User's manual
FLIR A310 ex
nbn Austria GmbH

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A310 ex Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FLIR A310 ex Series

Summary of Contents for FLIR A310 ex Series

  • Page 1 User’s manual FLIR A310 ex nbn Austria GmbH...
  • Page 3 User’s manual FLIR A310 ex #T559891; r. AE/57789/57789; en-US...

  • Page 5: Table Of Contents

    Note about authoritative versions..........4 Customer help ..................5 General .................. 5 Submitting a question ..............5 Downloads ................5 What is FLIR A310 ex?................6 Typical system overview..............7 Typical system setup procedure............8 Technical data ...................9 Online field-of-view calculator ............9 Note about technical data ............9 Note about authoritative versions..........

  • Page 7: Disclaimers

    GRANT OF SOFTWARE LICENSE. This EULA grants you the following 1.4 Copyright license: © 2019, FLIR Systems, Inc. All rights reserved worldwide. No parts of the ◦ You may use the SOFTWARE only on the DEVICE. software including source code may be reproduced, transmitted, transcribed ◦...

  • Page 8: Safety Information

    Safety information CAUTION Do not point the infrared camera (with or without the lens cover) at strong energy sources, for example, devices that cause laser radiation, or the sun. This can have an unwanted effect on the accuracy of the camera.

  • Page 9: Notice To User

    To access the latest manuals, translations of manuals, and notifications, go to the Down- load tab at: http://support.flir.com It only takes a few minutes to register online. In the download area you will also find the latest releases of manuals for our other products, as well as manuals for our historical and obsolete products.

  • Page 10: Important Note About This Manual

    Notice to user 3.6 Important note about this manual FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply to your particular camera model.

  • Page 11: Customer Help

    • The communication protocol, or method, between the camera and your device (for ex- ample, SD card reader, HDMI, Ethernet, USB, or FireWire) • Device type (PC/Mac/iPhone/iPad/Android device, etc.) • Version of any programs from FLIR Systems • Full name, publication number, and revision number of the manual 4.3 Downloads...

  • Page 12: What Is Flir A310 Ex

    ATEX product directives and similar regulations. The FLIR A310 ex is an ATEX-proof solution, with a thermal imaging camera mounted in an enclosure, making it possible to monitor critical and other valuable assets in explosive atmospheres.

  • Page 13: Typical System Overview

    Typical system overview 1. Thermovision System Tools & Utilities CD-ROM. 2. Ethernet cable. 3. Optical-to-Ethernet converter. 4. FC connectors from the camera housing (including two spares). 5. 24 V DC power supply. 6. Pigtail cable from the housing. The color coding of the pigtail cable is: •...

  • Page 14: Typical System Setup Procedure

    • FLIR IR Monitor. • FLIR IR Camera Player. 6. Start FLIR IP Config to identify the unit in the network and automatically assign or manually set IP addresses, etc. For more information, see the FLIR IP Config manual on the User Documentation CD-ROM or on the Help menu in FLIR IP Config.

  • Page 15: Technical Data

    8.2 Note about technical data FLIR Systems reserves the right to change specifications at any time without prior notice. Please check http://support.flir.com for latest changes.

  • Page 16: Flir A310 Ex 25

    Rev.: 51350 Introduction The FLIR A310 ex is an ATEX-proof solution, with a thermal imaging camera mounted in an enclosure—making it possible to monitor critical and other valuable assets in explo- sive atmospheres. Process monitoring, quality control, and fire detection in potentially explosive locations are typical applications for the FLIR A310 ex.
  • Page 17 Technical data Explosion protection-specific data For use in EX zone 1, 2, 21, 22 Ignition protection category Flame-proof enclosure “d” Maximum surface temperature (according to tem- Maximum 85°C perature class T6) ATEX certification (version -AXC) • II 2G Ex db IIC T6 / T5 •...
  • Page 18 Alarm output Log, store image, file sending (ftp), email notifica- tion (SMTP). With an additional FLIR I/O module (T130090 or T130091), the system can provide up to 8 digital outputs and 8 analog outputs that can be con- nected to any camera analytic function or the cameras status.
  • Page 19 Technical data Supplies & accessories: • T129252; Special temperature range -20 to +700 deg C • T129253; Special temperature range -20 to +500 deg C • T129254; High temperature measurement option -20 to +2000 deg C • T130151; Special temperature range -20 to +2000 deg C •...

