  • Page 1 User’s manual FLIR Ax5 series...
  • Page 3 User’s manual FLIR Ax5 series #T559770; r. AF/30726/30726; en-US...

  • Page 5: Table Of Contents

    FLIR A15 f=9 mm..............29 11.7 FLIR A15 f=9 mm (7.5 Hz) ............33 11.8 FLIR A15 f=9 mm with SC kit (7.5 Hz)..........37 11.9 FLIR A35 f=19 mm ..............41 11.10 FLIR A35 f=9 mm..............45 #T559770; r. AF/30726/30726; en-US...
  • Page 6 11.12 FLIR A5 f=5 mm ............... 53 11.13 FLIR A5 f=5 mm (7.5 Hz) ............57 11.14 FLIR A5 f=5 mm with SC kit (7.5 Hz) ..........61 11.15 FLIR A5 f=9 mm ............... 65 11.16 FLIR A5 f=9 mm (7.5 Hz) ............69 11.17 FLIR A65 f=13 mm ..............
  • Page 7 Table of contents 20.4 Infrared semi-transparent materials..........127 The measurement formula..............129 Emissivity tables ................133 22.1 References................133 22.2 Tables .................. 133 #T559770; r. AF/30726/30726; en-US...

  • Page 9: Legal Disclaimer

    Products which are not manufactured by FLIR Systems but included in systems delivered by FLIR Systems to the original purchaser, carry the warranty, if any, of the particular sup- plier only. FLIR Systems has no responsibility whatsoever for such products.

  • Page 10: Quality Assurance

    Names and marks appearing on the products herein are either registered trademarks or trademarks of FLIR Systems and/or its subsidiaries. All other trademarks, trade names or company names referenced herein are used for identification only and are the property of their respective owners.
  • Page 11 • NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT. FLIR Sys- tems AB HAS INDEPENDENTLY DETERMINED HOW TO USE THE SOFTWARE IN THE DEVICE, AND MS HAS RELIED UPON FLIR Systems AB TO CONDUCT SUFFICIENT TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE FOR SUCH USE.

  • Page 12: Safety Information

    The liquids can be dangerous. Injury to persons can occur. WARNING Applicability: FLIR Ax5. Do not use screws that are too long. If you use screws that are too long, damage to the camera will occur.

  • Page 13: Notice To User

    3.2 Calibration FLIR Systems recommends that you verify your calibration yearly. You can verify the cali- bration yourself or with the help of a FLIR Systems Partner. If preferred, FLIR Systems of- fers a calibration, adjustment, and general maintenance service.

  • Page 14: Note About Authoritative Versions

    Notice to user 3.8 Note about authoritative versions The authoritative version of this publication is English. In the event of divergences due to translation errors, the English text has precedence. Any late changes are first implemented in English. #T559770; r. AF/30726/30726; en-US...

  • Page 15: Customer Help

    Customer help 4.1 General For customer help, visit: http://support.flir.com #T559770; r. AF/30726/30726; en-US...

  • Page 16: Submitting A Question

    • The communication protocol, or method, between the camera and your device (for ex- ample, HDMI, Ethernet, USB, or FireWire) • Device type (PC/Mac/iPhone/iPad/Android device, etc.) • Version of any programs from FLIR Systems • Full name, publication number, and revision number of the manual 4.3 Downloads On the customer help site you can also download the following: •...

  • Page 17: Introduction

    Introduction The FLIR Ax5 cameras have features and functions that make them the natural choice for anyone who uses PC software to solve problems. Available resolutions include 80 × 64, 160 × 128, and 320 × 256 pixels. Among their main features are GigE Vision and GenICam compliance, which makes them plug-and-play when used with software packages such as IMAQ Vision and Halcon.

  • Page 18: List Of Accessories And Services

    Cable kit Mains (UK,EU,US) T198348 Cable M12 Pigtail T127605ACC Cable M12 Sync T127606ACC Ethernet cable CAT-6, 2m/6.6 ft. T951004ACC FLIR IR Camera Player DSW-10000 FLIR Tools T198584 FLIR Tools+ (license only) T198583 Focus adjustment tool T198342ACC Gigabit PoE injector 16 W, with multi-plugs...
  • Page 19 GUS, Middle East, North Africa) Travel and lodging expenses instructor (various) ITC-TOL-1004 NOTE FLIR Systems reserves the right to discontinue models, parts or accessories, and other items, or to change specifications at any time without prior notice. #T559770; r. AF/30726/30726; en-US...

  • Page 20: Mechanical Installation

    FLIR Systems provides P/N T198349 (base support) for this purpose, but other base supports or heat sinks can be used.

  • Page 21: Focusing The Camera

    Focusing the camera 8.1 Focusing cameras with 5, 9, 13, and 19 mm lenses 8.1.1 Necessary tools Focus adjustment tool (included in the package for cameras with 5, 9, 13, and 19 mm lenses). 8.1.2 Procedure Follow this procedure: 1. Note the four pegs on the inside of the focus adjustment tool. 2.

