- Page 1 User’s manual FLIR A500f/FLIR A700f series...
- Page 2 Important note Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers. Důležitá poznámka Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se jimi.
-
Page 3: Table Of Contents
EU Declaration of conformity ............14 Cleaning the camera ................ 16 12.1 Camera housing, cables, and other items........16 12.2 Infrared lens ................16 About FLIR Systems ................ 17 13.1 More than just an infrared camera ..........18 13.2 Sharing our knowledge ............18 13.3 Supporting our customers............ -
Page 4: Disclaimers
1.7 Copyright © 2021 FLIR Systems, Inc. All rights reserved worldwide. No parts of the software in- cluding source code may be reproduced, transmitted, transcribed or translated into any language or computer language in any form or by any means, electronic, magnetic, opti- cal, manual or otherwise, without the prior written permission of FLIR Systems. -
Page 5: Safety Information
WARNING Applicability: Digital devices subject to 15.21. NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems may void the FCC authorization to operate this equipment. WARNING Do not use screws that are too long. The depth of the holes in the camera is 4.0 mm (0.16 in) and 5.5 mm (0.22 in), see , page . - Page 6 Safety information CAUTION Applicability: Cameras where you can remove the lens and expose the infrared detector. Do not use compressed air of lower quality than “Process air” when you remove dust from the detector. Air of lower quality than “Process air” can contain high levels of contaminants. Damage to the detector can occur.
-
Page 7: Notice To User
To register the camera, go to www.flir.com/register. To access the registration form, you must log in to your FLIR account or sign up for a new account. You will also need the serial number of your camera, which is available on the calibration certificate. -
Page 8: Documentation Updates
3.7 Important note about this manual FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply to your particular camera model. -
Page 9: Customer Help
• The communication protocol, or method, between the camera and your device (e.g., SD card reader, HDMI, Ethernet, USB, or FireWire). • Device type (PC/Mac/iPhone/iPad/Android device, etc.). • Version of any programs from FLIR Systems. • Full name, publication number, and revision number of the manual. 4.3 Downloads... -
Page 10: Flir's Partner Network
FLIR’s Partner Network We welcome you to join our Partner Network at our Customer Support site! The Partner Network is located at http://support.flir.com (partner registration needed) and is specifically aimed at distributors and system integrators. Once your company has been approved, you can do one or more of the following, from a single location: •... -
Page 11: Introduction
When delivered, these cameras are already mounted into a environmental housing de- vice from VIDEOTEC. The device is based on model HOV Hi-PoE IPM with special FLIR front with support for visual and thermal camera. There is no active cooling, such as a cooling fan. However, the camera is mounted on FLIR custom made cooling plates and there are also extra cooling plates connecting the camera to the housing. -
Page 12: Mechanical Installation
Mechanical installation 7.1 Overview The FLIR A500f/FLIR A700f series camera is an infrared thermal imaging camera for out- door applications. It is intended to be mounted on a medium-duty fixed pedestal mount or wall mount commonly used in the CCTV industry. Cables will exit from the bottom of the camera housing. -
Page 13: Connecting Network And Power
Mechanical installation 7.5 Connecting network and power Connect an Ethernet cable (PoE, 36–56 V DC) to the connector gland on the bottom of the housing device. Use the strain-relief clamp that is delivered with the camera: Follow this procedure: 1. Unscrew the strain-relief clamp into one long (male) part and one short (female) part. 2. -
Page 14: Camera Installation
2. Connect the camera to power and the network. 3. The camera is set to use DHCP. On the computer, use FLIR IP Config to identify the camera on the network, and change the IP settings if necessary. -
Page 15: Rtsp Streams
RTSP Streams It is possible to establish streaming sessions with the FLIR A500f/FLIR A700f camera. For more information, refer to the User’s manual of the FLIR A400/A500/A700 camera series available online: https://support.flir.com/resources/chxa/. #T810485; r. AA/76994/76994; en-US... -
Page 16: Camera Web Interface
Camera web interface For information on how to configure the camera from the web interface, refer to the User’s manual of the FLIR A400/A500/A700 camera series available online: https://support.flir.com/resources/chxa/. #T810485; r. AA/76994/76994; en-US... -
Page 17: Eu Declaration Of Conformity
EU Declaration of conformity [See next page] #T810485; r. AA/76994/76994; en-US... - Page 18 Täby, Sweden March 11, 2021 AQ320237 CE Declaration of Conformity – EU Declaration of Conformity Product: FLIR-A8590 (Axxx) IR Camera in Environmental housing Name and address of the manufacturer: FLIR Systems AB PO Box 7376 SE-187 15 Täby, Sweden This declaration of conformity is issued under the sole responsibility of the manufacturer.
-
Page 19: Cleaning The Camera
Cleaning the camera 12.1 Camera housing, cables, and other items Use one of these liquids: • Warm water • A weak detergent solution Equipment: • A soft cloth Follow this procedure: 1. Soak the cloth in the liquid. 2. Twist the cloth to remove excess liquid. 3. -
Page 20: About Flir Systems
• Extech Instruments (2007) Figure 13.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a manufacturing plant in Tallinn, Estonia. -
Page 21: More Than Just An Infrared Camera
13.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infra- red camera systems. We are committed to enabling all users of our infrared camera sys- tems to work more productively by providing them with the most powerful camera–... -
Page 22: Supporting Our Customers
13.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equipment and expertise to solve it within the shortest possible time. - Page 23 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T810485...
