ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7556Q
DIFFICULT
Tools Required For Assembly
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 16-11-23
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7556Q
Summary of Contents for Furniture of America CM7556Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7556Q ASSEMBLY RATING Tools Required For Assembly The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Bolt Ø5/16" x 1-3/8" Headboard Panel #2 x 2pcs #B x 8pcs Look washer Ø5/16"...
- Page 4 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align legs (#2R/ L) to the holes of the headboard panel (#1). Secure with bolts (#A). #A x 6pcs #B x 6pcs #C x 6pcs Prepare 2 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 5 Hook side rails (#5) to the latch of the headboard (#1) and footboard (#4). Make sure the side rails (#5) are firmly connected to headboard and footboard. Attach support legs (#7) to each slat (#6). Adjust floor protector according to ground level. Page 5 of 6...
- Page 6 Align the slats (#6) to the side rails (#5), then secure with screws (#E). #E x 8pcs ASSEMBLY IS COMPLETED Page 6 of 6...