  • Page 22: Focusing Cameras With 25 Mm Lenses

    Focusing the camera 8.2 Focusing cameras with 25 mm lenses CAUTION Do not use the focus adjustment tool when focusing cameras with a 25 mm lens. 8.2.1 Necessary tools Allen wrench, 1.5 mm. 8.2.2 Procedure Follow this procedure: 1. Unlock the clamp by loosening the Allen screw. 2.

  • Page 23: Downloads

    Downloads The principal software used to configure and control the camera is FLIR GEV Demo 1.3.0. This software is based on the PleoraeBus SDK and the runtime Pleora GEVPlayer that comes with the SDK. Downloads: • http://support.flir.com/Ax5-software • Link to download PureGEV SDK Sample (source code): http://support.flir.com/ SwDownload/app/RssSWDownload.aspx?ID=133...

  • Page 24: About I/O, Synchronization, And Measurement

    About I/O, synchronization, and measurement 10.1 FLIR Ax5 General Purpose I/O The FLIR Ax5 camera has one general-purpose input line and one output line that can be used in control applications. Typical usage: • The output line is asserted when an alarm condition is met.

  • Page 25: Flir Ax5 Measurement

    SYNC_OUT port if set to ExtSyncMaster. 10.3 FLIR Ax5 measurement The FLIR Ax5 camera has an option to output 14-bit digital video that is temperature linear. Each count in the temperature-linear video corresponds to either 0.04 K or 0.4 K in 14-bit video, depending on the selected resolution.
  • Page 26 OInt register. The FLIR GEV Demo sample illustrates how to perform this kind of calibration. Please note that you will need to save the current settings if you want the new offset value to be persis- tent.
  • Page 27 About I/O, synchronization, and measurement Figure 10.2 1: Scene, T ; 2: Reflected background temperature; 3: Atmosphere, T ; 4: External win- scene dow, T ; 5: Infrared camera. NOTE The default values for the object parameters are set to values that will have no impact on the conversion between detector signal values and corrected signal values.

  • Page 28: Technical Data

    11.2 Note about technical data FLIR Systems reserves the right to change specifications at any time without prior notice. Please check http://support.flir.com for latest changes.

  • Page 29: Flir A15 F=19 Mm

    Rev.: 30712 General description The FLIR A15 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 160 × 128 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 30 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 31 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 32 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 33: Flir A15 F=19 Mm (7.5 Hz)

    Rev.: 30713 General description The FLIR A15 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 160 × 128 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 34 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 35 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 36 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 37: Flir A15 F=9 Mm

    Rev.: 30714 General description The FLIR A15 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 160 × 128 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 38 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 39 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 40 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 41: Flir A15 F=9 Mm (7.5 Hz)

    Rev.: 30715 General description The FLIR A15 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 160 × 128 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 42 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 43 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 44 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 45: Flir A15 F=9 Mm With Sc Kit (7.5 Hz)

    Rev.: 30716 General description The FLIR A15 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 160 × 128 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 46 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 47 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 48 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 49: Flir A35 F=19 Mm

    Rev.: 28019 General description The FLIR A35 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 320 × 256 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 50 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 51 Housing material Magnesium and aluminum Shipping information Packaging, type Cardboard box List of contents • Infrared camera with lens • FLIR Tools download card • Focus adjustment tool • Printed documentation • User documentation CD-ROM Packaging, weight Packaging, size 295 × 200 × 105 mm (11.6 × 7.9 × 4.1 in.)
  • Page 52 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 53: Flir A35 F=9 Mm

    Rev.: 28020 General description The FLIR A35 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 320 × 256 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 54 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 55 Housing material Magnesium and aluminum Shipping information Packaging, type Cardboard box List of contents • Infrared camera with lens • FLIR Tools download card • Focus adjustment tool • Printed documentation • User documentation CD-ROM Packaging, weight Packaging, size 295 × 200 × 105 mm (11.6 × 7.9 × 4.1 in.)
  • Page 56 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 57: Flir A35 F=9 Mm With Sc Kit

    Rev.: 28021 General description The FLIR A35 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 320 × 256 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 58 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 59 Infrared camera with lens • Base support • Cable tie (2 ea.) • Ethernet cable CAT-6, 2m/6.6 ft (2 ea.) • FLIR ResearchIR Standard 4 • Focus adjustment tool • Gooseneck • Mains cable kit (UK,EU,US) • PoE Injector (power over Ethernet) •...
  • Page 60 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 61: Flir A5 F=5 Mm

    Rev.: 30717 General description The FLIR A5 has features and functions that make it the natural choice for anyone who uses PC software to solve problems and for whom 80 × 64 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 62 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 63 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 64 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 65: Flir A5 F=5 Mm (7.5 Hz)

