1. Introduction
The Texas Instruments LM75AEB evaluation board (EB) helps designers evaluate the operation and
performance of the LM75A, an industry-standard digital temperature sensor with an integrated Sigma-Delta
analog-to-digital converter and I
accuracy of ±2°C from -25°C to 100°C and ±3°C over -55°C to 125°C.
The EVM contains one Digital Temperature Sensor (See Table 1).
TEMP SENSOR
2. Setup
This section describes the jumpers and connectors on the LM75AEB as well and how to properly connect, set
up and use the LM75AEB.
July 2012
2
C interface. The LM75A provides 9-bit digital temperature readings with an
Table 1: Device and Package Configurations
U6A1
LM75AEB User's Guide
LIST OF FIGURES
LIST OF TABLES
IC
LM75AIM
User's Guide
PACKAGE
SOP-8
LM75AEB User's Guide
July 2012
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM75AEB and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments LM75AEB

  • Page 1 Table 1: Device and Package Configurations TEMP SENSOR PACKAGE U6A1 LM75AIM SOP-8 2. Setup This section describes the jumpers and connectors on the LM75AEB as well and how to properly connect, set up and use the LM75AEB. July 2012 LM75AEB User’s Guide...
  • Page 2 Figure 2: Three Significant Bits A2  A1  A0  0  0  0  0  0  1  0  1  0  0  1  1  1  0  0  1  0  1  1  1  0  1  1  1  Table 1: I2C Address User Setting Input LM75AEB User’s Guide July 2012...
  • Page 3 “download” button and click the “Save” button to save the file to the known directory. • To open the ZIP file you just download click on the “Open” button LM75AEB User’s Guide SNIU007A July 2012...
  • Page 4 • When you see the Welcome screen as shown below, follow the instructions by clicking the “Next” button on the screen to install the software • When you finish the installation, please click “Finish” button LM75AEB User’s Guide July 2012...
  • Page 5 Setup • Before you launch the SensorEval software, connect LM75AEB device to one free USB port of your PC. The “New Hardware” screen appears and click the “Next” button. • A warning sign appears. Click “Continue Anyway” button LM75AEB User’s Guide...
  • Page 6 Setup 2.3. Operation For proper operation of the LM75AEB, JP4 should be jumpered. This will allow the LM75A’s VDD to be sourced from an on-board 3.3V regulator. Jumping JP5 and JP6 will allow configuring the I2C slave address to 4Ch.
  • Page 7 Setup • To run the SensorEval software, click the icon on the desktop. The dialog box appears to select the definition file of LM75. • A confirm screen appears. Click “OK” button. LM75AEB User’s Guide SNIU007A July 2012...
  • Page 8 Select the I2C Addr as “4c” • Select the Read Cont as “All Regs”. This will read the values continuously. • Changing the value of LM75A’s registers by clicking the white textbox on the Register Bits column LM75AEB User’s Guide July 2012...
  • Page 9 Board Layout 3. Board Layout Figure 4, Figure 5, and Figure 6 show the board layout for the LM75AEB. The EVM offers resistors, capacitors, eeprom, microcontroller and jumpers to set three least significant bits of I2C slave address to run the LM75AIM temperature sensor.
  • Page 10 Board Layout Figure 5: Top Layer Routing Figure 6: Bottom Layer Routing LM75AEB User’s Guide July 2012...
  • Page 11 Schematic 4. Schematic Figure 7: LM75AEB Schematic LM75AEB User’s Guide SNIU007A July 2012...
  • Page 12 Schematic Table 2: LM75AEB Bill of Materials COUNT REF DES DESCRIPTION SIZE PART NUMBER C5,C7,C15 Capacitor, tantalum,2.2Uf,10V 3216 Kemet T491A225K010AT C1,C2,C3,C4 Capacitor, ceramic, 10,000pF, 50V, 0805 Murata GRM216R71H103KA01D ,C6,C13,C14, 10%,X7R C16,C17,C18 ,C19,C20,C2 1,C22 Capacitor, ceramic, 100pF, 50V, 0805 TDK Corp...
