Gen5 POD MCIO Edition Assembly Reference
Slide the Host/Device Cable Adaptor Tray into the slot on the HOST side on
the underside of the POD Main Unit at an angle of about 60 ~ .
Rotate the Cable Adaptor Tray so it is horizontal and tighten the M3 Captive
Panel Screws to the POD Main Unit, ensuring not to over tighten.
0004674 - R1.3
Page 2 of 5
Host/Device Cable Adaptor Tray
POD Main Unit
M3 Captive Panel Screw
