ABR 7000
Quick Start Guide
Imager-based barcode reader with superior decoding capability and a powerful array of lens and lighting options
This guide is designed to help you set up and install the ABR 7000. For complete information on programming, performance, troubleshooting,
dimensions, and accessories, please refer to the Instruction Manual at www.bannerengineering.com. Search for p/n 207634 to view the In-
struction Manual and for p/n 207635 to view the Barcode Manager Software Instruction Manual. Use of this document assumes familiarity with
pertinent industry standards and practices.
WARNING: Not To Be Used for Personnel Protection
Never use this device as a sensing device for personnel protection. Doing so could lead to serious injury or death. This
device does not include the self-checking redundant circuitry necessary to allow its use in personnel safety applications.
A sensor failure or malfunction can cause either an energized or de-energized sensor output condition.
Models
Table 1: ABR 7000 Models
Model Resolution
ABR7109-RSE2
ABR7109-MSE2
ABR7112-RSE2
ABR7116-RSE2
1.3 MP
ABR7106-RSE2
(1280×1024 pixels)
ABR7106-MSE2
ABR71L9-RSE2
ABR71L9-MSE2
ABR71L9-WPE2
ABR72L9-RPE2
ABR72L9-RDE2 2 MP
(1600×1200 pixels)
ABR72L16-WSE2
ABR72L16-RDE2
Features
Figure 1. Models with Manual Adjustable Focus
1
2
3
4
9
5
6
8
7
2 Multicolored DPM models have red bright field lights and blue low angle lights for optimized reading of Direct Park Marked (DPM) codes. Red Diffused
DPM models have both groups of lights as well, but both are red and behind a diffuser.
Original Document
207633 Rev. C
Lens
9 mm, manual focus
9 mm, manual focus
12 mm, manual focus
16 mm, manual focus
6 mm, manual focus
6 mm, manual focus
9 mm, Liquid Lens Autofocus
9 mm, Liquid Lens Autofocus
9 mm, Liquid Lens Autofocus
9 mm, Liquid Lens Autofocus
9 mm, Liquid Lens Autofocus
16 mm, Liquid Lens Autofocus White
16 mm, Liquid Lens Autofocus Red Diffused DPM 2
1. Smart Teach Interface
2. Button
3. Good Read LED (green)
4. Internal Illuminator
5. Aiming System Laser Pointers
6. Lens
7. No Read LED (red)
8. Lens Cover
13
9. Focus Adjustment Screw
12
10. Power - Serial - I/O Connector
11. Ethernet Connector
11
12. Power ON LED
10
13. Ethernet Connection LED
Lighting Options
Red
Multicolored DPM 2
Red
Red
Red
Multicolored DPM 2
Red Standard
Multicolored DPM 2
White Polarized
Red Polarized
Red Diffused DPM 2
1
8
2021-1-6
Communications
Serial/Ethernet 1D and 2D
Figure 2. Models with Liquid Lens Autofocus
2
3
4
5
6
7
10
Codes
13
12
11
