Make sure it is firmly resting on the latch. Attach support legs (#8) to the center support slat (#7). Adjust adjustable floor protectors on the support legs (#8) according to ground level.
- Page 6 Align the slats (#6) to the center support slat and side rails. Secure with screws (#E).
- Page 10 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align the headboard legs (#2R/L) to the holes of the headboard (#1). Make sure the HB legs (#2R/L) are placed correctly. Secure with bolts (#A). Prepare 2 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 11 Hook the side rails (#5) to the latch of the headboard (#1) and footboard (#4). Make sure it is firmly resting on the latch. Attach support legs (#8) to the center support slat (#7). Adjust adjustable floor protectors on the support legs (#8) according to ground level.
- Page 12 Align the slats (#6) to the center support slat and side rails. Secure with screws (#E). Prepare 10 bolts assembly by inserting lock washer (#G), then flat washer (#H) onto bolts (#F). Align side rail top panel (#9) to the top of the slats of the side rails. Secure with bolts (#F).
