- Page 1 Amherst / Halifax / Washington TV Media Stand Model # AXCAMH16-LGB...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Ac vate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards. You may even receive store credit on your en re purchase! simpli-home.com/share-images...
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order informa on and issue. Submit form.
-
Page 5: Safety Information
IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 6: Care And Maintenance
Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions. -
Page 7: Maximum Load 25 Lbs
WARNING The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to 68.58 cm). For use with televisions weighing 200 lbs or less. Using larger or heavier televisions may cause instability or tip over which can lead to serious injury or even death. The recommended maximum width of the television intended for use is 60 inch (152.4 cm). - Page 8 Pre-Assembly Information Model # AXCAMH16-LGB Part Description LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF TOP SHELF LEFT DIVIDER QTY 1 QTY 1 QTY 1 SHELF DOOR (L&R Same) RIGHT DIVIDER QTY 2 QTY 2 QTY 1 SHELF TOP BACK PANEL BOTTOM BACK PANEL...
- Page 9 Pre-Assembly Information Model # AXCAMH16-LGB Hardware Description CAM LOCK PIN ALLEN KEY SCREW ALLEN KEY CAM LOCK M6 X 30 mm QTY 1 QTY 18 SETS QTY 12 WOOD DOWEL HANDLE PHILLIPS SCREW ROUND HEAD Ø8x30 M4x25 mm M4x15 mm QTY 8 QTY 2 SETS QTY 29...
-
Page 10: Warning Label
Components - Key Diagram Model # AXCAMH16-LGB Warning Label... - Page 11 Assembly Model # AXCAMH16-LGB Step 1 1. Attach Dividers EL , ER to Bottom Shelf C using Allen Key Srcews I through guide holes from Bottom Shelf C . Use Allen Key 3 to tighten Srews. 2. Attach 6 Cam Lock Pins 2 into pre-drilled holes at underneath of Top Shelf D . 3.
- Page 12 Assembly Model # AXCAMH16-LGB Step 2 1. Insert 4 Wood dowels 5 into guide holes on each Side BL , BR . 2. Use rubber mallet to tap Wood dowels 5 into bottom of holes securely. 1/2 length of dowels should be exposed. 3.
- Page 13 Assembly Model # AXCAMH16-LGB Step 3 1. Attach Bottom Support Leg K to Bottom Shelf C using 4 Phillips Screws 12 . 2. Use Phillips screwdriver to tighten screws. Do not over-tighten.
- Page 14 Assembly Model # AXCAMH16-LGB Step 4 1. Attach Top A with Sides BL , BR using Allen Key Screws 1 through guide holes. 2. Use Allen Key 3 to tighten Screws. Do not over-tighten.
- Page 15 Assembly Model # AXCAMH16-LGB Step 5 Warning Label 1. Attach Back Panels I , JL , JR, H to back of cabinet using Phillips Screws Round Head 6 through guide holes. 2. Use Phillips screwdriver to tighten screws. Do not over-tighten.
- Page 16 Assembly Model # AXCAMH16-LGB Step 6 1. Attach Adjustable Hinges 7 to Doors F using Phillips Screws 11 into pre-drilled holes on Doors F . 2. Attach Adjustable Hinges on Doors F to Sides BL , BR using Phillips Screws 11 into pre-drilled holes on Sides BL , BR .
-
Page 17: Important Note
Assembly Model # AXCAMH16-LGB IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1. Side adjustment 4 mm To move the door towards the side panel, loosen screw I and tighten screw II . - Page 18 Assembly Model # AXCAMH16-LGB Step 7 1. Attach Magnet Plates 8 to bottom corner of Doors F using Phillips Screws 10 into pre-drilled holes on Doors F . 2. Attach Magnets 8 using Phillips Screws 10 into pre-drilled holes on Bottom Shelf 3.
- Page 19 Assembly Model # AXCAMH16-LGB Step 8 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 1. Use 4 Shelf Supports 9 for each Shelf G1 , G2 in desired location . 2. 2 Shelf Supports 9 may be used on back top of each Shelf G1 , G2 as a tipping restraint.
- Page 20 Furniture Tip Over Restraint Assembly WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. Step 9 NOTE: The screwdriver is not included in the hardware pack.
- Page 21 Furniture Anti-Tipping Restraint Instructions Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
