H3C S5170-EI Series Installation Manual
Hide thumbs
Also See for S5170-EI Series:
- Hardware information (34 pages) ,
- Manual (46 pages) ,
- Troubleshooting manual (37 pages)
Subscribe to Our Youtube Channel
Related Manuals for H3C S5170-EI Series
Summary of Contents for H3C S5170-EI Series
- Page 1 H3C S5170-EI & S5570S-EI Switch Series Installation Guide New H3C Technologies Co., Ltd. http://www.h3c.com Document version: 6W101-20221011...
- Page 2 The information in this document is subject to change without notice. All contents in this document, including statements, information, and recommendations, are believed to be accurate, but they are presented without warranty of any kind, express or implied. H3C shall not be liable for technical or editorial errors or omissions contained herein.
- Page 3 Preface H3C S5170-EI & S5570S-EI Switch Series Installation Guide describes the installation, power-on, maintenance, and troubleshooting of the H3C S5170-EI & S5570S-EI switch series. This preface includes the following topics about the documentation: • Audience. • Conventions. • Documentation feedback.
- Page 4 Symbols Convention Description An alert that calls attention to important information that if not understood or followed WARNING! can result in personal injury. An alert that calls attention to important information that if not understood or followed CAUTION: can result in data loss, data corruption, or damage to hardware or software. An alert that calls attention to essential information.
- Page 5 Documentation feedback You can e-mail your comments about product documentation to info@h3c.com. We appreciate your comments.
-
Page 6: Table Of Contents
Contents Preparing for installation ················································································ 1 Safety recommendations ··································································································································· 2 Examining the installation environment ············································································································· 2 Cleanliness ················································································································································· 4 Corrosive gas limit ······································································································································ 4 Examining the installation site ···························································································································· 5 Checking power distribution or power supply environment ················································································ 6 Laser safety························································································································································ 6 Installation tools ·················································································································································... - Page 7 Removable power supply failure ················································································································ 1 Fan tray failure ··················································································································································· 2 Configuration terminal display issues················································································································· 2 No display ·················································································································································· 2 Garbled display ·········································································································································· 2...
-
Page 8: Preparing For Installation
You can view the PID of a switch on the label located on its rear panel or top panel. • The available chassis models and accessories vary by country and region. This document describes only the preceding models. For the chassis models and accessories available in your country or region, contact the local H3C marketing personnel. -
Page 9: Safety Recommendations
Safety recommendations To avoid any equipment damage or bodily injury caused by improper use, read the following safety recommendations before installation. Note that the recommendations do not cover every possible hazardous condition. • Before cleaning the switch, remove all power cords from the switch. Do not clean the switch with wet cloth or liquid. - Page 10 High temperature can accelerate the aging of insulation materials and significantly lower the reliability and lifespan of the switch. For the temperature and humidity requirements of the switch, see technical specifications in H3C S5170-EI & S5570S-EI Switch Series Hardware Information and Specifications. CAUTION: Ground the switch correctly and verify the grounding.
-
Page 11: Cleanliness
Item Requirements with protection earth (PE) to filter interference from the power grid. • Keep the device far away from radio transmitting stations, radar stations, and high-frequency devices. • Use electromagnetic shielding, for example, shielded interface cables, when necessary. Cleanliness Dust buildup on the chassis might cause electrostatic adsorption and dust corrosion, resulting in poor contact of metal connectors and contact points. -
Page 12: Examining The Installation Site
CAUTION: As a best practice, control the corrosive gas concentrations in the equipment room at their average values. Make sure the corrosive gas concentrations do not exceed 30 minutes per day at their maximum values. To control corrosive gases, use the following guidelines: •... -
Page 13: Checking Power Distribution Or Power Supply Environment
The power supply must be available before you install the switch. The voltage provided to the switch must be within the operating voltage range. Voltage For the operating voltage range, see H3C S5170-EI & S5570S-EI Switch Series Hardware Information and Specifications. •... -
Page 14: Installation Tools
Installation tools No installation tools are provided with the switch. Prepare the following tools yourself as required: • ESD wrist strap • Flat-blade screwdriver • Phillips screwdriver • Needle-nose pliers • Marker Installation accessories Before installation, make sure you have all the required installation accessories. If an installation accessory is damaged or lost, purchase a new one by using the BOM code in Table Table 8 Installation accessories... - Page 15 Code Description Quantity Applicable device models S5570S-54F-EI Power module filler panel S5570S-28S-HPWR-EI 1, provided S5570S-54S-PWR-EI S5570S-30MS-UPWR-EI Power module filler panel S5570S-28S-HPWR-EI-A 1, provided S5570S-54S-PWR-EI-A AC power cord 1, provided for the switch with a built-in power supply All models The appearance and 1, provided with parameters for AC power cords removable...