  • Page 20: Flir A310 Ex 45

    Rev.: 51351 Introduction The FLIR A310 ex is an ATEX-proof solution, with a thermal imaging camera mounted in an enclosure—making it possible to monitor critical and other valuable assets in explo- sive atmospheres. Process monitoring, quality control, and fire detection in potentially explosive locations are typical applications for the FLIR A310 ex.
  • Page 21 Technical data Explosion protection-specific data For use in EX zone 1, 2, 21, 22. Ignition protection category Flame-proof enclosure “d” Maximum surface temperature (according to tem- Maximum 85°C perature class T6) ATEX certification (version -AXC) • II 2G Ex db IIC T6 / T5 •...
  • Page 22 Alarm output Log, store image, file sending (ftp), email notifica- tion (SMTP). With an additional FLIR I/O module (T130090 or T130091), the system can provide up to 8 digital outputs and 8 analog outputs that can be con- nected to any camera analytic function or the cameras status.
  • Page 23 Technical data Supplies & accessories: • T129252; Special temperature range -20 to +700 deg C • T129253; Special temperature range -20 to +500 deg C • T129254; High temperature measurement option -20 to +2000 deg C • T130151; Special temperature range -20 to +2000 deg C •...

  • Page 24: Mechanical Drawings

    Mechanical drawings [See next page] #T559891; r. AE/57789/57789; en-US...

  • Page 26: Ec Type Examination Certificate

    EC Type Examination Certificate [See next page] #T559891; r. AE/57789/57789; en-US...

  • Page 29: Ec Type Examination Certificate, 1St Supplement

    EC Type Examination Certificate, 1st supplement [See next page] #T559891; r. AE/57789/57789; en-US...

  • Page 32: Ec Type Examination Certificate, 2Nd Supplement

    EC Type Examination Certificate, 2nd supplement [See next page] #T559891; r. AE/57789/57789; en-US...

  • Page 34: Ec Type Examination Certificate, 3Rd Supplement

    EC Type Examination Certificate, 3rd supplement [See next page] #T559891; r. AE/57789/57789; en-US...

  • Page 37: Ec Declaration Of Conformity (Enclosure)

    EC Declaration of conformity (enclosure) [See next page] #T559891; r. AE/57789/57789; en-US...
  • Page 38 EG-Konformitätserklärung EC-Declaration of Conformity Déclaration de Conformité CE AT – Automation Technology GmbH • Hermann-Bössow-Strasse 6 – 8 • D-23843 Bad Oldesloe, Germany erklärt in alleiniger Verantwortung, declares in its sole responsibility, déclare sous sa seule responsabilité dass das Produkt IRCamSafeEX-AXB that the product IRCamSafeEX-AXC...

  • Page 39: Certiticate Of Conformity (Camera)

    Certiticate of conformity (camera) [See next page] #T559891; r. AE/57789/57789; en-US...

  • Page 41: Thermographic Measurement Techniques

    Thermographic measurement techniques 16.1 Introduction An infrared camera measures and images the emitted infrared radiation from an object. The fact that radiation is a function of object surface temperature makes it possible for the camera to calculate and display this temperature. However, the radiation measured by the camera does not only depend on the tempera- ture of the object but is also a function of the emissivity.
  • Page 42 Thermographic measurement techniques 16.2.1.1.1 Method 1: Direct method Follow this procedure: 1. Look for possible reflection sources, considering that the incident angle = reflection angle (a = b). Figure 16.1 1 = Reflection source 2. If the reflection source is a spot source, modify the source by obstructing it using a piece if cardboard.
  • Page 43 Thermographic measurement techniques 3. Measure the radiation intensity (= apparent temperature) from the reflection source using the following settings: • Emissivity: 1.0 • D You can measure the radiation intensity using one of the following two methods: Figure 16.3 1 = Reflection source Figure 16.4 1 = Reflection source You can not use a thermocouple to measure reflected apparent temperature, because a thermocouple measures temperature, but apparent temperatrure is radiation intensity.
  • Page 44 Thermographic measurement techniques 5. Measure the apparent temperature of the aluminum foil and write it down. The foil is considered a perfect reflector, so its apparent temperature equals the reflected appa- rent temperature from the surroundings. Figure 16.5 Measuring the apparent temperature of the aluminum foil. 16.2.1.2 Step 2: Determining the emissivity Follow this procedure: 1.

