Summary of Contents for Horizon Hobby Spektrum SR2010

  • Page 1 SR2010 Instruction Manual SR2010 Bedienungsanleitung Manuel d’utilisation SR2010 Manuale di istruzioni SR2010...
  • Page 2: Warranty Registration

    NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. MEANING Of SpECIAl lANGUAGE The following terms are used throughout the product literature to indicate...
  • Page 3: General Precautions

    Waterproof Component Your new Spektrum™ SR2010 has been designed and built to allow you to operate the product in many “wet conditions”, including puddles, creeks, wet grass, snow and even rain. While waterproof, this component has not been designed to be immersed in water for long periods of time and should NOT be treated like a submarine.
  • Page 4: Wet Conditions Maintenance

    Furthermore, when appropriate maintenance procedures (as described below) are performed promptly following exposure, the receiver will remain best protected from corrosion or other long-term, water-related damage. Wet Conditions Maintenance Gently rinse the mud and dirt off the vehicle with a garden hose. Remove the battery pack(s) and dry the contacts. If you have an air compressor or a can of compressed air available, blow off the receiver to help remove any water that may have gotten into small crevices or corners.
  • Page 5: Aux Channel

    Aux channel The Aux channel can operate as a 3rd servo channel, or as a power supply for a personal transponder. If 5.5ms frame rate is selected in the transmitter, only two channels, Steering and Throttle, are operational. The Aux channel can be used to power a personal transponder or lights. If a frame rate other than 5.5ms is selected, the Aux channel will operate as a 3rd servo channel. IMpORTANT: When using the receiver with a DSMR transmitter, you must re-bind any time you change the frame rate in the transmitter. NOTICE: A DSMR is required for 5.5ms frame rate.
  • Page 6 powering the receiver with a separate receiver pack Receiver Throttle Servo Steering Servo Battery powering the receiver with an ESC Battery To Motor Electronic Speed Control Receiver Steering Servo Binding Receiver to Transmitter In order to operate, the receiver must be bound to the transmitter. Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifier) code of a single specific transmitter.
  • Page 7 2.4GHz Troubleshooting Guide Problem Possible Cause Solution The system will Your transmitter and Move transmitter 1 to 3 not connect receiver are too close meters from receiver together You are around metal Move to an area with less objects metal The receiver is not bound Check model selected and to the active model ensure you are bound to...
  • Page 8: Year Limited Warranty

    1-Year limited Warranty  What this Warranty Covers - Horizon Hobby, LLC, (Horizon) warrants to the origi- nal purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. ...
  • Page 9 the event that you may need any assistance. For questions or assistance, please visit our website at horizonhobby.com, submit an inquiry to productsupport@hori- zonhobby.com or call the toll-free telephone number referenced in the Warranty and Service Contact Information section to speak with a Product Support representative. Inspection or Services - If this Product needs to be inspected or serviced and is compliant in the country you live and use the Product in, please use the Horizon Online Service Request submission process found on our website or call Horizon...
  • Page 10: Warranty And Service Contact Information

    61822 USA (Product Technical 877-504-0233 Assistance) websales@horizon- Sales hobby.com 800-338-4639 sales@horizonhobby. Units 1–4, Ployters Rd, co.uk Service/Parts/Sales: Staple Tye, Harlow United Kingdom Horizon Hobby Limited Essex, CM18 7NS +44 (0) 1279 641 097 United Kingdom Horizon Technischer service@horizonhobby. Christian-Junge- Service Straße 1 Germany Sales: Horizon Hobby +49 (0) 4121 2655 25337 Elmshorn, GmbH Germany...
  • Page 11: Eu Compliance Statement

    (2) this device must accept any interference, Including interference that may cause undesired operation of the device. EU Compliance Statement: EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the RED Directive.
  • Page 12 Created 02/17 ©2017 Horizon Hobby, LLC. DSM, DSM2, DSMR, Active Vehicle Control, AVC and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. Patent pending.
