Symbol/PartsCod)
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
CHAPTER 1. OUTLINE OF THE PRODUCT, NOMENCLATURE AND FUNCTION
1. SPECIFICATIONS
Product specifications
Item
Name
LCD display
Dot pitch
Screen display size
Resolution (max.)
Displayable colors
Video signal
Sync signals
Input terminal
Plug & Play function
Power management
Temperature of operating environment
Power supply
Power consumption
Dimensions (W x D x H)
Weight
Dimensions (Units: mm)
174
362
240
LL-T1511A
38 cm (15 inches) Super-V and Anti Glare Low Reflection TFT LCD module
0.297(H) x 0.297(V) mm
Horizontal 304.1 mm x Vertical 228.1 mm
XGA 1024 x 768 pixels
16.19 million colors (max.)
Analog RGB (0.7p-p/75Ω)
H-Sync (TTL level: +/-), V-Sync (TTL level: +/-)
15 pin Mini D-sub connector
VESA DDC1 / DDC2B
VESA DPMS based
5-35°C
100-240V
23W max. (3W power-saving mode)
362 mm x 185 mm x 343 mm
Approx. 5.2 kg
185
Specification
Signal timings
Hsync
Display mode
(kHz)
VESA
640x480
31.5kHz
37.9kHz
37.5kHz
800x600
35.1kHz
37.9kHz
48.1kHz
46.9kHz
1024x768
48.4kHz
56.5kHz
60.0kHz
US text
720x400
31.5kHz
Power
640x480
35.0kHz
Macintosh
832x624
49.7kHz
series
1024x768
60.2kHz
Notes:
•
All are compliant only with non-interlace.
•
Frequencies for Power Macintosh and the Sun Ultra series are
reference values.
•
If the monitor is receiving timing signals that are not compat-
ible, [OUT OF TIMING] will appear. Follow your computer's
instruction manual to set the timing to be compatible with the
monitor.
•
If the monitor is not receiving any signal (synch signal), [NO
SIGNAL] will appear.
Vsync
Dot frequency
(Hz)
(MHz)
60Hz
25.175MHz
72Hz
31.5MHz
75Hz
31.5MHz
56Hz
36.0MHz
60Hz
40.0MHz
72Hz
50.0MHz
75Hz
49.5MHz
60Hz
65.0MHz
70Hz
75.0MHz
75Hz
78.75MHz
70Hz
28.3MHz
67Hz
30.5MHz
74.6Hz
57.3MHz
75Hz
80.0MHz
