  • Page 1 ACADIAN / NORMANDY / BRUNSWICK PARSON CHAIR MODEL # WS5113-4-DBR...
  • Page 2 Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 Monday to Friday between 9 am – 5 pm EST or go to www.simpli-home.com To assist you in a timely manner, please ensure you have all necessary...
  • Page 3: Safety Information

    IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts.
  • Page 4: Parts Description

    PRE-ASSEMBLY INFORMATION MODEL # WS5113-4-DBR MODEL # AXCOT-235-DBR PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION CHAIR BACK SEAT FRONT LEG QTY 1 QTY 1 QTY 2 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 (9 am to 5 pm EST)
  • Page 5: Hardware Description

    PRE-ASSEMBLY INFORMATION MODEL # WS5113-4-DBR MODEL # AXCOT-235-DBR PRE-ASSEMBLY INFORMATION HARDWARE DESCRIPTION ALLEN KEY SCREW ALLEN KEY SCREW ALLEN KEY SCREW M8 x 45 MM M8 x 60 MM M8 x 80 MM QTY 4 QTY 1 QTY 4 ALLEN KEY DOWEL FLAT WASHER Ø8 x 30 MM...
  • Page 6 ASSEMBLY MODEL # WS5113-4-DBR STEP 1 Insert Dowels (5) into pre-drilled holes on Seat (B). Attach Seat (B) to Chair Back (A) using Allen Key Screw (1) and one Washer each of (6) and (7). Use Allen Key (4) to tighten. Do not over-tighten...
  • Page 7 ASSEMBLY MODEL # WS5113-4-DBR STEP 2 Secure Seat (B) to Chair Back (A) using Allen Keys Screws (3) and four Washers each of (6) and (7). Use Allen Key (4) to tighten. Do not over-tighten.
  • Page 8 ASSEMBLY MODEL # WS5113-4-DBR STEP 3 Attach Front Legs (C) to Seat (B) using Allen Keys Screws (2) and four Washers each of (6) and (7). Use Allen Key (4) to tighten. Do not over-tighten.
  • Page 9 ASSEMBLY MODEL # WS5113-4-DBR STEP 4 Place Chair on a flat level surface to ensure it is level. If it is uneven, adjust either the Seat (B) or Front Legs (C). Ensure the Chair is level and then fully tighten all bolts.
  • Page 10: Warranty

    WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights.