- Page 16 Code Description Quantity Applicable device models 1, provided with PSR180-56A, S5570S-28S-HPWR-EI PSR360-56A, Releasable cable tie S5570S-54S-PWR-EI PSR720-56A, PSR1110-56A, S5570S-28S-HPWR-EI-A PSR600-54A-B, S5570S-54S-PWR-EI-A PSR920-54A-B, S5570S-30MS-UPWR-EI PSR1600-54A-B power supplies...
-
Page 17: Installing The Switch
CAUTION: Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any consequence. Figure 1 Hardware installation flow... -
Page 18: Installing The Switch In A 19-Inch Rack
Installing the switch in a 19-inch rack Installation methods Table 9 Installation methods Applicable Installation Requirements and Installation procedure switch models method guidelines S5170-28S-EI S5170-54S-EI S5170-54S-EI-DP S5170-28S-HPW R-EI Select an installation position for S5170-54S-PWR- the front mounting brackets as required: near the power supply S5170-36F-EI side or port side. -
Page 19: Installation Procedure At A Glance
Rack-mounting the switch by using front mounting brackets The installation procedures are the same for the S5170-EI series and S5570S-EI series except for the S5570S-28S-HPWR-EI, S5570S-54S-PWR-EI, and S5570S-30MS-UPWR-EI. The following uses the S5570S-54F-EI as an example. - Page 20 Figure 4 Attaching the front mounting brackets to the port-side mounting position Figure 5 Attaching the front mounting brackets to the power supply-side mounting position Mounting the switch in the rack This task requires two people. To mount the switch in the rack: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.
- Page 21 Figure 6 Mounting the switch in the rack (port-side mounting position for the front mounting brackets) Figure 7 Mounting the switch in the rack (power supply-side mounting position for the front mounting brackets)
-
Page 22: Rack-Mounting The Switch By Using Front And Rear Mounting Brackets
Rack-mounting the switch by using front and rear mounting brackets The installation procedures are the same for the S5570S-28S-HPWR-EI, S5570S-54S-PWR-EI, and 5570S-30MS-UPWR-EI. The following uses the S5570-28S-HPWR-EI as an example. Attaching the front mounting brackets and shoulder screws to the switch The switch provides two installation positions on its side for the front mounting brackets. - Page 23 Figure 9 Attaching the rear mounting brackets to the rack with the wide flange inside the rack Figure 10 Attaching the rear mounting brackets to the rack with the wide flange outside the rack Mounting the switch in the rack Wear an ESD wrist strap.
- Page 24 Make sure the front mounting brackets and shoulder screws are securely attached to the two sides of the switch. Attach cage nuts to the front rack posts. Make sure the corresponding cage nuts on the left and right front rack posts are at the same height. One person supports the chassis bottom with one hand, holds the front part of the chassis with the other, and pushes the chassis into the rack gently.
