Aaeon AMB-2003 Series User Manual

Modular system industrial panel pcs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AMB-2003 Series
Modular System Industrial Panel PCs
Version 2.2 for SBC-658
Industrial Panel PCs
Industrial Panel PCs for Industrial Automation
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMB-2003 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Aaeon AMB-2003 Series

Summary of Contents for Aaeon AMB-2003 Series

  • Page 1 AMB-2003 Series Modular System Industrial Panel PCs Version 2.2 for SBC-658 Industrial Panel PCs Industrial Panel PCs for Industrial Automation User’s Manual...
  • Page 2 Safety & Warranty 1. Read these safety instructions carefully. 2. Keep this user's manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. 4.
  • Page 3 15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY DAMAGE THE EQUIPMENT Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.

  • Page 4: Table Of Contents

    Contents Chapter1 General Information.........5 Introduction ............ 6 Specifications ..........7 General ................7 Environmental..............7 Power Supply Selection Table..........7 Features ................8 Specifications ..............9 Touchscreen (Optional)........9 LCD Specifications ........10 Dimensions ............ 11 Panel Mounting..........12 Packing List ..........13 Chapter2 Installation............14 Chapter3 Award BIOS Setup..........51...

  • Page 5: Chapter1 General Information

    Chapter1 General Information Introduction.............6 Specifications ...........7 Touchscreen (Optional) ........9 LCD Specifications........10 Dimensions.............11 Panel Mounting ..........12 Packing List ...........13...

  • Page 6: Introduction

    1.1 Introduction The AMB-2003 series modular system panel PCs, is the PC-base industrial computer that specially designed to keep normal operation under harsh environment, which meet the entire requirement as an industrial man machine interface (MMI). They provide a complete hard ware application and construct a high...

  • Page 7: Specifications

    1.2 Specifications General Construction: Heavy-duty aluminum chassis & plastic or aluminum front panel Disk drive housing: a 3.5" HDD or a 2.5”HDD, Slim CD-ROM & Slim FDD. Dimensions(AMB-2003): 330(W) x 252(H) x 128mm(D) Gross Weight: 9.6 Kg Environmental Operating temperature:0° to 50° Storage temperature: -20°...

  • Page 8: Features

    Features AMB-2003 (10.4”LCD + ACS-2303 Control Box) 10.4” VGA color TFT LCD display Plastic front panel and heavy-duty steel chassis Supports Socket 370 CPU up to Pentium III 850MHz Disk Drive Space for CD-ROM, FDD and HDD Supports DiskOnChip and DiskOnModule Two free expansion slots for ISA or PCI Resistive touchscreen (optional) Rotatable mounting mechanism (optional)

  • Page 9: Specifications

    Specifications AMB-2003 (10.4”LCD + ACS2303 Control Box) Construction: Heavy-duty steel chassis & plastic front panel. CPU: Up to Intel Celeron/ P III 850MHz Memory: Supports up to 128MB Display: 10.4” VGA (640 x 480) TFT color LCD LCD/CRT controller: NS Cx5530 Chipset UMA supports up to 2.5MB display memory Network (LAN): Intel 8139B 10/100 Base-T Ethernet controller...

  • Page 10: Lcd Specifications

    1.4 LCD Specifications Model AMB-2003 Display type TFT color LCD Size (diagonal) 10.4” Number of Pixels 640(W) x 480(H) Dot size 0.33(W) x 0.33 (mm x mm) View angle (Horizontal) 80° View angle (Vertical) 45° Luminance (cd/m 250 (TYP) Operating Temperature 0 ~ 45 °C Backlight Life-time (Hrs) 30,000...

  • Page 11: Dimensions

    1.5 Dimensions AMB-2003HT (mm) Unit : mm 19.2 AMB-2003 Cutout size : 309 x 231 mm...

  • Page 12: Panel Mounting

    1.6 Panel Mounting This display panels can be placed on a shelf or table, or mounted onto a control panel. To mount them onto a control panel you need a kind of mounting kits, which you will find in the accessory box. Take the mounting steps described here below: Set the display panel within the aperture in your control panel Slide the mounting kits into the slots on the chassis cover...