  • Page 45: Reflected Apparent Temperature

    50%. 16.6 Other parameters In addition, some cameras and analysis programs from FLIR Systems allow you to com- pensate for the following parameters: • Atmospheric temperature – i.e. the temperature of the atmosphere between the cam- era and the target •...

  • Page 46: About Flir Systems

    • Extech Instruments (2007) Figure 17.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a manufacturing plant in Tallinn, Estonia.

  • Page 47: More Than Just An Infrared Camera

    17.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infra- red camera systems. We are committed to enabling all users of our infrared camera sys- tems to work more productively by providing them with the most powerful camera–...

  • Page 48: Supporting Our Customers

    17.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equipment and expertise to solve it within the shortest possible time.
  • Page 49 This section contains the original manual from the manufacturer of the enclosure.
  • Page 50 Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras AT – Automation Technology GmbH Datum: 01.04.2017 Revision: 1.4 © AT – Automation Technology GmbH 2016...
  • Page 51 1 Inhaltsverzeichnis Allgemeine Angaben........................2 Hersteller ..........................2 Einleitung ..........................2 Kennzeichnung ........................3 Allgemeine Sicherheitshinweise ...................... 4 Verwendung und Vorgesehener Einsatzbereich ................5 Zulässige Einbauten ......................... 5 Zulässige Kabeleinführungen und Steckverbinder ..............6 Ausführung mit vorkonfektionierten Anschlusskabeln ............6 Normenkonformität ........................

  • Page 52: Allgemeine Angaben

    Bei den Kameragehäusen der Serie IRCamSafeEX-AXB/C handelt es sich um Schutzgehäuse für Infrarotkameras. Die Gehäuse sind für den Einsatz von Infrarotkameras der Serie FLIR A3XX/SC3XX und A615/SC6XX, sowie Flir G300A und AT IRS und Xenics Serval in explosionsgefährdeten Bereichen konzipiert. Die Variante–AXC ist zudem für den Einsatz in staubexplosionsgefährlicher Atmosphäre zugelassen.

  • Page 53: Kennzeichnung

    2.3 Kennzeichnung Gehäusevariante 24V DC: AT – Automation Technology GmbH Hermann-Bössow-Straße 6 – 8 • 23843 Bad Oldesloe • Germany Phone: +49 4531 88011-0 • www.AutomationTechnology.de Model: IRCamSafeEX-AXC Serial No.: 71000260 Year: 2016 Power: 24VDC, 60W amb -40°C - +40°C / 60°C max.

  • Page 54: Allgemeine Sicherheitshinweise

    3 Allgemeine Sicherheitshinweise Die Betriebsanleitung enthält grundlegende Sicherheitshinweise, die bei Aufstellung, Betrieb und Wartung zu beachten sind. Nichtbeachtung hat eine Gefährdung für Personen, Anlage und Umwelt zur Folge. Gefahr durch unbefugte Arbeiten am Gerät! Montage, Installation, Inbetriebnahme, Betrieb und Wartung dürfen ausschließlich von dazu befugtem und entsprechend geschultem Personal durchgeführt werden.

  • Page 55: Verwendung Und Vorgesehener Einsatzbereich

    4.1 Zulässige Einbauten Folgende Kamera und Optikkombinationen können eingesetzt werden. Kamera Optik Variante - AXC Flir A3XX, ohne Zusatzoptik SC3XX, 45° Zusatzoptik, f‘ = 10mm A3XXsc 15° Zusatzoptik, f‘ = 30mm 6° Zusatzoptik, f‘ = 76mm 90° Zusatzoptik, f‘ = 4mm Flir A615, 15°...

  • Page 56: Zulässige Kabeleinführungen Und Steckverbinder

    4.2 Zulässige Kabeleinführungen und Steckverbinder Für den Anschluss der Stromversorgungsleitung und der Datenübertragungsleitung stehen zwei druckfeste und zünddurchschlagsichere Kabeleinführungen zur Verfügung. Alternativ können druckfeste und zünddurchschlagsichere Steckverbindersysteme eingesetzt werden. Die Kabeleinführungen und Steckverbinderbuchsen sind vom Hersteller vormontiert. Optional wird vom Hersteller das Gehäuse zusätzlich mit bereits angeschlossenen Anschlusskabeln geliefert. Folgende EX-Kabeleinführungen sind für die Verwendung mit dem Schutzgehäuse geeignet.

