1810 NDSU Research Circle North
Fargo, ND 58102
Tel: 701-356-9222
www.intelligentag.com
Procedure to Update Firmware on TP-Link
(NOTE: This procedure must be performed using a Windows Laptop)
1 - Please verify the product model and the hardware version of your device from the label on the
bottom of the device behind the sliding cover, to make sure you are using the correct firmware.
Wrong firmware upgrading may damage your device and void the warranty.
If there is no hardware version indicated on the label as seen above, it means it is the first hardware
version (V1).
2 - Download the corresponding firmware and configuration files from
http://www.intelligentag.com/support/
according to the model number and hardware.
3 - Connect an Ethernet cable to the port labeled LAN0 or LAN (POE IN) on the bottom of the
access point assembly. (Some TP Links only have one connection point)

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP-link and is the answer not in the manual?

Questions and answers

Related Manuals for IntelligentAg TP-link

Summary of Contents for IntelligentAg TP-link

  • Page 1 Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com Procedure to Update Firmware on TP-Link (NOTE: This procedure must be performed using a Windows Laptop) 1 - Please verify the product model and the hardware version of your device from the label on the bottom of the device behind the sliding cover, to make sure you are using the correct firmware.
  • Page 2 Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com 4 - Connect the other end of the Ethernet cable to the POE port of the black TP Link power supply. 5 - Connect the access point inverter power cord to the black TP link power supply and plug it into a wall outlet.
  • Page 3 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com 10 - Click Change adapter settings. 11 - Right click on the Local Area Connection, and then click Properties. 12 - Double-click Internet Protocol Version 4 (TCP/IPv4).
  • Page 4 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com 13 - Select Use the following IP address and enter the information below. NOTE: Make note of your current settings so that you can change them back at the end of this process.
  • Page 5 Step 1 - Enter http://192.168.0.254 into the address bar of the web browser such as Chrome, Firefox. Then log into the TP-LINK Pharos device with your Username: admin and Password: admin, Click Login. You will be prompted to change the user name and password. It does not matter what you choose at...
  • Page 6 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com Click Finish Step 2 - Navigate to the System tab...
  • Page 7 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com At the Firmware Update field, click the Browse button to choose the firmware you already saved in the folder. Step 3 - Click the Upload button. A pop-up window will provide you three options: 1.
  • Page 8 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com Step 5 - Log into the devices again, navigate to the Status tab, and check the Firmware Version to see whether the device has been upgraded successfully. Step 6 – Click the System tab and click the Browse button in the configuration section.
  • Page 9 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com Step 7 - Navigate to the configuration file that you downloaded and click OK. Step 8- Click Upload. Once the update is complete, check the name of the wireless Network. If your TP Link network is normally named “IASBlockage”...
  • Page 10 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com Step 12 – Click the Wireless tab. Navigate to the SSID box under the Wireless AP settings.
  • Page 11 1810 NDSU Research Circle North Fargo, ND 58102 Tel: 701-356-9222 www.intelligentag.com Step 13 – Change the SSID to IASNetwork2 and click the Apply button to the right. Verify that the TP link is now broadcasting “IASNetwork2”. Step 14 -, change your laptop network settings back to the original settings.
