R e m o t e T o u c h D i s p l a y
A G D - 3 1 7 R
AGD-317R
17" SXGA (1280x1024)
Rugged Touch Display
With Remote Display Technology
IP-65 Front Bezel
Multi-Touch Window Design (Two-Point)
st
AGD-317R Manual 1
Ed
April 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGD-317R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aaeon AGD-317R

Summary of Contents for Aaeon AGD-317R

  • Page 1 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R AGD-317R 17” SXGA (1280x1024) Rugged Touch Display With Remote Display Technology IP-65 Front Bezel Multi-Touch Window Design (Two-Point) AGD-317R Manual 1 April 2012...

  • Page 2: Copyright Notice

    AAEON, assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Acknowledgments ® ®  Intel is registered trademarks of Intel Corporation.  IBM, PC/AT, PS/2 are trademarks of International Business Machines Corporation.

  • Page 4: Packing List

    The LCD monitor comes with the following standard parts shown as below. Check and make sure they are included and in good condition. If anything is missing or damaged, contact the dealer immediately.  AGD-317R  Utility CD-ROM Contains User’s Manual (in PDF format), Drivers and Utilities ...
  • Page 5 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Safety & Warranty 1. Read these safety instructions carefully. 2. Keep this user's manual for later reference. 3.
  • Page 6 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 14. If any of the following situations arises, get the equipment checked by service personnel: a.
  • Page 7 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Display 有毒有害物质或元素 部件名称 铅 汞 镉...

  • Page 8: Table Of Contents

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Contents Chapter 1 General Information 1.1 Introduction..............1-2 1.2 Features ..............1-3 1.3 General Specification ..........1-4 1.4 Dimension ..............
  • Page 9 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Chapter 3 On Screen Display Control 3.1 On Screen Display (OSD) Board Description... 3-2 3.2 OSD Main Menu: Push The MENU Keys....

  • Page 10: Chapter 1 General Information

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Chapter General Information Chapter 1 General Information...

  • Page 11: Introduction

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 1.1 Introduction Thank you for purchasing of the Infotainment Touch Display with Remote Display Technology - a marvelous contribution of cutting-edge technology.

  • Page 12: Features

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 1.2 Features  17” SXGA (1280x1024) TFT LCD Display  Supports Remote Display Technology ...

  • Page 13: General Specification

    VGA, DVI  Input signal  Control Menu, Auto, LCD on/off, Up, Down AGD-317R-A2: USB x 3 (2 on front, 1 on  I/O connector rear), LAN x 1, Line-out x 1 AGD-317R-A1: LAN x 2, Line-out x 1 ®...
  • Page 14 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R  Storage -4°F~ 158°F (-20°C ~ 70°C) Temperature  Storage 10%~95% @ 40°C, non-condensing Humidity 1g rms/5-500Hz/random operation ...
  • Page 15 A G D - 3 1 7 R Touchscreen 5-wire resistive (AGD-317R-A2 only)  Type  Light Transmission Lifetime (times) 35 million activations  Note: Users have to select the ACG-203 to work with the AGD-317R Chapter 1 General Information...

  • Page 16: Dimension

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 1.4 Dimension 302.40 100.00 75.00 419.79 6.00 28.00 7.50 64.40 71.90 Chapter 1 General Information...

  • Page 17: Network Topology

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 1.5 Network Topology One-to-one Network The purpose of a one-to-one network is to allow a display to be used anywhere away from the host PC.
  • Page 18 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Cascade Network The purpose of a cascade network is to save on cabling installation costs. It is specially designed for digital signage applications with limited space such as trains, buses and airports.

  • Page 19: Chapter 2 Hardware Installation

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Chapter Hardware Installation Chapter 2 Hardware Installation...

  • Page 20: Before Unpacking

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 2.1 Before Unpacking It is very important to place the LCD Display in a suitable environment.

  • Page 21: Connecting Power And Cables

    2.2 Connecting Power and Cables To power on the LCD Display, use the provided AC-DC adapter and the power cord to connect to the power output socket of the monitor. Fasten the connector securely. AGD-317R-A1 AGD-317R-A2 Chapter 2 Hardware Installation...

