With the purchase of this SUREFIRE flashlight,
you have invested in one of the world's best
"illumination tools."
We believe it to be a prime example of our
philosophy that design decisions should always
be made in the interest of the product being the
very best it can be.
Frequently, this means deciding to use a
more costly process or a more expensive ma-
terial than would normally be called for. We
know that in order to produce the best, one must
do it right.
We thank you for supporting this decision
and electing to confirm our belief in "no com-
promise" in a product that, by its performance
and reliability, may some day be called upon
to save your life.
There is no other choice.
MILLENNIUM
M2 CENTURION
Lithium Powered
65/120 Lumens
John Matthews
President, SUREFIRE
TM
Advertisement
Table of Contents
Related Manuals for Surefire millenium m2 centurion
Summary of Contents for Surefire millenium m2 centurion
- Page 1 MILLENNIUM M2 CENTURION Lithium Powered 65/120 Lumens With the purchase of this SUREFIRE flashlight, you have invested in one of the world’s best “illumination tools.” We believe it to be a prime example of our philosophy that design decisions should always be made in the interest of the product being the very best it can be.
- Page 3 The rugged, weatherproof design and military grade, hard-anodized finish ensures exceptional durability and reliability even under the most severe conditions. SUREFIRE’s exclusive tail cap switch gives instant access to momentary light, constant illumination, or light lock-out. This unique lock-out feature prevents accidental activation of the light during covert operations, transport or storage.
- Page 4 M2 CENTURION There are two ways to activate the light from the M2. The Tail Cap switch of the Flashlight can be activated by rotating the Tail Cap in a clockwise direction for a constant “ON” setting or by pressing on the Push Button for temporary light.
-
Page 5: Specifications
SPECIFICATIONS Output Power P60 - 65 Lumens P61 - 120 Lumens Run Time P60 - 60 Minutes P61 - 20 Minutes Battery Type Lithium - SF123A Number Required Supplied 5.2 inches Length 5.25 ounces Weight Diameter Body - 1.0 inch Bezel - 1.47 inch Lamp Assembly Xenon P60... -
Page 6: Parts Replacement List
PARTS REPLACEMENT LIST Component Part No. Lithium Battery SF123A Belt Clip 13597-1 Bezel Assembly 13586-1 Flashlight Body 13600-1 Grip Ring 13595-1 65 lumen Lamp Assembly 120 lumen Lamp Assembly Lens 13656-31 Rear O-Ring Seal (front) 19-01-040 Rear O-Ring Seal (end) 19-01-077 Front O-Ring Seal 19-01-096 Lock Out Tail Cap Assembly... - Page 7 M2 CENTURION LENS BEZEL ASSEMBLY LAMP/REFLECTOR FRONT O-RING BELT CLIP BODY GRIP RING BATTERY (2) CONTACT SPRING REAR O-RINGS (2) TAIL CAP ASSEMBLY PUSH BUTTON...
-
Page 8: Changing The Lamp
CHANGING THE LAMP 1. Remove the Flashlight Bezel from the Flashlight Body by holding the Body and ro- tating the Head counterclockwise (as viewed from the front of the Flashlight) until it is free of the Body. 2. Remove the Lamp/ Reflector and replace with the desired Lamp/Reflector. - Page 9 1. Remove the Flashlight Tail Cap by un- screwing it until it is free of the Flashlight Body. 2. Insert the SF123A Lithium Batteries into the Flashlight Body, observing proper polar- ity. 3. Install the Flashlight Tail Cap back on to the Flashlight Body by turning it until the light comes on.
-
Page 10: Customer Service
(no COD’s please) to: SUREFIRE L.L.C. Repairs Department, RA# ___ 18300 Mt. Baldy Circle Fountain Valley, CA 92708 SUREFIRE will pay any reasonable shipping costs to return the unit to you. Protected by U.S. Patent Number(s) 5,642,932 , 6,046,572 , 6,222,138 ©... - Page 11 Tail Cap Lanyard Ring Lanyard, Black Tail Cap Lanyard Kit Spares Carrier Hurricane™ Emergency Battery Pack Light (includes 12 each SF123A) Custom Engraving: Engraving of name, logo, slogan or other icons is available to personalize your SUREFIRE product. Call Customer Service.