  • Page 13: Packing List

    1.7 Packing List Then you should also check if the package contains the following items. You should contact your dealer immediately if any of these items are missing or damaged One series industrial MMI panel PC with flat panel display CD-ROM for User’s Manual, Drivers and Utilities Accessory Plane for extension solution...

  • Page 14: Chapter2 Installation

    Installation This chapter describes how to set up the main board hardware, including instruc- tions on setting jumpers and connecting peripherals, switches, and indicators. Be sure to read all the safety precautions before you begin the installation proce- dure. Chapter 2 Installation 9...
  • Page 15 Jumpers and connectors Connectors on the board link it to external devices such as hard disk drives, a keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to configure your system to suit your application. The following tables list the function of each of the board's jumpers and connectors.
  • Page 16 Label Function USB connector LCD display connector Internal keyboard connector Parallel port connector COM2 RS-232/422/485 serial port connector CN6 (Pin 1~5) IrDA connector CN6 (Pin 6, 7) Reset switch CN6 (Pin 8~11) External speaker CN6 (Pin 13, 14) IDE drive LED CPU fan power connector VGA display connector 100Base-Tx Ethernet connector...
  • Page 17 Locating jumpers 12 SBC-658 User Manual...
  • Page 18 Locating connectors CN15 CN11 CN12 CN10 PWR1 Chapter 2 Installation 13...
  • Page 19 Setting jumpers You can configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close”...
  • Page 20 CPU installing and upgrading You can upgrade to a more powerful Celeron CPU at any time. Simply remove the old CPU, install the new one, and set the jumpers for the new CPU speed. Warning! Always disconnect the power cord from your chassis when you are working on it.
  • Page 21 3. Press the lever down. The plate will slide forward. You will feel some resistance as the pressure starts to secure the CPU in the socket. This normal and won't damage the CPU. When the CPU is installed, the lever should snap into place at the side of the socket.
  • Page 22 Installing SDRAM (DIMMs) System Memory The upper edge of the SBC-658 contains one sockets for 168 pins dual inline memory module (DIMM). The socket uses 3.3 V unbuffered synchronous (SDRAM). DIMM is available in capaci- ties of 16, 32, 64, 128, or 256 MB. The socket can be filled in the DIMM of any size, giving your SBC-658 single board computer between 16 and 256 MB of memory.
  • Page 23 DOC address & CPU frequency ratio select SW1 (S1 ~ S6) DOC address select The DiskOnChip 2000 occupies a 8KB window in the upper memory address range of D400 to DC00. You should ensure this does not conflict with any other device's memory address. SW1 (S5, S6) controls the momory address of the Flash disk.
  • Page 24 LCD clock signal & driving voltage select (J1) You can select the LCD connector CN2 driving voltage & control signal by setting J1. The configurations are as follows: 5 3 1 6 4 2 LCD clock signal & driving voltage select (J1) ASHF CLK / +5V ASHFCLK / +3.3V SHFCLK / +5V...
  • Page 25 COM2 RS-232/422/485 select (J2, J3) The SBC-658 COM2 serial port can be selected as RS-232, RS-422, or RS-485 by setting J2 & J3. 1 3 5 2 4 6 1 4 7 10 3 6 9 12 COM2 Select (J2, J3) RS-232* RS-422 RS-485...
  • Page 26 Clear CMOS (J4) You can connect an external jumper cap or switch to clear CMOS. Clear CMOS procedure: 1. Disconnect all power source. 2. Move J4 from 1-2 to 2-3 for few seconds. 3. Move J4 back to 1-2. 1 2 3 Clear CMOS (J4) Protect* Clear CMOS...
