  • Page 1 I n s t a l l a t i o n & O p e r a t i n g I n s t r u c t i o n s...

  • Page 2: General Information

    1. General Information These instructions should be read carefully in full before installation, and retained for further reference and maintenance. 2. Safety • Before installation or maintenance, ensure the mains supply to the smart switch is switched off and the circuit supply fuses are removed or the circuit breaker turned off.

  • Page 3: Technical Specifications

    3. Technical Specifications • 230V AC 50 Hz • This unit is of class II construction • Switching capacity: • Manual ON/OFF Controls • Fixing Hole Centres: 81.5mm • Operating temperature: -20°C to +40°C • Operating Humidity: ≤80%RH • WLAN-Standard: 802.11 b/g/n •...

  • Page 4: System Requirements

    4. System Requirements • Smartphone/Tablet with at least iOS 8.0 or Android 5.0 • WLAN-enabled router: 2.4GHz (Separate Band) • Tuya Smart App 5. Installation 5.1. Ensure the mains supply is switched off and the circuit supply fuses are removed or the circuit breaker turned off.
  • Page 5 5.3 If the unit is to permanently fixed to a wall/joist or ceiling:- a) Using the unit as a template mark the position of the fixing holes. b) Drill the holes for the rawl plugs ensuring not to infringe with any gas/water pipes or electrical cables that may be hidden below the surface.
  • Page 6 5.6 Fit the supplied cable retaining clamps, ensuring the cables are secure. 5.7 Refit the terminal covers and secure using the terminal cover screws. Make sure not to over tighten. 5.8 Turn the mains supply back on.

  • Page 7: Connection Diagram

    6. Connection Diagram • Connect the 230V AC 50Hz mains supply and load cables as per the diagram below L Input L Output INPUT OUTPUT N Input N Output Live Supply (Brown or red) L Input: Neutral Supply (Blue or Black) N Input: L Output: Switch Live Load (Brown or Red) N Output: Neutral Load (Blue or Black)
  • Page 8 7. Downloading App and Registration Note: the smartphone or tablet must be connected to a 2.4GHz band on the router. Paring on the 5GHz band will result in paring either timing out or being unsuccessful. Refer to your ISP (Internet Service Provider) on separating the bands if required.
  • Page 10 • Install the App and open it to the registration screen. Click on the ‘Register’ button.
  • Page 11 • Tap ‘Agree’ to accept the privacy policy.
  • Page 12 • Choose your region by selecting the Country Code. Enter your email address or phone number and click ‘Get Verification Code’ .
  • Page 13 • Enter the Verification Code sent to the email address or phone number that you provided. Once you have successfully entered the code, it will automatically move you to the Password screen.
  • Page 14 • Assign a Password (this must be between 6 to 20 characters including letters and digits) and click ‘Done’ .
  • Page 15 • You are now registered and by default will see the App home page.

  • Page 16: Home Management

    8. Home Management Note: Before adding any devices to your account, structuring your household (or the property) may be a consideration if you plan on using Smart devices in different rooms or locations. • Select the ‘Me’ option from the home page which will navigate you to your personal settings.
  • Page 19 • Select the ‘Home Name’ option and enter your last name or even ‘My Home’ if preferred. (This is required to allocate devices to separate rooms later once paired). • Next tick the rooms you wish to assign to your account; this can be changed at any time and custom room names can also be added.
  • Page 20 • To navigate back to the home screen, press the ‘Back’ button, and then click Home.

  • Page 21: Pairing Your Device(S)

    9. Pairing your Device(s) • To add a new device to your account, click the ‘Add Device’ button (or click on the + button in the top right hand corner)
  • Page 22 • Notice the different categories of products; it is essential that the correct product is selected for the pairing process to be successful. For the Wi-Fi Smart Switch, choose the ‘Breaker (Wi-Fi)’ option from the list.
  • Page 23 • The add device menu will be displayed. To add the device on your account, press and hold the ‘On/Off/Pair button’ , until the Wi-Fi light (Status LED) begins to flash.
  • Page 24 • When the Status LED is flashing press the ‘Confirm indicator rapidly blinking’ button. Enter the password for the network and press the ‘Confirm’ button to pair the product to your account (In most cases the password should autofill).
  • Page 26 • The App will pair the smart product to the network. The time it takes for pairing to complete, which will differ depending on the network connection. Shortly into the pairing process, the flashing Status LED will turn OFF. This indicates that the product has joined the network.
  • Page 27 • If the following screen is displayed, then the product has been paired successfully. To rename your product, select the pencil icon. If this is not required, click on the ‘Done’ button and you will guided to the device controls menu.
  • Page 29 • To navigate back to the home screen, press the ‘Back’ button. The newly paired Wi-Fi Smart Switch will now be listed. Note: If the pairing process was not successful, disconnect the mains supply from the product and re-establish power to the unit. Follow the bullet points from ’Section 9‘...
  • Page 30 10. Smart Home Assistant • To add your device to your Smart Home Assistant services, such as Google Home or Amazon Alexa, follow the on-board instructions located on the TuyaSmart App. To do this, select the ‘Me’ option from the home menu, and then select ‘More Services’...
  • Page 31 • On the more services screen, you will see support or different applications for automated Smart Home control. Follow the instructions on the TuyaSmart App to add the devices to your Smart Home Assistant service.
  • Page 32 Note: The Smart Home Assistant services supported by the TuyaSmart App may change as it is a 3rd party App Service. Any services that may be removed are the responsibility of TuyaSmart developers and not Timeguard.
  • Page 33 11. Support Note: If you have any concerns that the intended application of this product does not meet your requirements, please contact Timeguard directly prior to installation.

  • Page 34: Year Guarantee

    12. Guarantee & Company Details 3 Year Guarantee In the unlikely event of this product becoming faulty due to defective material or manufacture, within 3 years of the date of purchase, please return it to your supplier in the first year with proof of purchase and it will be replaced free of charge.
  • Page 35 If you experience problems, do not immediately return the unit to the store. Telephone the Timeguard Customer Helpline: HELPLINE 020 8450 0515 or email helpline @ timeguard.com Qualified Customer Support Coordinators will be online to assist in resolving your query. For a product brochure please contact: Timeguard Limited.
