Manual version: APW101-20170630
H3C SecPath T9000-S NSQM2IPSDSCA0 intrusion
prevention system service module
1 Identifier
The module identifier NSQM2IPSDSCA0 is at the upper right corner of the front panel.
2 Introduction
The H3C fourth-generation high performance intrusion prevention system service module
NSQM2IPSDSCA0 is developed for the H3C T9008-S intrusion prevention system. The module
provides features including firewall, VPN, content filtering, content identification, URL filtering, and
NAT and can greatly enhance security capabilities of the gateway.
3 Specifications
The module has a console port, a USB port, a GE copper port, and a hard disk slot
Figure 1 Front panel
1
2
(1) Captive screw
(3) Hard disk slot (reserved)
(5) GE copper port (10/100/1000BASE-T)
(7) Hard disk LED (HD)
Table 1 Module specifications
Item
Flash
Memory
Micro SD card
Dimensions (H × W × D)
Power consumption
Weight
Hot swapping
3
Specification
8MB Nor Flash
Standard configuration: 16 GB (two 8GB VLP RDIMMs)
One built-in Micro SD card slot
Standard configuration: 8 GB
40.1 × 399.2 × 376.8 mm (1.58 × 15.71 × 14.83 in)
116 W to 124 W
3.8 kg (8.38 lb)
Supported
(2) Ejector lever
(4) Console port (CONSOLE)
(6) USB port (reserved)
(8) System status LED (SYS)
i
BOM: 3123A1MQ
7
4
5
6
8