  • Page 27 Power connectors P8 & P9 (PWR1) In single board computer (non-passive backplane) application. You will need to connect the power directly to the SBC-658 board using PWR1. This connector is fully compatible with the standard PC PS/ 2 power supply connector, P8 & P9. See the following table for its pin assignments: P9 from standard PS/2 power supply...
  • Page 28 USB connector (CN1) The SBC-658 provides two USB (Universal Serial Bus) interfaces, which give complete plug and play, hot attach/detach for up to 127 external devices. The USB interfaces comply with USB specifica- tion Rev. 1.0, and can be disabled in the system BIOS setup. 9 7 5 3 1 10 8 6 4 2 USB connector (CN1)
  • Page 29 Display connectors (CN8, CN2) The SBC-658's PCI SVGA interface can drive conventional CRT displays and is capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD, and active LCD displays. The board has two connectors to support these displays, one for standard CRT VGA monitors and one for flat panel displays.
  • Page 30 VGA display connector (CN8) VGA display connector (CN8) Signal Red video Green video Blue video Not used Red return (GND) Green return (GND) Blue return (GND) Sync return (GND) DDCDAT Horizontal sync Vertical sync DDC CLK Chapter 2 Installation 25...
  • Page 31 LCD display connector (CN2) CN2 is a 50-pin, dual-in-line header used for flat panel displays. When the SBC-658's power is applied, the control signal is low until just after the relevant flat panel signals are present. Configuration of the VGA interface is done completely via the software utility.
  • Page 32 Keyboard and PS/2 mouse connector (CN3, CN15) The SBC-658 provides a keyboard connector which supports both a keyboard and a PS/2 style mouse. In most cases, especially in embedded applications, a keyboard is not used. The standard PC/ AT BIOS will report an error or fail during power-on-self-test (POST) after a reset if the keyboard is not present.
  • Page 33 (CN15) (Mini-DIN 6 pins) Keyboard and PS/2 mouse connector Signal KB DATA MS DATA KB CLOCK MS CLOCK Internal keyboard connector (CN3) Signal KB_CLOCK KB_DATA 28 SBC-658 User Manual...
  • Page 34 Parallel port connector (CN4) Normally, the parallel port is used to connect the board to a printer. The SBC-658 includes an onboard parallel port, accessed through CN4, a 26-pin flat-cable connector. You need an adapter cable if you use a traditional DB-25 connector. The cable has a 26- pin connector on one end and a DB-25 connector on the other.
  • Page 35 Parallel port IRQ The SBC-658 supports one parallel port. The port is designated as LPT1 and can be disabled or changed to LPT2 or LPT3 in the system BIOS setup. Parallel port connector table (CN4) Parallel port connector (CN4) Signal Signal STROBE AUTOFD...
  • Page 36 Serial ports (CN11, CN5) The SBC-658 offers two serial ports, one RS-232 (CN11) and one RS-232/422/485 (CN5). These ports allow you to connect them to serial devices (mouse, printers, etc.). (COM2) CN11 (COM1) COM2 RS-232/422/485 serial ports (CN5) COM2 RS-232/422/485 serial port (CN5) SIGNAL SIGNAL COM2 1...
  • Page 37 IrDA connector (CN6, Pin 1~5) The IrDA connector (CN6, Pin 1~5) can be configured to support wireless infrared module, with this module and application software such as laplink or Win95 Direct Cable connection, user can transfer files to or from laptops, notebooks, PDA and printers. This connector supports HPSIR (115.2Kbps, 2 meters), ASK-IR (56Kbps).