-
Page 25: Mounting The Switch On A Workbench
• Correctly connecting the grounding cable is crucial to lightning protection and ESD and EMI protection. You must connect the grounding cable correctly and reliably for the switch. • For information about lightning protection for the switch, see H3C Network Devices Lightning Protection Guide. -
Page 26: Grounding The Switch By Using A Grounding Strip
chassis ground to the earth to minimize the potential for system damage, maximize the safety at the site, and minimize EMI susceptibility of the system. Select a grounding method based on the installation environment. NOTE: The power and grounding terminals in this section are for illustration only. Grounding the switch by using a grounding strip CAUTION: •... -
Page 27: Grounding The Switch By Using A Grounding Conductor Buried In The Earth Ground
Attach the bended part of the grounding cable to the grounding post and use the hex nut to fasten the bended part to the post. Figure 14 Connecting the grounding cable to a grounding strip (1) Grounding post (2) Grounding strip (3) Grounding cable (4) Hex nut Grounding the switch by using a grounding conductor buried... -
Page 28: Installing And Removing A Power Supply
PWR1 empty and power supply slot PWR2 installed with a filler panel. S5570S-28S-EI (LS-5570S-28S-EI-GL), S5570S-54S-EI (LS-5570S-54S-EI-GL), S5570S-36F-EI-GL (LS-5570S-36F-EI-GL), S5570S-54F-EI (LS-5570S-54F-EI-GL), S5570S-28S-HPWR-EI-A (LS-5570S-28S-HPWR-EI-A-GL), S5570S-54S-PWR-EI-A (LS-5570S-54S-PWR-EI-A-GL) switches support shipment with power supplies installed. If you hope that the switch is shipped with the purchased power supplies installed, contact the H3C sales personnel. -
Page 29: Installing/Removing A Power Supply (1)
WARNING! • To avoid bodily injury or switch damage, strictly follow the procedures in Figure 16 Figure 17 to install and remove a power supply. • You must provide a circuit breaker for each power supply. Figure 16 Installation procedure Turn on the circuit 安装电源模块... - Page 30 Figure 18 Removing the filler panel Unpack the power supply and verify that the power supply model is correct. Correctly orient the power supply with the power supply slot (use the letters on the power supply faceplate for orientation), grasp the handle of the power supply with one hand and support its bottom with the other, and slide the power supply slowly along the guide rails into the slot (see callout 1 in Figure...
-
Page 31: Installing/Removing A Power Supply (2)
Put away the removed power supply in an antistatic bag or the power supply package bag for future use. Figure 20 Removing a power supply Installing/removing a power supply (2) This section applies to the PSR180-56A, PSR360-56A, PSR560-56D, PSR720-56A, PSR1110-56A, PSR600-54A-B, PSR920-54A-B, and PSR1600-54A-B power supplies, which use a similar installation/removal procedure. - Page 32 Keep the packaging box and packaging bag for the power supply secure for future use. Correctly orient the power supply. Make sure the lettering on the power supply is upward. Align the power supply with the power supply slot. Grasping the handle of the power supply with one hand and supporting its bottom with the other, slide the power supply slowly into the slot along the guide rails until the latch of the power supply clicks into the slot.
-
Page 33: Connecting The Power Cord
Keep the removed power supply in an antistatic bag or the power supply package bag for future use. Install the filler panel to prevent dust and ensure good ventilation if no power supply is installed in the slot. Figure 24 Removing the power supply Connecting the power cord CAUTION: •... -
Page 34: Connecting The Power Cord For A Built-In Power Supply
Power supply Available power source Connection procedure reference model PSR600-54A-B/PSR AC power source 920-54A-B/PSR1600 240 V HVDC power source -54A-B Connecting the power cord for a built-in power supply Wear an ESD wrist strap. Make sure the strap makes good skin contact and is reliably grounded. -
Page 35: Connecting The Power Cord For A Ca-70A12 Or Psr75-12A Power Supply
Connecting the power cord for a CA-70A12 or PSR75-12A power supply The power cord connection procedure is similar for the CA-70A12 and PSR75-12A power supplies. The following procedure connects the power cord for a PSR75-12A power supply. To connect the power cord for a PSR75-12A power supply: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. -
Page 36: Connecting The Power Cord For A Psr150-D1 Or Psr560-56D Power Supply
• To use a –48 VDC power source to supply power to the power supply, use the DC power cord supplied with the power supply. • To use an H3C RPS (–54 VDC) to supply power to the power supply, use a compatible RPS power cord to connect the RPS to the power supply. -
Page 37: Psr600-54A-B, Psr920-54A-B, Or Psr1600-54A-B Power Supply
• If a power line is routed from outdoors, verify that a surge protected power strip is used for the switch. NOTE: For information about lightning protection for the switch, see H3C Lightning Protection Guide. -
Page 39: Accessing The Switch For The First Time
Accessing the switch for the first time Connecting the switch to a configuration terminal The S5170-EI series and S5570S-EI series switches each provide a serial console for connecting to a configuration terminal. Figure 31, the switch is connected to a configuration terminal (PC as an example) from the serial console port. -
Page 40: Connecting A Usb-To-Rj45 Console Cable
A DB9-to-RJ45 console cable is an 8-core shielded cable, with a crimped RJ-45 connector at one end for connecting to the serial console port of the switch, and a DB-9 female connector at the other end for connecting to the serial port on the console terminal. Figure 32 DB9-to-RJ45 console cable Table 13 DB9-to-RJ45 console cable signal pinout RJ-45... - Page 41 Click the following link, or copy it to the address bar on your browser and download the USB-to-RJ45 console driver. http://www.h3c.com/en/home/USB_to_RJ45_Console/ View the TXT file Read me in the Windows folder to check whether the Windows system of the configuration terminal supports the driver.
