CHANGING THE LAMP

1. Remove the Flashlight Head from the
Flashlight Body by holding the Head and ro-
tating the Body counterclockwise (as viewed
from the tail of the Flashlight) until it is free
of the Head.
2. Separate the Bezel from the Flashlight
Head by holding the Bezel and rotating the
Head counterclockwise until the two separate.
3. Remove the inoperative Lamp/ Reflec-
tor and replace with the new X80 Lamp/Re-
flector.
Avoid touching the inside of the Lamp/
Reflector to prevent degrading the Re-
flector Surface.
4. Install the Bezel back onto the Head/
Body.
X80 LAMP/REFLECTOR
BEZEL
Do not install a new Lamp/Reflector in the Flash-
light without first removing the Flashlight Head
from the Flashlight Body. Failure to follow the
above procedure could result in a damaging short
circuit caused by the Lamp/Reflector Spring short-
ing the Battery terminal.
FLASHLIGHT HEAD
Caution
FLASHLIGHT BODY