  • Page 38 Reset switch (CN6, Pin6, 7) You can connect an external switch to easily reset your computer. This switch restarts your computer as if you had turned off the power, then turned it back on. Reset switch (CN6, Pin6, 7) Function RST-IN Chapter 2 Installation 33...
  • Page 39 External/internal speaker (CN6, Pin 8~11) The CPU card has its own buzzer. You can also connect to the external speaker on your computer chassis. Pin assignments for CN6 (Pin8~11)are shown below: External speaker (CN6, Pin 8~11) Function Vcc (For external speaker use) BZ_IN* BUZZ* * default...
  • Page 40 Hard drive LED (CN6, Pin 13, 14) You can connect an LED to indicate when an IDE device is in use. The pin assignments for this connector are as follows: Hard drive LED (CN6, Pin 13, 14) Function HD-LED+ HD-LED- Chapter 2 Installation 35...
  • Page 41 CPU fan power connector (CN7) The SBC-658 onboard offer +12V power for the CPU cooling fan. Plug in the fan cable onto the 3 pins fan power connector onboard. The fan connector is marked CN7. 1 2 3 CPU fan power connector (CN7) Signal +12V Fan speed sense...
  • Page 42 100Base-T Ethernet connector (CN9) This 100Base-T Ethernet connector CN9 is a standard RJ-45 connector. The onboard Intel 82559ER fast Ethernet controller supports 10Mb/s and 100 Mb/s N-way auto-negotiation operation. Chapter 2 Installation 37...
  • Page 43 IDE hard drive connector (CN10) You can attach up to two Enhanced Integrated Device Electronics hard disk drives to the SBC-658's CN10. The SBC-658's IDE controller uses a PCI local bus interface. This advanced interface supports faster data transfer and allows the IDE hard drive to exceed 528 MB.
  • Page 44 IDE hard drive connector (CN10) (CN10) IDE hard drive connector Signal Signal IDE RESET DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15...
  • Page 45 Floppy drive connector (CN12) You can attach up to two floppy drives to the mainboard control- ler. You can use any combination of 5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB, and 2.88 MB) drives. A 34-pin daisy-chain drive connector cable is required for a dual- drive system.
  • Page 46 Connecting the floppy drive 1. Plug the 34-pin flat-cable connector into CN12. Make sure that the red or blue wire corresponds to pin 1 on the connector. 2. Attach the appropriate connector on the other end of the cable to the floppy drive(s). You can use only one connector in the set.
  • Page 47 Floppy drive connector (CN12) Floppy drive connector (CN12) Signal Signal DENSITY SELECT 0 DENSITY SELECT 1 INDEX MOTOR 0 DRIVE SELECT 1 DRIVE SELECT 2 MOTOR 1 DIRECTION STEP WRITE DATA WRITE GATE TRACK 0 WRITE PROTECT READ DATA HEAD DELECT DISK CHANGE 42 SBC-658 User Manual...
  • Page 48 DiskOnChip socket (U10) The DiskOnChip 2000 family of products provides a single chip solid-state flash disk in a standard 32 pins DIP package. The DiskOnChip 2000 is a solid-state disk with no moving parts, resulting in a significant reduction in power consumption and an increase in reliability.
  • Page 49 DiskOnChip (DOC) 2000 Installation When the DOC is installed correctly, a DOC will work like an HDD or an FDD. To install the DOC on the SBC-658, follow the instruc- tions below: 1. Plug the DOC into the socket. Make sure pin 1 of the DOC is aligned with pin 1 of the socket.
  • Page 50 Award BIOS Setup This chapter describes how to configure the BIOS for the system. Chapter 3 Award BIOS Setup...

