A AUDIO EZ-EXTENDER BILL OF
MATERIALS
The bill of materials corresponds to
page B-1. Please check the latest schematics on the Analog Devices web-
site:
http://www.analog.com/Processors/Processors/DevelopmentTools/tec
hnicalLibrary/manuals/DevToolsIndex.html#Evalua-
tion%20Kit%20Manuals
Ref. Qty. Description
1 1 SN74LVC1G08
SOT23-5
2 1 74LVC74A
TSSOP14
3 1 27MHZ OSC011
6 S
N74LVC257 TSSOP16
4
5 2 AD1938XSTZ
LQFP48
6 1 ADAV801ASTZ
LQFP64
7 8 AD8608ARUZ
TSSOP14
8 3 RCA 4X2 CON011
9 2 RCA 1X1 CON012
10 3 0.05 45x2 CON018
Blackfin Audio EZ-Extender Manual
"Audio EZ-Extender Schematic" on
.
Reference Designator
U1
U9
Y1
U3,U6,U10-11,U13,
U16
U7,U18
U14
U4-5,U8,U12,U15,U
19,U21-22
J4,J7-8
J5-6
P1-3
Manufacturer Part Number
TI SN74LVC1G08DBVR
PHILIPS 74LVC74APW
DIGI-KEY 300-8571-1-ND
DIGI-KEY 296-8506-1-ND
ANALOG AD1938XSTZ
DEVICES
ANALOG ADAV801ASTZ
DEVICES
ANALOG AD8608ARUZ
DEVICES
SWITCH- PJRAS4X2U01X
CRAFT
SWITCH- PJRAN1X1U01X
CRAFT
SAMTEC TFC-145-32-F-D
A-1
