CARGO
FLIGHT CASE BOX INSTALLATION MANUAL
ENGLISH V 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CARGO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRIOBIKE CARGO

Summary of Contents for TRIOBIKE CARGO

  • Page 1 CARGO FLIGHT CASE BOX INSTALLATION MANUAL ENGLISH V 1.0...
  • Page 2 Our customer service department is dedicated to your satisfaction with Triobike and its products. If you have questions or need advice regarding assembly, parts, performance, or returns, please contact the experts at Triobike.
  • Page 3 INSTALLING THE FLIGHT CASE BOX ~10 mm ~10 mm FOAM thickness side view 30 mm width 160 mm top view length 570 mm Using double sided tape, place two 30mm thick foam panels on the bike frame, as shown in the picture. The holes for the M6 bolts, close to the side tubes, have to stay uncovered.
  • Page 4 INSTALLING THE FLIGHT CASE BOX INSTALLING THE FLIGHT CASE BOX rear view from the bottom of the bike front Using a long and thin marker, mark the center of the holes with the red circle on the Remove the box from the bike and turn it upside down. Drill 4 holes Ø8 mm on the bottom of the flight case box.
  • Page 5 INSTALLING THE FLIGHT CASE BOX INSTALLING THE FLIGHT CASE BOX M6x100 DIN 912 bolt M6 washer foam / spacer flight case box bottom bike frame M6 washer M6 nut Place again the box on the frame, and remove the lid from the top. Place an M6 washer and a M6x100 bolt on each of the 4 holes.
  • Page 6 Copyright© Triobike A/S 2022. All Rights Reserved.
  • Page 7 TRIOBIKE A/S Vesterbrogade 149, 1620 Copenhagen V - Denmark phone: +45 3670 0070 info@triobike.dk | www.triobike.com...