  • Page 51: Chapter3 Award Bios Setup

    Starting setup The Award BIOS is immediately activated when you first turn on the computer. The BIOS reads system configuration information in CMOS RAM and begins the process of checking out the system and configuring it through the power-on self test (POST). When these preliminaries are finished, the BIOS seeks an operating system on one of the data storage devices (hard drive, floppy drive, etc.).
  • Page 52 Setup keys These keys helps you navigate in Setup: Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item in the left hand Right arrow Move to the item in the right hand Main Menu: Quit and not save changes into CMOS RAM Other pages: Exit current page and return to...
  • Page 53 Getting help Press F1 to pop up a small help window that describes the appro- priate keys to use and the possible selections for the highlighted item. To exit the Help Window press Esc or the F1 key again. In Case of Problems If, after making and saving system changes with Setup, you discover that your computer no longer is able to boot, the Award- BIOS supports an override to the CMOS settings that resets your...
  • Page 54 Main setup Menu Standard CMOS Options in the original PC AT-compatible BIOS. BIOS Features Award Software enhanced BIOS options. Chipset Features Options specific to your system chipset. Power Advanced Power Management (APM) Management options. PnP/PCI Plug and Play standard and PCI Local Bus Configuration configuration options.
  • Page 55 Load BIOS BIOS defaults are factory settings for the Defaults most stable, minimal-performance system operations. Load Setup Setup defaults are factory settings for Defaults optimal-performance system operations. Save & Exit Save settings in nonvolatile CMOS Setup RAM and exit Setup. Exit Without Abandon all changes and exit Setup.
  • Page 56 Standard CMOS setup When you choose the STANDARD CMOS SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. Chapter 3 Award BIOS Setup...
  • Page 57 This standard setup menu allows users to configure system components such as the date, time, hard disk drive, floppy drive, display, and memory. Online help for each field can be accessed by pressing F1. Date and Time Configuration The BIOS determines the day of the week from the other date information.
  • Page 58 selecting the drive type are available: 1.Match the specifications of your installed IDE hard drive(s) with the preprogrammed values for drive types 1 through 45. 2.Select USER and enter values into each drive parameter field. 3.Use the IDE HDD AUTO DECTECTION function in Setup. Here is a brief explanation of drive specifications: •Type: The BIOS contains a table of pre-defined drive types.
  • Page 59 - LBA (Logical Block Addressing): During drive accesses, the IDE controller transforms the data address described by sector, head, and cylinder number into a physical block address, significantly improving data transfer rates. For drives with greater than 1024 cylinders. Drive A Drive B Select the correct specifications for the diskette drive(s) installed in the computer.
  • Page 60 Halt On During the power-on-self-test (POST), the computer stops if the BIOS detects a hardware error. You can tell the BIOS to ignore certain errors during POST and continue the boot-up process. These are the selections: • No errors: POST does not stop for any errors. •...
  • Page 61 • Extended Memory Above the 1-MB boundary. Early IBM personal computers could not use memory above 1 MB, but current PCs and their software can use extended memory. • Other Memory Between 640 KB and 1 MB; often called High memory. DOS may load terminate-and-stay-resident (TSR) programs, such as device drivers, in this area, to free as much conventional memory as possible for applications.
  • Page 62 BIOS features setup By choosing the BIOS FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. Chapter 3 Award BIOS Setup...
  • Page 63 The displayed configuration is based on the manufacturer's SETUP DEFAULTS settings. Virus Warning When enabled, you receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an anti- virus program.
  • Page 64 Shadow Software that resides in a read-only memory (ROM) chip on a device is called firmware. The AwardBIOS permits shadowing of firmware such as the system BIOS, video BIOS, and similar operat- ing instructions that come with some expansion peripherals, such as, for example, a SCSI adaptor.
  • Page 65 CHIPSET features setup By choosing the CHIPSET FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. SBC-658 User Manual...
  • Page 66 The displayed configuration is based on the manufacturer's SETUP DEFAULTS settings. This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and access to system memory resources, such as SDRAM. It also coordinates communications between the conventional ISA bus and the PCI bus.
  • Page 67 SDRAM Precharge Control When Enabled, all CPU cycles to SDRAM result in an All Banks Precharge Command on the SDRAM interface. DRAM Data Integrity Mode Select Non-ECC or ECC (error-correcting code), according to the type of installed DRAM. System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better system performance.
  • Page 68 Memory Hole at 15M-16M You can reserve this area of system memory for ISA adapter ROM. When this area is reserved, it cannot be cached. The user informa- tion of peripherals that need to use this area of system memory usually discusses their memory requirements.
