300 Tall Wall Unit

Assembly Instructions -

609868

Please keep for future reference

609878

Dimensions

Width - 30cm

Depth - 18cm

Height - 120cm

Important -

Please read these instructions fully before starting assembly

For all enquiries please contact : 0333 241 2701

Ref. no BTOFST006 Date: 04/2021

Need help?

Do you have a question about the 609868 and is the answer not in the manual?

Questions and answers

Summary of Contents for House Beautiful 609868

Page 1 300 Tall Wall Unit Assembly Instructions - 609868 Please keep for future reference 609878 Dimensions Width - 30cm Depth - 18cm Height - 120cm Important - Please read these instructions fully before starting assembly For all enquiries please contact : 0333 241 2701...
Page 2 Safety and care advice Getting started - Please read these intructions fully before starting assembly • Check the pack and make • Warning: sure that you have all parts. Serious or fatal crushing If not contact your local store injuries can occur from furni- who will be able to help you.
Page 3 Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more ﬁttings may be supplied than are required. Shelf pin x 12 Cover x 2 Bracket x 1 Bump x 2 15mm Screw x 4...
Page 4 Assembly Instructions Step 1 Mark the location of the unit against the wall Step 2 Mark the location of the bracket against the wall 65mm 65mm...
Page 5: Care And Maintenance
A Guide to Wall Mounting & Fixings IMPORTANT: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure. HINTS: 1) General Rule Always use a larger screw and wall plug if you are not sure.
Page 6 Assembly Instructions Step 3 Fix wall anchor into the wall Ø8 x 4 (not included) Step 4 Fix the bracket to the wall x 4 (not included)
Page 7 Assembly Instructions Step 5 Fix the unit into the bracket...
Page 8 Assembly Instructions Step 6 Bracket adjustment...
Page 9 Assembly Instructions Step 7 Fix the clip hunge Door...
Page 10 Assembly Instructions Step 8 Fix hinge mounting plate...
Page 11 Assembly Instructions Step 9 Fix the door “CLICK”...
Page 12 Assembly Instructions Step 10 A Fix push latch...
Page 13 Assembly Instructions tep 10 A Soft closing deactivation tep 10 A Push latch adjustment...
Page 14 Assembly Instructions Step 10 B Fix the handle handle not included handle not included...
Page 15 Assembly Instructions tep 10 B Soft closing setting...
Page 16 Assembly Instructions Step 11 Insert shelf pin and position the shelves...
Page 17 Assembly Instructions Step 12 Insert cover Step 13 Remove protective films...
Page 18 Assembly Instructions Step 14 Total max weight of wall anchoring 40kg Total max weight of shelves loading 2kg each...
Page 19: Cleaning Instructions
Assembly Instructions That's the Stool completed. Take care of your unit by using a damp cloth to clean it. Please remember to occasionally check that all Cams and Screws are tight. CLEANING INSTRUCTIONS This product has been manufactured using modern manufacturing methods and materials.