  • Page 22: Panel Mounting

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 2.3 Panel Mounting This LCD Display can be placed on a shelf or table, or mounted onto the wall.

  • Page 23: Desktop, Swing-Arm Mounting

    Desktop Stand The brackets of desktop stand are attached to the rear of AGD-317R. First of all, loosen the screw of point A. Then, unscrew the screw of point B. Pull...

  • Page 24: Vesa Wall Mounting

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R in point B. There should be no screw in point A. 2.5 VESA Wall Mounting Mounting the LCD Display with UL Listed Wallmount Bracket only.
  • Page 25 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Monitor Arm or Wallmount Plate Installation The LCD Display has Video Electronics Standards Association (VESA) standard mounting holes tapped into the rear panel.

  • Page 26: Led Definitions

    Link in process Flash Load firmware 2.7 Button Definitions There are three buttons on remote gateway and display. Refer to the following LED definitions. AGD-317R-A1 (One-to-multiple Network) Link on: Link (Default) Video Mode* (Default) Short Press Link off: Unlink Graphic Mode*...
  • Page 27 Note: All of the displays has to be set in one resolution and it will be the lowest resolution. AGD-317R-A2 (One-to-one Network) Link on: Link (Default) Video Mode* (Default)
  • Page 28 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R *3: Engineering mode: (1)Static IP: 192.168.0.88 (2)User can connect to http://192.168.0.88 webpage for firmware update.

  • Page 29: Dip Switch

    The function of DIP switch is to make ACG-203 and remote displays in one group. When users want to send the data from specific ACG-203 to several specific AGD-317R, they need to make the DIP switch of ACG and AGD-317R to be the same.

  • Page 30: Connecting Power Of Remote Display

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 2.9 Connecting Power of Remote Display To power on the LCD monitor, use the provided AC-DC adapter and the power cord to connect to the power output socket of the monitor.

  • Page 31: Connection Debugging

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 2.11 Connecting Debugging If the connection or display cannot work well, please refer to the debugging steps below.

  • Page 32: The Matching Of The Remote Box And Remote

     A2 Display (One to one) has to work with ACG-203-A2 If you did not use AAEON’s Remote Displays, you have to use ACG-204 series to work with non-AAEON displays. The PC will connect to ACG-203 series and the ACG-203 series will connect to ACG-204 series through RJ-45 cables.

  • Page 33: Display

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Chapter On Screen Display Control Chapter 3 On Screen Display Control 3-1...

  • Page 34: On Screen Display (Osd) Board Description

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.1 On Screen Display (OSD) Board Description Buttons Description  Power Turn the monitor power ON or OFF. ...

  • Page 35: Osd Main Menu: Push The Menu Keys

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.2 OSD Main Menu: Push The MENU Keys Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm...

  • Page 36: Select Input Source

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.3 Select Input Source Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 37: Contrast/ Brightness- Submenu

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.4 Contrast/ Brightness- Submenu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 38: Geometry Menu

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.5 Geometry Menu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...
  • Page 39 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.6 Color Temperature- Submenu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 40: Rgb Color- Submenu

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.7 RGB Color- Submenu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 41: Language- Submenu

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.8 Language- Submenu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 42: Auto Config- Submenu

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.9 Auto Config- Submenu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 43: Mode Resolution- Submenu Chapter

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.10 Mode Resolution- Submenu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 44: Exit Menu- Submenu

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3.11 Exit Menu- Submenu Available Key Functions Power On/Off the LCD Monitor Increase the gaguge value of the selected option Decrease the gaguge value of the selected option Slected to confirm Return to last menu...

  • Page 45: Chapter 4 Touch Screen Driver Installation

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Chapter Touch Screen Driver Installation Chapter 4 Touch Screen Driver Installation...

