2.5 OPTIONAL: Enabling High Fan Noise

Once you've used the system, if flow is detected on your runs when no product is running,
configure your system to use the High Fan Noise feature. This is especially prevalent on
machines with on-board tanks.
NOTE: Re-calibrate the high fan noise setting whenever product, product rate, tractor RPM, or
fan speed is changed.
1. Set the tractor engine to the RPM that will be used while seeding.
2. Engage the hydraulics to the fan and set the fan to the RPM that will be used while
seeding.
3. Allow the fan to stabilize for one minute. This ensures that the fan and airflow are at the
operating speed.
4. Tap the settings
5. Without product running, enable the High Flow Noise switch under Flow Rate.
If you have Low or Very Low flow selected, your flow rate will be reset to Normal when
High Fan Noise is enabled.
6. Return to the Blockage screen. Tap Start Calibration when it appears.
7. Tap Done when Calibration Ready appears. Calibration is complete.
600890-000075, rev 1.0
icon on the main Blockage screen.
Figure 12: High Fan Noise Calibration Screen
Recon Blockage Plus™ Operator's Guide
Page 14 of 26