-
Page 42: Setting Terminal Parameters
Figure 34 Finishing the driver installation Connect the standard USB connector of the cable to the USB port of the configuration terminal. Connect the RJ-45 connector of the cable to the console port of the switch. Setting terminal parameters To configure and manage the switch through the console port, you must run a terminal emulator program, such as TeraTermPro, on your configuration terminal. -
Page 43: Powering On The Switch
• The console cable is correctly connected. • The PC has started, and the terminal parameters have been correctly configured. Powering on the switch During the startup process, you can access Boot ROM menus to perform tasks such as software upgrade and file management. -
Page 44: Setting Up An Irf Fabric
Setting up an IRF fabric You can use H3C IRF technology to connect and virtualize S5170-EI or S5570S-EI switches into a large virtual switch called an "IRF fabric" for flattened network topology, and high availability, scalability, and manageability. An S5170-EI or S5570S-EI switch can set up an IRF fabric only with switches from the same switch series. -
Page 45: Planning Irf Fabric Setup
Step Description • Planning the cabling scheme "Installing the switch in a 19-inch rack" or "Mounting the switch Install IRF member switches on a workbench." Connect grounding cables and "Grounding the switch" and "Connecting the power cord." power cords Power on the switches Configure basic IRF settings See the IRF configuration guide for the switch series. -
Page 46: Planning Irf Topology And Connections
Planning IRF topology and connections You can create an IRF fabric in daisy chain topology or more reliable ring topology. In ring topology, the failure of one IRF link does not cause the IRF fabric to split as in daisy chain topology. Instead, the IRF fabric changes to a daisy chain topology without interrupting network services. -
Page 47: Identifying Physical Irf Ports On The Member Switches
SFP port—GE SFP fiber transceiver module and optical fiber, GE SFP copper transceiver module and twisted pair cable or GE SFP cable. For the available transceiver models and cables, see ports in H3C S5170-EI & S5570S-EI Switch Series Hardware Information and Specifications. - Page 48 • SFP+ port—SFP+ fiber transceiver module and optical fiber or SFP+ cable. For the available transceiver models and cables, see ports in H3C S5170-EI & S5570S-EI Switch Series Hardware Information and Specifications. For a short-distance IRF connection in an equipment room, use a twisted pair/SFP+/SFP cable.
-
Page 49: Configuring Basic Irf Settings
Connect the IRF member switches as planned. Wear an ESD wrist strap when you connect cables or transceiver modules and fibers. For how to connect them, see H3C Transceiver Modules and Network Cables Installation Guide. Verifying the IRF fabric setup... - Page 50 Table 15 Displaying and maintaining IRF configuration and running status Task Command display irf Display information about the IRF fabric. Display all members’ IRF configurations that take display irf configuration effect at a reboot. display irf topology Display IRF fabric topology information. NOTE: To avoid IP address collision and network problems, configure a minimum of one multi-active detection (MAD) mechanism to detect the presence of multiple identical IRF fabrics and handle...
-
Page 51: Maintenance And Troubleshooting
LEDs (PWR1 and PWR2) on the switch in combination with the status LEDs on the power supplies to identify power supply failure. For more information, see H3C S5170-EI & S5570S-EI Switch Series Hardware Information and Specifications, H3C PSR180-56A Power Module User Manual, H3C PSR180-56A Power Module... - Page 52 Symptom The system status LED on the switch indicates a fan tray failure. Solution When a fan tray issue occurs, contact H3C Support. Configuration terminal display issues If the configuration environment setup is correct, the configuration terminal displays booting information when the switch is powered on. If the setup is incorrect, the configuration terminal displays nothing or garbled text.
- Page 53 Data bits—8. Stop bits—1. Parity—None. Flow control—None. If the issue persists, contact H3C Support.
