  • Page 1 A-626 / 628 User’s Manual Warranty All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser. Warning ICP DAS assume no liability for damages consequent to the use of this product.

  • Page 2: Table Of Contents

    CONTENTS 1. INTRODUCTION 1.1. F EATURES 1.2. A PPLICATIONS 1.3. S PECIFICATIONS 2. INSTALL A-626 / A-628 2.1. P RODUCT HECK 2.2. J DIP S UMPER AND WITCH ETTING 2.3. A-628’ AYOUT A-626’ AYOUT 2.4. I/O A DDRESS ETTING 2.4.1. A-626 A...
  • Page 3 5. TERMINAL BOARD 5.1. DB-16P I SOLATED NPUT OARD 5.2. DB-16R R ELAY OARD 5.3. DB-24PR P OWER ELAY OARD 5.4. DB-8125 S CREW ERMINAL OARD 5.5. DN-37 (D-S I/O C DIN R ONNECTOR LOCK OUNTING A-626 / A-628 User’s Manual...

  • Page 4: Introduction

    1.Introduction The A-626 / A-628 Provides 6 / 8 Channel analog outputs, 16 channel digital outputs and 16 channel inputs . Each analog output channel can be user configurable , range of Voltage output :0-5V,0-10V,±5,±10V or Current loop :4-20mA .

  • Page 5: Specifications

    0~50°C ! Power Consumption +5V (A-626/A-628) : 450 / 600mA (Typical), 900/1200mA (Max) +12V (A-626/A-628) : 50 / 60mA (Typical), 110 / 120mA (Max) -12V (A-626/A-628) : 14 / 16mA (Typical), 90 / 130mA (Max) A-626 / A-628 User’s Manual...

  • Page 6: Install A-626 / A-628

    2.2. Jumper and DIP Switch Setting When you use the A-626 / A-628 , You should set the I/O address and voltage range first . you can configure output voltage of each channel and I/O address by jumper and switch.

  • Page 7: A-628'S Layout

    Ext. VR3-2 VR3-1 Ext. VR2-2 VR2-1 Ext. VR1-2 VR1-1 Ext. D-In D - Out Note: UN :Unipolar JPn : Jumper Number Ext. :External S : Dip Switch Bi :Bipolar VR :Veritable Resister CN : Connector A-626 / A-628 User’s Manual...

  • Page 8: A-626'S Layout

    BI/UN VR4-2 JP13 VR4-1 JP18 BI/UN VR3-2 JP12 VR3-1 JP11 BI/UN VR2-2 JP10 VR2-1 VR1-2 VR1-1 D-Out D-In Note : Unipolar Bipolar Internal Reference Voltage -5V -10V Internal Reference Voltage -10V External Reference Voltage Input A-626 / A-628 User’s Manual...

  • Page 9: I/O Address Setting

    2.4. I/O Address Setting 2.4.1. A-626 Address Setting The A-626 requires consecutive locations in I/O address space. The base address is set by DIP switch S1 .The default address is 2C0 Hex . A7 A6 A5 A4 S1 : Base Address...

  • Page 10: A-628 Address Setting

    238-23F Bus Mouse 3A0-3AF SDLC 278-27F Parallel Port 3B0-3BF MDA/Parallel Port 2B0-2DF 3C0-3CF 2E0-2E7 AT GPIB 3D0-3DF 2E8-2EF Serial Port 3E0-3EF Serial Port 2F8-2EF Serial Port 3F0-3F7 Floppy Disk 300-31F Prototype Card 3F8-3FF Serial Port A-626 / A-628 User’s Manual...

  • Page 11: Jumper Setting 2.5.1. A-626 Jumper Setting

    2.5. Jumper Setting 2.5.1. A-626 Jumper Setting The A-626 each D/A channel can be configurable. You can setting the voltage range for your applications. The A-626 provides -5V or -10V internal reference voltage and unipolar or bipolar voltage output . Each channel is individually jumper selectable to any ranges.

  • Page 12: A-628 Jumper Setting

    Jumper Number : JP9 , JP10 , JP11 , JP12 , JP13 , JP14 , JP15 , JP16 Unipolar Mode Bipolar Mode Jumper Number :JP17 , JP18 , JP19 , JP20 , JP21 , JP22 , JP23 , JP24 A-626 / A-628 User’s Manual...

  • Page 13: Reference

    JP 12 & JP20 Channel 4 JP 5 JP 13 & JP21 Channel 5 JP 6 JP 14 & JP22 Channel 6 JP 7 JP 15 & JP23 Channel 7 JP 8 JP 16 & JP24 A-626 / A-628 User’s Manual...

  • Page 14: Pin Assignment

    2.6. Pin Assignment A-626 P1: 37-Pin Connector for Voltage Output & Current Loop CH0 V.Out CH4 V.Out CH0 Ext Ref In CH4 Ext Ref. In CH0 I .Out CH4 I.Out A. GND A.GND CH1 V.Out CH5 V.Out CH1 Ext Ref In CH5 Ext Ref.
  • Page 15 ! CH n Ext Ref In D/A External Reference Input Channel n ! CH n I. Out Current Loop Output Channel n ! A. GND Analog Ground ! D.GND Digital Ground ! PC’s +5V From PC Power Supply +5V A-626 / A-628 User’s Manual...
  • Page 16 DO 14 DO 15 +12V The A-626 / A-628 has 16 channel digital output /Input , all of the digital channels are TTL compatible. The DB-16R ( 16 Channel Relay Actuator Board) or DB-24PR (24 Channel Power Relay Actuator Board) and DB-16P (16Channel Isolation Input Board) are designed...

