HP SignagePlayer mp8200 Quickspecs page 16

QuickSpecs
Technical Specifications - Communications
Data Rates Data Rates Data Rates Data Rates
Modulation Modulation Modulation Modulation
Security Security Security Security
Sub-channels Sub-channels Sub-channels Sub-channels
Media Access Protocol Media Access Protocol Media Access Protocol Media Access Protocol
Network Architecture Network Architecture Network Architecture Network Architecture
Models Models Models Models
Roaming Roaming Roaming Roaming
Output Power (for CCK) Output Power Output Power Output Power
Output Power (for OFDM; Output Power Output Power Output Power
power varies by data rate)
Power Consumption Power Consumption
Power Consumption Power Consumption
Power Management Power Management Power Management Power Management
Antenna Connections Antenna Connections Antenna Connections Antenna Connections
Range Range Range Range
Form Factor Form Factor Form Factor Form Factor
Weight Weight Weight Weight
Dimensions Dimensions Dimensions Dimensions
Operating Voltage Operating Voltage Operating Voltage Operating Voltage
Temperature Temperature Temperature Temperature
Humidity Humidity Humidity Humidity
Altitude Altitude Altitude Altitude
802.11b: 1, 2, 5.5, 6, 9, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: ranging from 6 Mbps to 300 Mbps, depending on the combination of Bandwidth, Modulation
Coding Scheme, and Guard Interval used, as defined in IEEE 802.11n specification
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES (support for key sizes of 128,
192, and 256 bits), 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2,
LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products
through the Cisco Compatible Extensions Program Version 4) with Microsoft Windows Vista and XP only.
Multinational support with frequency bands and channels compliant to local regulations.
CSMA/CA (Collision Avoidance) with ACK
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points
15 dBm
15 dBm
Transmit: 2.3 Watts (average, with one spatial streams)
Receive: 1.9 Watts (average with two receive chains)
Idle mode: 30mW - 40mW (average)
Radio off: 20 mW (max)
ACPI compliant power management
802.11 compliant power saving mode
3 U.FL type connectors, 50 ohm nominal impedance
802.11 a - Typical (@6
Mbps)
802.11 b - Typical (@1
Mbps)
802.11 g - Typical (@1
Mbps)
MiniPCI-Express
0.013 lb (4.0 g)
1.1 x 1.2 in (26.8 x 30.0 mm)
3.3V +/- 9%, 1.5V +/- 5%
Operating: 32° to 176° F (0° to 80° C)
Non-operating: -40° to 176° F (-40° to 80° C)
Operating: 10% to 90% (non-condensing)
Non-operating: 5% to 90% (non-condensing)
Operating: 0 to 10,000 ft (3,048 m)
Non-operating: 0 to 50,000 ft (15,240 m)
DA - 14115 North America — Version 2 — October 28, 2011
600 feet - Outdoor Open Area
150 feet - Indoor, Office environment
1200 feet - Outdoor Open Area
300 feet - Indoor, Office environment
1200 feet - Outdoor Open Area
300 feet - Indoor, Office environment
HP SignagePlayer mp8200 Series HP SignagePlayer mp8200 Series HP SignagePlayer mp8200 Series HP SignagePlayer mp8200 Series
Page 16
