Furniture of America CM7500EK Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM7500EK
ASSEMBLY RATING
Tools Required For Assembly:
The Assembly Rating is a 5-point system that
Allen Wrench
shows the degree of effort needed in
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Phillips Screwdriver
products, two persons are recommended.
(Not Included)
EASY
DIFFICULT
2 PERSONS RECOMMENDED
Rev: 18-01-04
Page 1 of 10