  • Page 17: Signal Connection

    2.7.1. Voltage Output A-626 Output Current Max (±5mA) Convertor Load DATA 12-Bit A.GND The A-626 / A-628 D/A Voltage Output Maximum Current :± 5 mA 2.7.2. Current Loop Current Loop 4~20mA A-626 I. Out LOAD D/A 0-5V External Power Supply 9V-36V The A-626/ A-628 422Ω...

  • Page 18: Programming

    3. Programming 3.1. I/O Register 3.1.1. A-626 I/O Port Address Address Function Read/Write Base + 0x0 D/A CH0 High Byte Write Base + 0x1 D/A CH0 Low Byte Write Base + 0x2 D/A CH1 High Byte Write Base + 0x3...

  • Page 19: A-628 I/O Port Address

    Base + 0x4 Base + 0x5 Base + 0x6 Base + 0x7 Base + 0x8 Base + 0x9 Base + 0xA Base + 0xB Base + 0xC Base + 0xD Base + 0xE Base + 0xF A-626 / A-628 User’s Manual...

  • Page 20: Data Register

    ‘Unipolar 0-5V D/A Channel 0 will output 2.5 V High Byte Data Low Byte Data D7 D6 D5 D4 D3 D2 D1 D0 D7 D6 D5 D4 D3 D2 D1 D0 0x000 0x800 0xFFF 12 Bit Data A-626 / A-628 User’s Manual...
  • Page 21 2048 (Current Loop) 0000 0000 0000 (0~5V) 2.5V (0~10V) (±5V) -10V (±10V) +10V (4~20mA) 12mA 20mA 0 (0x000) 2048 (0x800) 4095 (0xFFF) 0000 0000 0000 1000 0000 0000 1111 1111 1111 12 bit Data Format A-626 / A-628 User’s Manual...
  • Page 22 Output Range = 4~20mA Current Sink = ((20-4 ) X 3076/4095 )+ 4=16.0185(mA) Example Program : ( Quick Basic) BasAddress=&H2C0 ‘ A-626 / A-628 Base Address RefVol=5 ‘ Reference Voltage = -5V ( Unipolar 0 - 5 V ) Vo = 3.5 ‘...

  • Page 23: Digital Input / Output

    3.3. Digital Input / Output Register A-626 Digital Input / Output Register Address Write Read Base + 0x0C Digital Output Channel 0~7 Digital Input Channel 0~7 Base + 0x0D Digital Output Channel 8~15 Digital Input Channel 8~15 Digital Input / Output Data Format...

  • Page 24: Calibration

    4. Calibration The each channel of A-626 /A-628 has three VR can be adjust to current value. A-626 VR’s Table D/A Channel Unipolar Full Scale Bipolar Off-set Current loop 4mA VR1-2 VR1-1 VR1-3 VR2-2 VR2-1 VR2-3 VR3-2 VR3-1 VR3-3 VR4-2...
  • Page 25 2. Ref. Sec. 2.7 signal connection connect DAM to current loop channel 3. Write 0x000 (Hex) to D/A Channel 0 4. Trim VR1-3 until the DAM reading 4.0000mA 5. Write 0xFFF (Hex) to D/A Channel 0 6. Trim VR1-2 until the DAM reading 20mA A-626 / A-628 User’s Manual...
  • Page 26 A-626/ A-628 Digital Input Opto-Isolated A-626 / A-628 20Pin cable DB-16P AC or DC Signal 0V to 24V A-626 / A-628 User’s Manual...
  • Page 27 From C Relay Normal Open Normal Close Com. 20Pin cable DB-16R A-626 / A-628 Note: Channel : 16 From C Relay Relay : Switching up to 0.5A at 110ACV / 1A at 24DCV A-626 / A-628 User’s Manual...
  • Page 28 20-Pin connector For 16 Channel digital output , A-82X ,A-62X , DIO-64 Channel : 16 From A Relay , 8 From C Relay Relay : Switching up to 5A at 110ACV / 5A at 30DCV A-626 / A-628 User’s Manual...
  • Page 29 The DB-8125 is low cost universal screw terminal board . for 37-pin D-type connector or two 20-pin connector. A-626 / A-628 37-pin cable Industrial type terminal blocks permit heavy-duty and reliable connection of signals. DB-8125 A-626 / A-628 User’s Manual...
  • Page 30 Termination accessory with 37 screw terminals for easy connection of field I/O signals to 37-pin boards. Includes one 37-pin D-sub connector for direct connection to 37-pin cables with hardware for mounting on a standard DIN rail. A-626 / A-628 37-pin cable DN-37 Wire Wire A-626 / A-628 User’s Manual...
