Summary of Contents for Simpli Home AXCRAMH15-LGB
- Page 1 SIMP HOME L I F E B Y D E S I G N AMHERST / HALIFAX / WASHINGTON MEDIUM STORAGE CABINET MODEL # AXCR AMH15-LG 1/21...
- Page 2 SIMP HOME L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. -
Page 5: Pre-Assembly Information
MODEL # AXCRAMH15-LGB PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF CENTRE SUPPORT DOOR QTY 1 QTY 1 QTY 1 Warning Label SHELF LEFT BACK PANEL RIGHT BACK PANEL QTY 1 QTY 1... - Page 6 MODEL # AXCRAMH15-LGB PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION DRAWER FRONT LEFT DRAWER SIDE RIGHT DRAWER SIDE QTY 4 QTY 4 QTY 4 DRAWER BOTTOM DRAWER BACK QTY 4 QTY 4 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
-
Page 7: Hardware Description
MODEL # AXCRAMH15-LGB PRE-ASSEMBLY INFORMATION HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN ALLEN KEY M6 X 30 mm CAM LOCK QTY 1 QTY 28 QTY 22 SETS PHILLIPS SCREW ROUND HEAD HANDLE ADJUSTABLE HINGE M4 X 15 mm QTY 5 SETS... - Page 8 COMPONENTS – KEY DIAGRAM MODEL # AXCRAMH15-LGB 8/21...
- Page 9 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 1 1. Attach 4 Cam Lock Pins 2 to back of Drawer Front I . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides JL , JR . 3. Insert 2 Cam Lock 2 into guide holes on each Drawer Side JL , JR .
- Page 10 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 3 1. Align Drawer Back K with Drawer Bottom L and press firmly into slot . 2. Attach back using 2 Allen Key Screws 1 through guide holes on each side. 3. Use Allen Key 3 to tighten Screws. Do not over tighten.
- Page 11 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 5 1. Attach Centre Support E to Bottom Shelf D using Allen Key Screws 1 through guide holes. 2. Use Allen Key 3 to tighten Screws. Do not over tighten. STEP 6 1. Attach Cam Lock Pins 2 into pre-drilled holes on each Side B , C .
- Page 12 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 7 1. Attach Top A to Sides B , C using Allen Key Screws 1 . 2. Attach Top A to Centre Support Shelf E using Allen Key 1 . Tighten the Centre Support Shelf to pre-drill hole at the right side support bar underneath of top.
- Page 13 ASSEMBLY MODEL # AXCRAMH15-LGB Triangle ruler STEP 8 NOTE: The triangle ruler is not included in the hardware pack. Adjust the cabinet frame before assembling the back panels. STEP 9 Warning Label 1. Attach Back Panels GL , GR to back of cabinet using Phillips Screws Round Head 5 into guide holes.
- Page 14 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 10 1. Attach Adjustable Hinges 6 to Door F using Phillips Screws 10 into pre-drilled holes on Door F . 2. Attach Adjustable Hinges on Door F to Side C using Phillips Screws 10 into pre-drilled holes on Side C .
-
Page 15: Important Note
ASSEMBLY MODEL # AXCRAMH15-LGB IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1. Side adjustment 4 mm To move the door towards the side panel, loosen screw I and tighten screw II . - Page 16 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 11 1. Attach Magnet Plate 7 to bottom corner of Door F using Phillips Screws 9 into pre-drilled holes on Door F . 2. Attach Magnet 7 using Phillips Screws 9 into pre-drilled holes on Bottom Shelf D .
- Page 17 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 12 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 1. Use 4 Shelf Supports 8 for each Cabinet Shelf H in desired location. 2. 2 Shelf Supports 8 may be used on back top of each Cabinet Shelf H as...
- Page 18 ASSEMBLY MODEL # AXCRAMH15-LGB STEP 13 1. Insert assembled drawers into glides on assembled Medium Storage Cabinet. 18/21...
- Page 19 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP 14 NOTE: The screwdriver is not included in the hardware pack.
- Page 20 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 21: Warranty
L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