  • Page 69 Power management setup By choosing the POWER MANAGEMENT option from the INITIAL SETUP SCREEN menu, the screen below is displayed. SBC-658 User Manual...
  • Page 70 The displayed configuration is based on the manufacturer's SETUP DEFAULTS settings. Power Management This option allows you to select the type (or degree) of power saving for Doze, Standby, and Suspend modes. This table describes each power management mode: Max Saving Maximum power savings.
  • Page 71 PM Control by APM If Advanced Power Management (APM) is installed on your system, selecting Yes gives better power savings. Video Off Method Determines the manner in which the monitor is blanked. V/H SYNC+Blank System turns off vertical and horizontal synchronization ports and writes blanks to the video buffer.
  • Page 72 Standby Mode After the selected period of system inactivity, the CPU clock stops, the hard drive enters an idle state, and the L2 cache enters a power- save mode. All other devices still operate at full speed. Suspend Mode After the selected period of system inactivity, the chipset enters a hardware suspend mode, stopping the CPU clock and possibly causing other system devices to enter power management modes.
  • Page 73 Reload Global Timer Events When Enabled, an event occurring on each device listed below restarts the global timer for Standby mode. IRQ3-7, 9-15, NMI Primary IDE 0 Primary IDE 1 Floppy Disk Serial Port Parallel Port SBC-658 User Manual...
  • Page 74 PNP/PCI configuration setup By choosing the PNP/PCI CONFIGURATION SETUP option from the initial SETUP SCREEN menu, the screen below is displayed. Chapter 3 Award BIOS Setup...
  • Page 75 The displayed configuration is based on the manufacturer's SETUP DEFAULTS settings. NOTE: This chapter describes all fields offered by Award Software in this screen. Your system board designer may omit or modify some fields. PNP OS Installed Select Yes if the system operating environment is Plug-and-Play aware (e.g., Windows 95).
  • Page 76 Load BIOS defaults/Load setup defaults LOAD BIOS DEFAULTS loads the default system values directly from ROM. The BIOS DEFAULTS provides the most stable settings, though they do not provide optimal performance. LOAD SETUP DEFAULTS, on the other hand, provides for maximum system performance.
  • Page 77 Integrated peripherals setup By choosing the INTEGRATD PERIPHERALS option from the initial SETUP SCREEN menu, the screen below is displayed. SBC-658 User Manual...
  • Page 78 The displayed configuration is based on the manufacturer's SETUP DEFAULSTS settings. IDE HDD Block Mode Select Enabled only if your hard drives support block mode. IDE Primary Master/Slave UDMA UDMA (Ultra DMA) is a DMA data transfer protocol that utilizes ATA commands and the ATA bus to allow DMA commands to transfer data at a maximum burst rate of 33 MB/s.
  • Page 79 RxD, TxD Active Consult your IR peripheral documentation to select the correct setting of the TxD and RxD signals. ECP Mode Use DMA Select a DMA channel for the port. EPP Mode select Select EPP port type 1.7 or 1.9. SBC-658 User Manual...
  • Page 80 Supervisor/User password setting You can set either SUPERVISOR or USER PASSWORD, or both of them. The difference between the two is that the supervisor password allows unrestricted access to enter and change the options of the setup menus, while the user password only allows entry to the program, but not modify options.
  • Page 81 When you select this function, a message appears at the center of the screen: ENTER PASSWORD: Type the password, up to eight characters, and press Enter. Typing a password clears any previously entered password from CMOS memory. Now the message changes: CONFIRM PASSWORD: Again, type the password and press Enter.
  • Page 82 IDE HDD auto detection The IDE HDD AUTO DETECTION utility can automatically detect the IDE hard disk installed in your system. You can use it to self- detect and/or correct the hard disk type configuration. You need to repeat the setup for each of the IDE combinations: Chapter 3 Award BIOS Setup...
  • Page 83 Save & exit setup If you select this option and press <ENTER>, the values entered in the setup utility will be recorded in the chipset's CMOS memory. The microprocessor will check this every time you turn your system on and compare this to what it finds as it checks the system.
  • Page 84 Flat Panel/CRT Controller Display Drivers and Utilities This chapter provides information about: • Driver types and installation Chapter 4 Driver Installation...
  • Page 85 Software drivers This chapter describes the operation and installation of the display drivers supplied on the Supporting CD-ROM that are shipped with your product. The onboard VGA adapter is based on the CHIPS VGA Flat Panel/CRT controller and is fully IBM VGA compatible. This controller offers a large set of extended functions and higher resolutions.
  • Page 86 Necessary prerequisites The instructions in this manual assume that you understand elementa- ry concepts of MS-DOS and the IBM Personal Computer. Before you attempt to install any driver or utility, you should: • Know how to copy files from a CD-ROM to a directory on the hard disk •...
