ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7500Q
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 10
(Included)
(Not Included)
Rev: 18-01-04

Advertisement

loading
Need help?

Need help?

Do you have a question about the Karla CM7500GYQ and is the answer not in the manual?

Questions and answers

Related Manuals for Furniture of America Karla CM7500GYQ

Summary of Contents for Furniture of America Karla CM7500GYQ

  • Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7500Q ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
  • Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
  • Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #A x 6pcs #1 x 1pc Bolt Ø5/16" x 1-3/8" Headboard #2 x 2pcs #B x 6pcs Headboard Leg(L&R) Lock Washer Ø5/16"...
  • Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #9 x 1pc #I x 24pcs Rail Drawer Support Slat Screw #4 x 12mm #10 x 1pc 5/16"...
  • Page 5 #A x 6pcs Prepare 6 bolts assembly by inserting lock #B x 6pcs washer (#B), then flat washer (#C) onto bolts #C x 6pcs (#A). Align HB legs (#2R/L) to the holes of the headboard (#1). Secure by using bolts (#A). Align and hook the side rails (#8) to the latch of the headboard (#1) and footboard (#3).
  • Page 6 Attach support legs (#5) to the holes of the support slat (#4). Adjust the leveler on the support legs (#5) according to ground level. Prepare 2 bolts assembly by inserting lock washer (#F), then flat washer (#G) onto bolts (#E). Align support slat (#4) to the #E x 2pcs side rails (#8), then secure by using bolts (#E).
  • Page 7 Prepare 6 bolts assembly by inserting lock washer (#F), then flat washer (#G) onto bolts (#E). Align drawer rails (#6) to the holes of the footboard (#3) and support slat (#4). Secure by using bolts #E x 6pcs (#E). #F x 6pcs #G x 6pcs Attach support leg (#10) to the hole of the drawer support slat (#9).
  • Page 8 Align drawer support slat (#9) to the side rails (#8), then secure by using screws (#H). #H x 2pcs Align and attach support legs (#13) to the holes of the center support (#12). Adjust the levelers of the support legs (#13) according to ground level.
  • Page 9 Align slats (#14) to the side rails (#8), then secure by using screws (#H). #H x 15pcs #7,#11 #I x 6pcs #7,#11 #7,#11 Unfold the drawers (#7,11), then secure the drawers (#7,11) by using screws (#I). Page 9 of 10...
  • Page 10 Align and attach the drawers (#7,11) through the center metal glides. ASSEMBLY IS COMPLETED Page 10 of 10...
  • Page 11 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7500CK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
  • Page 12 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
  • Page 13 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #A x 6pcs #1 x 1pc Bolt Ø5/16" x 1-3/8" Headboard #2 x 2pcs #B x 6pcs Headboard leg(L&R) Lock Washer Ø5/16"...
  • Page 14 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #9 x 1pc #I x 24pcs Rail Drawer Support Slat Screw #4 x 12mm #10 x 1pc Ø5/16"...
  • Page 15 #A x 6pcs #B x 6pcs #C x 6pcs Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align HB legs (#2R/L) to the holes of the headboard (#1). Secure by using bolts (#A). Align and hook the side rails (#8) to the latch of the headboard (#1) and footboard (#3).
  • Page 16 Attach support legs (#5) to the holes of the support slat (#4). Adjust the leveler on the support legs (#5) according to ground level. Prepare 2 bolts assembly by inserting lock washer (#F), then flat washer (#G) onto bolts (#E). Align support slat (#4) to the side rails (#8), then secure by using bolts (#E).
  • Page 17 Prepare 12 bolts assembly by inserting lock washer (#F), then flat washer (#G) onto bolts (#E). Align drawer rails (#6) to the holes of the footboard (#3) and support slat (#4). Secure by using bolts (#E). #E x 12pcs #F x 12pcs #G x 12pcs Attach support leg (#10) to the hole of the drawer support slat (#9).
  • Page 18 Align drawer support slat (#9) to the side rails (#8), then secure by using screws (#H). #H x 2pcs Align and attach support legs (#13) to the holes of the center support (#12). Adjust the levelers of the support legs (#13) according to ground level.
  • Page 19 Align slats (#14) to the side rails (#8), then secure by using screws (#H). #H x 15pcs #7,#11 #I x 6pcs #7,#11 #7,#11 Unfold the drawers (#7,11), then secure the drawers (#7,11) by using screws (#I). Page 9 of 10...
  • Page 20 Align and attach the drawers (#7,11) through the center metal glides. Prepare 10 bolts assembly by inserting lock washer (#F), then flat washer (#E) onto bolts (#G). Align side rail top panels (#15) to the holes of the side rails (#8), then secure by using bolts (#G).
  • Page 21 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7500EK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
  • Page 22 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
  • Page 23 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1pc #A x 6pcs Bolt Ø 5/16" x 1-3/8" Headboard #2 x 2pcs #B x 6pcs Headboard leg(L&R)
  • Page 24 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #9 x 1pc #I x 24pcs Rail Drawer Support Slat Screw #4 x 12mm #10 x 1pc 5/16"...
  • Page 25 #A x 6pcs Prepare 6 bolts assembly by inserting lock #B x 6pcs washer (#B), then flat washer (#C) onto bolts #C x 6pcs (#A). Align HB legs (#2R/L) to the holes of the headboard (#1). Secure by using bolts (#A). Align and hook the side rails (#8) to the latch of the headboard (#1) and footboard (#3).
  • Page 26 Attach support legs (#5) to the holes of the support slat (#4). Adjust the leveler on the support legs (#5) according to ground level. Prepare 2 bolts assembly by inserting lock washer (#F), then flat washer (#G) onto bolts (#E). Align support slat (#4) to the side #E x 2pcs rails (#8), then secure by using bolts (#E).
  • Page 27 #E x 12pcs Prepare 12 bolts assembly by inserting lock washer (#F), then flat washer #F x 12pcs (#G) onto bolts (#E). Align drawer rails (#6) to the holes of the footboard #G x 12pcs (#3) and support slat (#4). Secure by using bolts (#E). Attach support leg (#10) to the hole of the drawer support slat (#9).
  • Page 28 Align drawer support slat (#9) to the side rails (#8), then secure by using screws (#H). #H x 2pcs Align and attach support legs (#13) to the holes of the center support (#12). Adjust the levelers of the support legs (#13) according to ground level.
  • Page 29 Align slats (#14) to the side rails (#8), then secure by using screws (#H). #H x 15pcs #7,#11 #I x 6pcs #7,#11 #7,#11 Unfold the drawers (#7,11), then secure the drawers (#7,11) by using screws (#I). Page 9 of 10...
  • Page 30 Align and attach the drawers (#7,11) through the center metal glides. ASSEMBLY IS COMPLETED Page 10 of 10...
