- Page 1 CARGO HOOD INSTALLATION MANUAL ENGLISH V 1.0...
-
Page 2: Installing The Hood
INSTALLING THE HOOD Open the box and place the parts on a flat and clean surface. Take the 3 short straight bars, and fix them to the frame with the M5 screws (on the 2 Take the 2 side frame tubes and insert them into the front and rear panel brackets pins. kids hood: the shortest straight bar goes to the front, the longer one goes to the rear). - Page 3 INSTALLING THE HOOD INSTALLING THE HOOD Adjust the hood fabric in order to make it tight and well placed. Once this is done, lift Take the fabric cover and put it on the frame, placed symmetrically. Close the Velcro up the fabric and mark each position of the 6 snap buttons directly on the panels with a stripes around the metal frame and head tube, in the positions shown by the blue circles.
- Page 4 INSTALLING THE HOOD INSTALLING THE HOOD Mount each snap button and washer on the marked position, using a screwdriver. Finally press the buttons and secure the fabric.
- Page 5 TRIOBIKE A/S Vesterbrogade 149, 1620 Copenhagen V - Denmark phone: +45 3670 0070 info@triobike.dk | www.triobike.com...