  • Page 87 Windows® 95 ® ® These drivers are designed to work with Microsoft Windows . You ® just install these drivers through the Windows operating system. Driver installation ® 1. Install Windows 95 as you normally would for a VGA display. Click the Start button, go to Settings and click on Control Panel.
  • Page 88 Click the setting buttom, then click the Advanced Properties icon into the Advanced Display properties windows, show as figure2: figure 2 Chapter 4 Driver Installation...
  • Page 89 click on Change Display Type. In the Change Display Type window, click on the Change button under Adapter Type into the select Device window show as figure(3):This will bring up the Select Device window. figure 3 SBC-658 User Manual...
  • Page 90 2. Place the Supporting CD-ROM in your CD-ROM drive. figure 4 Chapter 4 Driver Installation...
  • Page 91 The name of the Chips And Techn "69000 PCI " driver will appear highlighted in the Models list boxfhow as figure. Click OK to start the driver installation show as figure 6: figure 6 SBC-658 User Manual...
  • Page 92 3. Once the installation is complete, the Advanced display Properties window will reappear. Show as figure (7): figure 7 Chapter 4 Driver Installation...
  • Page 93 Click on close to close the window. Then the Display Properties window will reappear. Show as figure (8): figure 8 SBC-658 User Manual...
  • Page 94 Click on Apply. Restart the system for the new settings to take effect, show as figure (9): figure 9 Chapter 4 Driver Installation...
  • Page 95 Windows® NT 3.51 ® ® These drivers are designed to work with Microsoft Windows Driver installation ® 1. Install Windows NT 3.51 as you normally would for a VGA display. Click the Star buttom, go to Settings and click on Control Panel icon.
  • Page 96 Windows® NT 4.0 Driver installation ® 1. Install Windows NT 4.0 as you normally would for a VGA display. Click the Star buttom, go to Settings and click on Control Panel icon. Then choose the Display and double click on the icon. In the Display Properties window, click the Setting buttom, then click the Display Type buttom into the Display Type windows, then click on Change buttom from the Adapter Type icon.
  • Page 97 SBC-658 User Manual...
  • Page 98 Ethernet Software Configuration This chapter describes how to configure the Etherent Card to match your applica- tion requirements. Chapter 5 Software Configuration...
  • Page 99 Ethernet software configuration The onboard Ethernet interface supports all major network operating systems. I/O addresses and interrupts are easily configured via the Award BIOS Setup. To configure the medium type, to view the current configuration, or to run diagnostics, please refer to the following instruction: 1.
  • Page 100 Programming the Watchdog Timer The mainboard is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial stand-alone and unmanned environments. Appendix A Programming the Watchdog Timer...
  • Page 101 Programming the watchdog timer Watchdog timer The watchdog timer uses a 8-bit counter. The time range is from 32 seconds to 254.5 min with a resolution of 1 min. When timer times out, a system reset will happen. Configuration register The watchdog timer of SBC-658 is located on the chipset –...
  • Page 102 How to set the watchdog timer 1.Set register 30h of logical device 7 to 1 to activate the timer. 2.Write the desired counter value to register F2h of logical deivice Logical Device 7 : Register number 30h (CR30) 00h : timer inactive 01h : timer active Logicel Device 8 : Register number F2h (CRF2) 00h : Time-out Disable...
  • Page 103 Example Following is an example of programming 32 sec period for watch- dog timer in assembly language. When timer times out, it will generate signal of system reset. CONFIG_PORT 3f0h DATA_PORT 3f1h SetWatchDog_Time PROC push bx push cx push dx bl,7 ;;...
  • Page 104 ;; Enter to I/O Chip Program Configuration Register Mode Enterv Config proc push push al,87h ;; Specific value to enter Config ;; Mode dx,cs:CONFIG_PORT dx,al ;; Write to Config Port twice! dx,al ;; Delay EnterConfig endp ;; Exit to I/O Chip Program Configuration Register Mode ExitConfig proc push ax push dx...
  • Page 105 ExitConfig endp ;; Select The I/O Chip Program Configuration Register Logical Device ;; Input : bl = logical device number SelectDevice proc push ax push dx al,07h ;; Select control register 7 dx,cs:CONFIG_PORT dx,al ;; Write to Config Port al,bl ;;...
  • Page 106 W977Write PROC push call EnterConfig ;; Enter Config Mode call SelectDevice ;; Select logical device dx,cs:CONFIG_PORT dx,al ;; Select register number al,ah dx,cs:DATA_PORT dx,al call ExitConfig ;; Exit Config Mode W977Write ENDP Appendix A Programming the Watchdog Timer...
  • Page 107 Installing PC/104 Modules This appendix provides instructions for installing PC/104 modules. Appendix B Installing PC/104 Modules...
  • Page 108 Installing PC/104 modules The SBC-658's PC/104 connectors give you the flexibility to attach PC/104 expansion modules. These modules perform the functions of traditional plug-in expansion cards, but save space and valuable slots. Modules include: • PCM-3115B PCMCIA Module (two-slot) • PCM-3420 PC/104 Fast SCSI Module •...
  • Page 109 PC/104 Mounting Support Female Male Main board PC/104 Module PC/104 Module Mounting Diagram 0.300 3.250 3.775 3.575 3.575 0.200 0.200 3.350 0.200 3.550 PC/104 module dimenstions (inches ±5%) Appendix B Installing PC/104 Modules...
