Insert cover in guide and secure with screw. Refer to Figure 18.

CAUTION: The Guide must be properly and completely installed

in the slot or the cover may dislodge and prevent you

from removing the PCI/EISA Assembly from the

system unit.

Guide

Figure 18. Replacing J2240 PCI/EISA Assembly Cover

Remove the plastic Connector Protector from the J2240 PCI/EISA Assembly

connector (if present).