  • Page 57: Normenkonformität

     Zweite Anschlussseite ist nicht-konfektioniert und zum Spleißen geeignet  Typische Länge 5m Anschluss 2 (Stromversorgung) ist mit einem 3 adrigen Kupfer-Kabel (z.B. Helukabel 37264) mit folgenden Eigenschaften ausgestattet:  Manteldurchmesser: 9,8mm  Aderquerschnitt: 3 x 1,5mm feindrähtig  Typische Länge 5m, optional mit Stecker Stahl 8570/12-306 konfektioniert Kundenspezifische Längen und Konfektionierungen der freien Enden sind auf Anfrage möglich.

  • Page 58: Technische Daten

    6 Technische Daten Allgemeine technische Daten:  Normal-Betriebsumgebungstemperaturbereich T : -40°C … +60°C  Schutzart: IP67  Gewicht: 6,7 kg (ohne Kamera und Optik)  Leervolumen: 5,06l  Außenmaße (ohne Sonnendach und Anschlüsse): D=170mm, L=408mm  Gehäusematerial: Aluminium  Oberfläche: pulverbeschichtet, ...
  • Page 59 Abb. 1: Übersicht IRCamSafeEX-AXC (alle Maße in mm) – Änderungen vorbehalten Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras 9 AT-Automation Technology GmbH...

  • Page 60: Transport, Lagerung Und Entsorgung

    7 Transport, Lagerung und Entsorgung Transport: Erschütterungsfrei in der Originalverpackung, nicht stürzen, vorsichtig handhaben. Lagerung: Trocken in der Originalverpackung lagern Entsorgung: Die umweltgerechte Entsorgung aller Bauteile gemäß den gesetzlichen Bestimmungen ist sicherzustellen. 8 Montage und Demontage Vor der Montage den Umgebungstemperaturbereich und die Schutzart gemäß Typenschild auf Zulässigkeit im Montagebereich prüfen.

  • Page 61: Installation

    9 Installation Installationsarbeiten nur durch Fachpersonal! Installationsarbeiten dürfen nur von dazu befugtem und entsprechend geschultem Personal durchgeführt werden. Geltende nationale Bestimmungen im Einsatzland, z.B. EN 60079-14 beachten. Die Montage der Kabeleinführungen oder gehäuseseitigen Steckverbinder und die Installation der Anschlussleitungen erfolgt durch den Hersteller oder durch vom Hersteller autorisiertes Personal.

  • Page 62: Installation Der Anschlussleitungen

    9.1 Installation der Anschlussleitungen Leitungen Die Qualität der verwendeten Zuleitung ist so zu wählen, dass sie den thermischen und mechanischen Anforderungen im Einsatzbereich genügt. Die Kabel müssen den entsprechenden Richtlinien für direkte Einführung in druckfeste Kapselung nach EN 60079-14 genügen. Die Kabeleinführung ist mit Vergussmasse zur Abdichtung der Einzeladern auszuführen.

  • Page 63: Hinteren Gehäusedeckel Schließen

    Nicht korrekt durchgeführte Installation!  Bitte beachten Sie die Gewindegrößen für die Leitungseinführungen in der Dokumentation des Betriebsmittels.  Die Anschlussleistung muss den geltenden Vorschriften entsprechen und über den erforderlichen Querschnitt verfügen. Der Durchmesser muss mit den Angaben auf der Kabeldurchführung übereinstimmen.

  • Page 64: Inbetriebnahme

    2. Konfigurieren der Ethernet-Verbindung zum Schutzgehäusekontroller mit dem Tool „EDS Configurator“ 3. Starten der Website des Schutzgehäusekontrollers und ggf. Konfigurieren der Netzwerk- Switch Einstellungen. 4. Prüfen und Konfigurieren der Ethernet-Verbindung zur Infrarotkamera mit dem Tool „FLIR IP Config“ 5. Starten der Monitorsoftware 6. Prüfen des Kamerabildes 7.

  • Page 65: Wartung

    11 Wartung Der Betreiber einer elektrischen Anlage in explosionsgefährdeter Umgebung hat diese in ordnungsgemäßem Zustand zu halten, ordnungsgemäß zu betreiben, zu überwachen und Instandhaltungs- sowie Instandsetzungsarbeiten durchzuführen! Wartungsarbeiten und Arbeiten zur Störungsbeseitigung dürfen nur von Fachpersonal durchgeführt werden. Im Rahmen der Wartung sind vor allem die Teile, von denen die Zündschutzart und die Funktionsfähigkeit abhängen, auf Ihren ordnungsgemäßen Zustand zu prüfen.

