1
What's on your package?
One A-8111 series card
One companion ISA CD (V2.1 or later)
One Quick Start Guide(This document)
......................................................
2
Installing Windows Driver
Follow those steps:
1. Setup the Windows driver.
You can get the driver from:
CD:\NAPDOS\ISA\A8111\DLL_OCX\Driver\
http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/a8111/dll_ocx/driver/
Windows driver only support windows 98/NT/2000 and
XP/2003 versions.
Language
Version
Update
- 1 -
A-8111
English
V1.0
Oct.2008
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ICP DAS USA A-8111 Series
Summary of Contents for ICP DAS USA A-8111 Series
- Page 1 Language Version V1.0 Oct.2008 Update ……………………………………………… What’s on your package? One A-8111 series card One companion ISA CD (V2.1 or later) One Quick Start Guide(This document) ……………………………………………… Installing Windows Driver Follow those steps: 1. Setup the Windows driver. You can get the driver from: CD:\NAPDOS\ISA\A8111\DLL_OCX\Driver\ http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/a8111/dll_ocx/driver/...
- Page 2 2. Click button to start installation. 3. Click button to install driver into the default folder. 4. Click button to continue installation. 5. Select “NO, I will restart my computer later” and then click button. ……………………………………………… I/O Base Address Setting The base address is set from SW1 DIP switch on board: SW1 : BASE ADDRESS...
-
Page 3: Adding Hardware
……………………………………………… Installing Hardware on PC Follow those steps: 1. Shut down and power off your computer 2. Remove all covers from the computer 3. Select an empty ISA slot 4. Carefully insert your I/O card into the ISA slot 5. Replace the PC covers 6. - Page 4 7-4 Select the item “Add a new device” and click the “Next >” button. 7-5 Select the item “No, I want to select the hardware from a list” and click the “Next >” button. 7-6 Select the item “Other device” and click the “Next >” button. 7-7 Click the “Have Disk…”...
- Page 5 ……………………………………………… Pin Assignments CN1: Analog input/Analog output connector. Description Description A/D Analog Input Channel 0 Analog GND A/D Analog Input Channel 1 Analog GND A/D Analog Input Channel 2 Analog GND A/D Analog Input Channel 3 Analog GND A/D Analog Input Channel 4 Analog GND A/D Analog Input Channel 5 Analog GND...
- Page 6 ……………………………………………… Self-Test 1. Use CA-2002(Optional) to connect the CN2 with CN3. 2. Run the A-8111 sample program. Get the file from: C:\NAPDOS\ISA\A8111\DLL_OCX\DEMO\ http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/a8111/dll_ocx/d emo/ - 6 -...
- Page 7 3. Check number of the A-8111 and test DIO function. Click this I/O Base value (Depend on I/O Base Address) 2. Click this button to do DIO test. 4. Get DIO function test result. 3. Click the channel 0 、2、4、6 in the DO. 4.
- Page 8 ……………………………………………… Additional Information A-8111 Series Card Product page: http://www.icpdas.com/products/DAQ/pc_based/a-8111.htm CA-2002(Optional) page: http://www.icpdas.com/products/Accessories/cable/cable_selection.htm Documents: CD:\NAPDOS\ISA\A8111\manual http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/a8111/manual/ Software: CD:\NAPDOS\ISA\A8111 http://www.icpdas.com/download/isa/a8111/index.htm The ICP DAS Web Site http://www.icpdas.com Technical support Supplies and ordering information Ways to enhance your device Application story Contact Us Service@icpdas.com Copyright ©2008 by ICP DAS Co., Ltd.
