Horizon Hobby JR XP7202 Programming Manual

Programming Guide for the JR XP7202 for the Hangar 9 Ultra Stick
To start with, plug your servos into the correct channels. Below is a listing of what servo to plug
into each channel. You will need a 7-channel receiver to use the full set up that the 7202 is capable of
doing with the Ultra Stick.
Ch. 1 Throttle
Ch. 2 Right Aileron
Ch. 3 Elevator
Ch. 4 Rudder

System Set-Up Mode

To begin setting up the transmitter, press and hold the down and select keys, and turn the 7202
on, then release the down and select keys.
Press the up or down key until Model Select is on the top of the screen, and select the model you want
the ultra stick on by pressing the increase or decrease key.
Press the up key and scroll through the menu options until you get to Model Reset. With the arrow
pointing at data reset, press the clear key.
Press the down key until you get to the Type Select function. Press the increase or decrease button until
the arrow points at ACRO. If you change this from heli, it will then request you to press the clear key to
say yes to change the model type.
Set the modulation as needed to match your receiver by pressing the up key to get to the Modulation
function, and select the modulation needed by pressing the increase or decrease keys.
Press the up key until you get to the Input Select function. With the arrow pointing at Aux2, press the
increase key until it says INH next to Aux2. Press the select key and the arrow should now point at
Ch. 5 Left Aileron (Listed as Gear Channel on Receiver)
Ch. 6 Right Flap (Listed as Aux 1 on Receiver)
Ch. 7 Left Flap (Listed as Aux 2 on Receiver)

Model Selection

Model Reset

Model Type Selection

Modulation Selection

Input Select Set Up
