SMART-AVI RKT8-HDX100 Quick Start Manual

TECHNICAL SPECIFICATION

VIDEO
Format HDMI
Maximum Pixel Clock 165MHz
Inputs (8) HDMI
Local Outputs (8) HDMI
Remote Outputs (8) RJ-45
Up to 1920 x 1200 @60Hz or
Resolution
480p/720i/720p/1080i/1080p
DDC 5 volts p-p(TTL)
Input Equalization Automatic
Cable Length Up to 20 ft
OTHER
Power Internal 110-240 VAC
Dimensions 17" W x 1.6" H x 3.25" D
Weight 5 lbs
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
WHAT'S IN THE BOX
PART NO. Q-TY DESCRIPTION
8-port HDMI Rack
RKT8-HDX100 1
Mountable Transmitter
Power Cord 1 CCPWR06
Quick Start Guide 1
