VERSION # 20-03-06
1 / 10
MODEL #
CM7580CK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7580CK
Summary of Contents for Furniture of America CM7580CK
- Page 1 MODEL # CM7580CK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 1 0...
- Page 5 CM7580CK #1 1pc #2 2pcs #3 1pc #4 1pc Headboard Panel Leg(L&R) Leg Support Footboard #7 1pc #8 4pcs #5 2pcs #6 1set Rail Slat (13 pcs) Center Support Support Leg 305x30x30mm #9 2pcs Side Rail Top Panel #A 8pcs...
-
Page 6: Exploded View
#E 15pcs #F 10pcs #G 10pcs #H 10pcs Screw #4 x 30mm Lock Washer Bolt Ø1/4" x 1-3/8'' Flat Washer Ø1/4" Ø1/4" Exploded View 6 / 10... - Page 7 CM7580CK is packed in 3 cases Carton Disignation Part Hardware #A x 8pcs Headboard Panel #1 #B x 8pcs CM7580 CK -HB Leg(L&R) #C x 8pcs #D x 1pc Leg Support CM7580 Footboard CK -FB #E x 15pcs Side Rails...
- Page 8 ASSEMBLY INSTRUCTIONS Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) Part #1 x1pc onto bolts (#A). Align the Part #2 x2pcs headboard legs (#2R/L) to the holes of the headboard Hardware #A x6pcs (#1). Make sure the HB legs (#2R/L) are placed Hardware #B x6pcs correctly.
- Page 9 ASSEMBLY INSTRUCTIONS Hook the side rails (#5) to the latch of the headboard (#1) and footboard (#4). Make sure it is firmly resting on the latch. Part #4 x1pc Part #5 x2pcs Attach support legs (#8) to the center support slat (#7). Adjust adjustable floor protectors Part #7 x1pc on the support legs (#8) according to ground level.
- Page 10 ASSEMBLY INSTRUCTIONS Align the slats (#6) to the center support slat and side rails. Secure with screws (#E). Part #6 x1set Hardware #E x15pcs Prepare 10 bolts assembly by inserting lock washer (#G), then flat washer (#H) onto bolts (#F). Align side rail top panel (#9) to the top of the slats of the side rails.
