Saxby Lighting Lucca Wall Instruction Manual

Advertisement

Photocell Sensor (only for 67177)

• This product is fitted with a photocell.
• The light will automatically switch on when the ambient light level drops below 30 lux and will automatically switch off
when it reaches 70 lux.
• The photocell is located on the right hand side of the casing. To avoid nuisance triggering, the photocell should be
aimed a minimum of 12m away from heat sources, such as BBQ's, Air-Conditioners, other outside lighting, moving
cars and flue vents or reflective surfaces such as smooth white walls or swimming pools.

Technical data

Supply
220-240 V~, 50 Hz
Voltage:
Bulb
30W LED module (SMD), 4000K
Type:
This product contains a light source of energy efficiency class E.
Non-replaceable light source
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
This product is Class 1, must be connected to earth.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
This product is rated at IP65.
65
IP

Care and Safety

We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
This light source is protected by a shade. This part must be replaced immediately should the shade
become cracked or damaged. This fitting must not be used without the shade in place.
Replace Cracked Shade
For further information, please visit https://www.lighting-info.co.uk/67176
V4 07/06/2022
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
Non-replaceable control gear
Instruction manual
Lucca Wall
67176, 67177
www.saxbylighting.com
