AH-XP10 * B AU-X10 * B AH-XP13 * B AU-X13 * B AH-XP18 * B AU-X18 * B AH-XP24 * B AU-X24 * B “Plasmacluster" and "Device of a cluster of grapes" are registered trademarks or trademarks of Sharp Corporation.
ENGLISH Please read this manual carefully before using the product. This manual should be kept in a safe place for handy reference. CONTENTS • SAFETY INSTRUCTIONS ......................EN-1 • PART NAMES ..........................EN-3 • USING THE REMOTE CONTROL ....................EN-5 • AUXILIARY MODE ........................EN-5 • BASIC OPERATION ........................EN-6 • ADJUSTING THE AIR FLOW DIRECTION ................. EN-7 • POWERFUL JET / SUPER JET OPERATION ................EN-8 • PLASMACLUSTER OPERATION ....................EN-8 • BABY MODE OPERATION ......................EN-9 • ECO MODE OPERATION ......................EN-9 • BEST SLEEP OPERATION ......................
• Do not attempt to install/remove/repair a person responsible for their safety. the unit by yourself. Incorrect work Children should be supervised to will cause electric shock, water leak, ensure that they do not play with the fire etc. Consult your dealer or other appliance. qualified service personnel for the • Make sure to connect the air installation/removal/repair of the unit. conditioner to power supply of the rated voltage and frequency. Use of CAUTION a power supply with improper voltage • Open a window or door periodically and frequency can result in equipment to ventilate the room, especially when damage and possible fire. using gas appliances. Insufficient • Do not install the unit in a place ventilation may cause oxygen where inflammable gas may leak. It shortage. may cause fire. • Do not operate the buttons with wet Install the unit in a place with minimal hand. It may cause electric shock. dust, fumes and moisture in the air.
PART NAMES INDOOR UNIT Indoor unit apperance may be different from the image above. ※ 1 Inlet (Air) 2 Open Panel 3 Air Filter 4 AUX Button 5 Receiver Window 6 Vertical Airflow Louver 7 Horizontal Airflow Louver 8 Outlet (Air) 9 OPERATION Lamp (green 10 TIMER Lamp (orange ) 11 PLASMACLUSTER Lamp (blue EN-3 EN-3...
REMOTE CONTROL 1 TRANSMITTER 2 DISPLAY 3 POWERFUL JET / SUPERJET Button 4 ON/OFF Button 5 PLASMACLUSTER Button 6 BABY MODE Button 7 FAN Button 8 THERMOSTAT Button 9 MODE Button 10 SWING Button : Vertical direction) 11 ECO Button 12 TIMER ON Button 13 BEST SLEEP Button 14 TIMER OFF Button 15 RESET Button 16 TIMER CANCEL Button 17 SELF CLEAN Button 18 DISPLAY Button 19 POWERFUL JET / SUPER JET Symbol DISPLAY 20 MODE Symbols FAN / AUTO / COOL / DRY...
USING THE REMOTE CONTROL AUXILIARY MODE LOADING BATTERIES Use this mode when the remote control is not available. Remove the battery cover. TO TURN ON Insert two batteries. (AAA(R03)) Press the AUX button. Make sure the (+) and (-) polarities are correctly aligned. • The green OPERATION lamp ( ) will light up and the unit will start operating in the AUTO Reinstall the battery cover.
BASIC OPERATION Press the MODE button to select the op- eration mode. FAN AUTO COOL DRY Press the ON/OFF button to start opera- tion. • The green OPERATION lamp ( ) will light up. TO TURN OFF Press the ON/OFF button again. • The green OPERATION lamp ( ) will turn off. Press the THERMOSTAT button to set the desired temperature, you can set temper- ature in 0.5 C increments.
ADJUSTING THE AIR FLOW DIRECTION VERTICAL AIR FLOW DIRECTION HORIZONTAL AIR FLOW DIRECTION Press the SWING button ( ) to set Hold the horizontal airflow louver lever the desired airflow direction. and adjust the airflow direction. In AUTO mode, airflow direction cannot be set to “ ”.
POWERFUL JET / SUPER JET OPERATION PLASMACLUSTER OPERATION The air conditioner works at the maximum Plasmacluster ions released into the room power and optimum louver direction to will reduce some airborne mold. make the room cool rapidly. During operation, press the PLAS- MACLUSTER button.
ECO MODE OPERATION BABY MODE OPERATION The air conditioner will operate with Soft , quiet and clean operation cools a lower power consumption than usual in room with well optimized for infants. this mode. During operation, press the BABY During operation, press the ECO MODE button.
BEST SLEEP OPERATION For more comfortable sleep, temperature and fan speed will be controlled automatic- ally by the best program. During operation, press the BEST SLEEP button. • The remote control will display “ ”. • Temperature and fan speed will be con- trolled automatically for the best sleep. TO CANCEL Press the BEST SLEEP button again. NOTE: • BEST SLEEP operation is not available in DRY and FAN mode. EN-10 EN-10...
TIMER OPERATION TIMER ON TIMER OFF Press the TIMER ON button and set Press the TIMER OFF button and set the time as desired. the time as desired. • The orange TIMER lamp ( ) will light up. • The orange TIMER lamp ( ) will light up. • The timer setting will count down to show • The timer setting will count down to show the remaining time. the remaining time.
SELF CLEAN OPERATION DISPLAY BUTTON SELF CLEAN operation will reduce (For Kind C models only) the growth of mold fungus with During operation, press the DISPLAY Plasmacluster ions and dry inside of the button. unit. Utilize the operation at seasonal • The blue PLASMACLUSTER lamp ( )will change over terms or every 4 months.
MAINTENANCE Be sure to disconnect the power cord from MAINTENANCE AFTER AIR CONDI- the wall outlet or turn off the circuit breaker TIONER SEASON before performing any maintenance. Dry the inside of the indoor unit thor- CLEANING THE FILTERS oughly by taking the following steps. Turn off the unit.
BEFORE CALLING FOR SERVICE The following conditions do not denote Check the following points before call- equipment malfunctions. ing for service. UNIT DOES NOT OPERATE The unit does not operate The unit will not operate if it is turned on im- • Check if the circuit breaker has tripped or the mediately after it is turned off. The unit will not fuse has blown. operate immediately after the mode is changed. The unit does not cool effectively This is to protect the unit. Wait 3 minutes before operating the unit.
BEFORE CALLING FOR SERVICE ABOUT ERROR CODE Press the FAN button once, the remote control will display “ ”. • The error code contains main code and sub code. Example: error 23-4. ERROR CODE Main Sub Code Code GET THE ERROR CODE Press the THERMOSTAT button “ ” Example: error 23-4.