  • Page 46: Introduction

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 4.1 Introduction The optional AGD-317R Series touch screen uses 5-wire resistive technology to provide more accurate sensing capacity than other technologies. The touch screen is specially designed for tough industrial environments, and has been approved by FCC Class A standards.
  • Page 47 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Serial Interface • EIA 232E (Serial RS-232), DCE configuration. 8 Data Bits, 1 Stop Bit, No Parity, Full Duplex. •...
  • Page 48 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R Operating Modes Full Touch Smart Set protocol. Emulation of E281A-4002 protocol can be selected by Smart Set command. Initial/ Stream/ Un touch/ Z-axis Enable Modes.

  • Page 49: Resistive Touch Screen Driver Installation

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 4.2 Resistive Touch screen Driver Installation Hardware Touch screen controllers must be configured for the driver prior to installation.
  • Page 50 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R ® ® The Windows XP and Windows 7 operating systems have native HID drivers that provide low-level support for EETI touch screen controller.

  • Page 51: Installing Driver For Windows

    R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R ® ® 4.3 Installing Driver for Windows XP/ Windows 7 / Linux ® ® The touch screen has drivers for Windows XP、...
  • Page 52 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 2. Click the “Next” button on the screen 3. Click on the “Finish” button and restart your system Single monitor, Serial Port controller The driver files will install automatically.
  • Page 53 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 1. Executing eGalax on Desktop 2. Recognition devices choose to run calibration immediately Chapter 4 Driver Installation...
  • Page 54 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3. Choose Tools to calibrate 4. Click on 4 Points Calibration to execute calibration Note: If the alignments do not match display by 4 Points Calibration, please use 9 Ports or more to calibrate.
  • Page 55 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R ® For Windows 7 OS please execute: CD-ROM: \\TouchScreen-DRV\eGalax Touch \Win 7 \Setup.exe 1. Click on the “Next” button 2.
  • Page 56 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3. Tick “None” if the system did not start 4 points calibrating after reboot. Click on the “Next” button. 4.
  • Page 57 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 5. Select Destination Folder, and click on the “Next” button 6. Click on the “Next” button Single monitor, Serial Port controller The driver files will install automatically.
  • Page 58 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 1. Executing eGalax on Desktop 2. Recognition devices choose to run calibration immediately 4-14 Chapter 4 Touch Screen Driver Installation...
  • Page 59 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3. Choose Tools to run calibration 4. Click on 4 Points Calibration to execute calibration Note: If the alignments do not match display by 4 Points Calibration, please use 9 Ports or more to calibrate.
  • Page 60 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R For Linux Fedora 14 kernel 2.6.35.6-45.fc14 OS please execute: CD-ROM: \\TouchScreen-DRV\eGalax Touch \Linux\eGalaxTouch 32 1.
  • Page 61 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 3. Input command ( cp /root/xorg.conf.new /etc/X11/xorg.conf) 4. Load Linux Folder Touch Driver 4-17 Chapter 4 Driver Installation...
  • Page 62 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 5. Executive Touch Driver 6. Which interface controller do you use? 4-18 Chapter 4 Touch Screen Driver Installation...
  • Page 63 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 7. Select the “ 3 ” USB interface. (Select the USB interface and press “Enter” key of the keyboard to start the installation) 8.
  • Page 64 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 9. Execute reboot 10. Select the X86 Folder (Because Linux is 32 bit) 4-20 Chapter 4 Touch Screen Driver Installation...
  • Page 65 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 11. Select “eGalax Touch32_Version1.1-2.6X” Folder 12. Select “eGalax Touch32” Folder 4-21 Chapter 4 Driver Installation...
  • Page 66 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 13. Click on the “eGalax Touch” to calibrate immediately 14. Choose “Tool” to calibrate 4-22 Chapter 4 Touch Screen Driver Installation...
  • Page 67 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 15. Execute 4 Points Calibration Note: If the alignments do not match display by 4 Points Calibration, please use 9 Ports or more to calibrate.
  • Page 68 R e m o t e T o u c h D i s p l a y A G D - 3 1 7 R 17. If you are going to replace the Interface, please remove the old Touch Driver (Input command: sh setup.sh uninstall) 18.
