- Page 1 Instruction Guide 40203 Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20220317R1 Date: __________...
- Page 2 Step 2 – Install Shelf .......................... 3 Before You Begin Read all instructions prior to assembling or installing any Holman product. Always locate your installation locations prior to performing any work. Be sure to have adjustable bottle restraint installed prior to installing shelf.
- Page 3 Instructions – 40203 Parts Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2...
- Page 4 Instructions – 40203 DO NOT EXCEED MANUFACTURERS WEIGHT CAPACITY FOR ROOF. Step 1 – Assemble Shelf Using four 1/4” x 1/2” carriage bolts and four 1/4” flanged lock nuts, attach shelf to gussets. Be sure the flanges on gussets are directed inward.
- Page 5 Instructions – 40203 Mark on installation surface the location of the holes in the gussets. Using a 9/32” drill bit, drill through the installation surface. MARK MARK MARK MARK Using four 1/4” x 5/8” hex bolts, four 1/4” lock washers, and four 1/4” flat washers, bolt through installation surface into press nuts on gussets.