  • Page 66: Reinigung

    11.2 Reinigung Die Reinigung des Gehäuses kann mit einem Tuch, Besen, Staubsauger o.ä. erfolgen. Sollte für die Reinigung des Sichtfensters die Demontage des Schutzgitters erforderlich sein ist das Gerät vorher spannungsfrei zu schalten. Das Fenster kann mit Wasser oder auch mit Isopropanol (vorausgesetzt das dieses in dem Bereich zulässig ist) gereinigt werden.

  • Page 67: Eg-Baumusterprüfbescheinigung

    13 EG-Baumusterprüfbescheinigung Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras 17 AT-Automation Technology GmbH...
  • Page 68 Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras 18 AT-Automation Technology GmbH...
  • Page 69 Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras 19 AT-Automation Technology GmbH...
  • Page 70 Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras 20 AT-Automation Technology GmbH...
  • Page 71 Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras 21 AT-Automation Technology GmbH...
  • Page 72 Betriebsanleitung IRCamSafeEX-AXC Ex-d Gehäuse für Infrarotkameras 22 AT-Automation Technology GmbH...
  • Page 73 This section contains a translation of the original manual from the manufacturer of the enclosure. The translation has been approved by the manufacturer.
  • Page 74 Operating Instructions IRCamSafeEX-AXC Ex-d Enclosure for Infrared Cameras AT – Automation Technology GmbH Date: 4/1/2017 Version: 1.4 © AT – Automation Technology GmbH 2017...
  • Page 75 1 Contents General Information ........................2 Manufacturer .......................... 2 Introduction ..........................2 Labeling ........................... 3 General Safety Instructions ......................4 Use and Intended Area of Application .................... 5 Permitted Attachments ......................5 Permitted Cable Glands and Connectors ................6 Construction With Preassembled Connection Cables ............. 6 Compliance With Applicable Standards ..................

  • Page 76: General Information

    FLIR A3XX/SC3XX and A615/SC6XX series, as well as the Flir G300A, AT IRS and Xenics Serval, in potentially explosive atmospheres. The AXC variant is also approved for use in explosive atmospheres caused by combustible dusts.

  • Page 77: Labeling

    2.3 Labeling 24-VDC enclosure type: AT – Automation Technology GmbH Hermann-Bössow-Straße 6 – 8 • 23843 Bad Oldesloe • Germany Phone: +49 4531 88011-0 • www.AutomationTechnology.de Model: IRCamSafeEX-AXC Serial No.: 71000260 Year: 2016 Power: 24VDC, 60W amb -40°C - +40°C / 60°C max.

  • Page 78: General Safety Instructions

    3 General Safety Instructions The operating instructions contain important safety instructions that must be observed when carrying out assembly, operation and maintenance work. Failure to observe the safety instructions may endanger people, the plant and the environment. Hazard caused by unauthorized work on the device Assembly, installation, commissioning, operation and maintenance work may only be performed by personnel who are authorized and trained to do so.

  • Page 79: Use And Intended Area Of Application

    4.1 Permitted Attachments The following camera and lens combinations can be used. Camera Lens model Flir A3XX, Without ancillary lens SC3XX, 45° ancillary lens, focal length = 10 mm A3XXsc 15° ancillary lens, focal length = 30mm 6° ancillary lens, focal length = 76mm 90°...

  • Page 80: Permitted Cable Glands And Connectors

    4.2 Permitted Cable Glands and Connectors There are two pressure-resistant, flameproof cable glands to connect the power supply line and the data transmission line. Alternatively, pressure-resistant, flameproof connector systems can be used. The cable glands and connectors are preassembled by the manufacturer. The enclosure can also be supplied by the manufacturer with the connection cables already connected.
  • Page 81  Second terminal side is not assembled and can be spliced  Typical length: 5 m Connection 2 (electrical power supply) is equipped with a three-core copper cable (e.g. Helukabel 37264) that has the following properties:  Sheath diameter: 9.8 mm ...

