Gen5 POD MCIO Edition Assembly Reference
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the MCIO Host PCBA and connect to the
HOST side of the POD Unit. Secure in position on the Host/Device
Cable Adaptor Tray with the M3 Captive Screws
0004674 - R1.3
Page 5 of 5
POD Main Unit
M3 Captive Screw
Host/Device Cable Adaptor Tray
MCIO Host PCBA
