Banner ABR 3000 Series Quick Start Manual

ABR 3000
Quick Start Guide
Imager-based barcode reader with superior decoding capability in a compact housing
This guide is designed to help you set up and install the ABR 3000. For complete information on programming, performance, troubleshooting,
dimensions, and accessories, please refer to the Instruction Manual at www.bannerengineering.com. Search for p/n 207637 to view the In-
struction Manual and for p/n 207635 to view the Barcode Manager Software Instruction Manual. Use of this document assumes familiarity with
pertinent industry standards and practices.
WARNING: Not To Be Used for Personnel Protection
Never use this device as a sensing device for personnel protection. Doing so could lead to serious injury or death. This
device does not include the self-checking redundant circuitry necessary to allow its use in personnel safety applications.
A sensor failure or malfunction can cause either an energized or de-energized sensor output condition.
Models
Table 1: ABR 3000 Models
Model Resolution
ABR3009-WSU2
ABR3009-WSE2 WVGA
(752 × 480 pixels)
ABR3009-WSU1
ABR3009-WSE1
ABR3106-WSU2
ABR3106-WSE2
ABR3106-WSU1 1.2 MP
(1280 × 960 pixels)
ABR3106-WSE1
ABR3106-WPU2
ABR3106-WPE2
Features
Figure 1. Models with Serial and Ethernet
2
1 3
4
5
6
8 7
5
Indicators
Figure 3. Indicators—Top of Device
5
6
4
7
3
During the reader startup, all of the LEDs turn on for one second.
See Smart Teach Interface on p. 3 for the colors and meanings of the five LEDs when the reader is in Smart Teach mode.
Original Document
207636 Rev. B
Lens
9 mm, manual focus
6 mm, manual focus
1. Smart Teach Interface
2. Ethernet Connection LED
3. Power LED
4. Button
5. Internal Illuminators
6. Good Read LED (green)
7. Lens
8. Aiming System Laser Source
9. Focus Adjustment Screw
9
10. Ethernet Cable
10
11. Power - Serial - I/O Cable
11
Indicator
1 Power
2 Ethernet Connection
3
READY/Learn
2 4
GOOD/Setup
1
5
TRIGGER/Focus (Aim)
6
COM/Test
7
STATUS
Lighting Options
Standard
White
Polarized
1
5
Color LED Status During Normal Operation
Blue Indicates connection to the power supply
Amber Indicates connection to the Ethernet network
Green Ready
Green Reading successful
Reading in progress. Do not trigger a new reading attempt until the cur-
Amber
rent attempt finishes
Amber Active result output transmission on the Main serial or USB ports
Red No read result
2021-1-6
Communications Codes
Serial/USB 1D and 2D
Serial/Ethernet 1D and 2D
Serial/USB 1D
Serial/Ethernet 1D
Serial/USB 1D and 2D
Serial/Ethernet 1D and 2D
Serial/USB 1D
Serial/Ethernet 1D
Serial/USB 1D and 2D
Serial/Ethernet 1D and 2D
Figure 2. Models with Serial and USB
3
4
5
6
11
8 7
9