  • Page 82: Compliance With Applicable Standards

    5 Compliance With Applicable Standards The protective enclosures comply with the following standards and guidelines:  Directive 2014/34/EC  EN 60079-0:2012+A11:2013;"Explosive atmospheres — Part 0: Equipment — General requirements"  EN 60079-1:2014; "Explosive atmospheres — Part 1: Equipment protection by flameproof enclosures 'd'"...

  • Page 83: Technical Data

    6 Technical Data General technical data:  Normal operating conditions temperature range T : -40°C to +60°C  Protection class: IP67  Weight: 6.7 kg (without camera and lens)  Total capacity: 5.06l  External dimensions (excluding canopy and connections): diameter=170 mm; length=408 mm ...
  • Page 84 Fig. 1: Overview of IRCamSafeEX-AXC (all measurements in mm) — subject to change without notice Operating Instructions IRCamSafeEX-AXC Ex d Enclosure for Infrared Cameras 10 AT-Automation Technology GmbH...

  • Page 85: Transport, Storage And Disposal

    7 Transport, Storage and Disposal Transport: The device should transported in its original packaging and should not be able to move around within the packaging. Handle the device with care; do not drop it. Storage: Store the device in its original packaging in a dry place. Disposal: All components must be disposed of in a manner that does not harm the environment and in line with legal requirements.

  • Page 86: Installation

    9 Installation Installation work must only be carried out by specialist personnel Installation work may only be performed by personnel who have been authorized and trained to do so. All applicable national regulations in the country in which the product is used must be observed (e.g.

  • Page 87: Installing The Connection Lines

    9.1 Installing the Connection Lines Lines The quality of the supply pipe used must meet the thermal and mechanical requirements in the area of application. The cables must comply with the applicable guidelines for direct entry into flameproof enclosures in line with EN 60079-14. Cable glands must be sealed with a sealing compound to waterproof the individual wires.

  • Page 88: Locking The Rear Enclosure Cover

    Incorrect Installation  Please observe the thread sizes for the cable glands in the operating instructions  The connection line must meet the applicable requirements and the cross section dimensions must be sufficient. The diameter must comply with the cable gland requirements ...

  • Page 89: Commissioning

    Configurator" tool 3. Load the website for the protective enclosure controller and if necessary, configure the network switch settings 4. Check and configure the Ethernet connection to the infrared camera using the "FLIR IP Config" tool 5. Start the monitor software 6.

  • Page 90: Maintenance

    11 Maintenance Operators of electrical systems in potentially explosive atmospheres must ensure that the system is kept in proper working order and is operated correctly. The operator must also monitor the system and carry out maintenance and repair work as required. Maintenance work and troubleshooting must only be performed by specialist personnel.

  • Page 91: Cleaning

    11.2 Cleaning The enclosure can be cleaned with a cloth, brush, vacuum cleaner or other similar products. If it is necessary to remove the protective grid to clean the viewing window, the device must first be disconnected from the mains. The window can be cleaned with water or with isopropanol (provided that this is permitted in the relevant area).

  • Page 92: Ec-Type Examination Certificate

    13 EC-Type Examination Certificate Operating Instructions IRCamSafeEX-AXC Ex d Enclosure for Infrared Cameras 18 AT-Automation Technology GmbH...
  • Page 93 Operating Instructions IRCamSafeEX-AXC Ex d Enclosure for Infrared Cameras 19 AT-Automation Technology GmbH...
  • Page 94 Operating Instructions IRCamSafeEX-AXC Ex d Enclosure for Infrared Cameras 20 AT-Automation Technology GmbH...
  • Page 95 Operating Instructions IRCamSafeEX-AXC Ex d Enclosure for Infrared Cameras 21 AT-Automation Technology GmbH...
  • Page 96 Operating Instructions IRCamSafeEX-AXC Ex d Enclosure for Infrared Cameras 22 AT-Automation Technology GmbH...
  • Page 97 Operating Instructions IRCamSafeEX-AXC Ex d Enclosure for Infrared Cameras 23 AT-Automation Technology GmbH...
  • Page 98 A note on the technical production of this publication This publication was produced using XML — the eXtensible Markup Language. For more information about XML, please visit http://www.w3.org/XML/ A note on the typeface used in this publication This publication was typeset using Linotype Helvetica™ World. Helvetica™ was designed by Max Miedinger (1910–1980) LOEF (List Of Effective Files) T501085.xml;...
  • Page 100 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T559891...