    Rev.: 30718 General description The FLIR A5 has features and functions that make it the natural choice for anyone who uses PC software to solve problems and for whom 80 × 64 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 66 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 67 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 68 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 69: Flir A5 F=5 Mm With Sc Kit (7.5 Hz)

    Rev.: 30719 General description The FLIR A5 has features and functions that make it the natural choice for anyone who uses PC software to solve problems and for whom 80 × 64 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 70 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 71 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 72 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 73: Flir A5 F=9 Mm

    Rev.: 30720 General description The FLIR A5 has features and functions that make it the natural choice for anyone who uses PC software to solve problems and for whom 80 × 64 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 74 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 75 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 76 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 77: Flir A5 F=9 Mm (7.5 Hz)

    Rev.: 30724 General description The FLIR A5 has features and functions that make it the natural choice for anyone who uses PC software to solve problems and for whom 80 × 64 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 78 Technical data Measurement analysis Atmospheric transmission correction Automatic, based on inputs for distance, atmos- pheric temperature and relative humidity Optics transmission correction Automatic, based on signals from internal sensors Emissivity correction Variable from 0.5 to 1.0 Reflected apparent temperature correction Automatic, based on input of reflected temperature External optics/windows correction Automatic, based on input of optics/window trans-...
  • Page 79 Technical data Digital input/output Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated Synchronization out, type LVC Buffer @ 3.3V, ”0”=24 MA max, “1”= –24 mA max.
  • Page 80 • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198342ACC; Focus adjustment tool • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 81: Flir A65 F=13 Mm

    Rev.: 28022 General description The FLIR A65 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 640 × 512 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 82 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 83 Housing material Magnesium and aluminum Shipping information Packaging, type Cardboard box List of contents • Infrared camera with lens • FLIR Tools download card • Focus adjustment tool • Printed documentation • User documentation CD-ROM Packaging, weight Packaging, size 295 × 200 × 105 mm (11.6 × 7.9 × 4.1 in.)
  • Page 84 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 85: Flir A65 F=13 Mm (7.5 Hz)

    Rev.: 28023 General description The FLIR A65 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 640 × 512 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 86 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 87 Housing material Magnesium and aluminum Shipping information Packaging, type Cardboard box List of contents • Infrared camera with lens • FLIR Tools download card • Focus adjustment tool • Printed documentation • User documentation CD-ROM Packaging, weight Packaging, size 295 × 200 × 105 mm (11.6 × 7.9 × 4.1 in.)
  • Page 88 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 89: Flir A65 F=13 Mm With Sc Kit (7.5 Hz)

    Rev.: 28024 General description The FLIR A65 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 640 × 512 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 90 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 91 Infrared camera with lens • Base support • Cable tie (2 ea.) • Ethernet cable CAT-6, 2m/6.6 ft (2 ea.) • FLIR ResearchIR Standard 4 • Focus adjustment tool • Gooseneck • Mains cable kit (UK,EU,US) • PoE Injector (power over Ethernet) •...
  • Page 92 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 93: Flir A65 F=25 Mm

    Rev.: 28025 General description The FLIR A65 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 640 × 512 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 94 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 95 Shipping information Packaging, type Cardboard box List of contents • Infrared camera with lens • FLIR Tools download card • Printed documentation • User documentation CD-ROM Packaging, weight Packaging, size 295 × 200 × 105 mm (11.6 × 7.9 × 4.1 in.)
  • Page 96 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 97: Flir A65 F=25 Mm (7.5 Hz)

    Rev.: 28026 General description The FLIR A65 has features and functions that make it the natural choice for anyone who uses PC soft- ware to solve problems and for whom 640 × 512 pixel resolution is sufficient. Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used with software packages such as IMAQ Vision and Halcon.
  • Page 98 Frame synchronization in to control camera Synchronization in 1×, non-isolated Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V. Synchronization out, purpose Frame synchronization out to control another FLIR Ax5 camera Synchronization out 1×, non-isolated #T559770; r. AF/30726/30726; en-US...
  • Page 99 Shipping information Packaging, type Cardboard box List of contents • Infrared camera with lens • FLIR Tools download card • Printed documentation • User documentation CD-ROM Packaging, weight Packaging, size 295 × 200 × 105 mm (11.6 × 7.9 × 4.1 in.)
  • Page 100 • T911183; Gigabit PoE injector 16 W, with multi-plugs • T127605ACC; Cable M12 Pigtail • T127606ACC; Cable M12 Sync • T198594ACC; Transport case Ax5 • T198584; FLIR Tools • T198583; FLIR Tools+ (download card incl. license key) • DSW-10000; FLIR IR Camera Player #T559770; r. AF/30726/30726; en-US...

  • Page 101: Mechanical Drawings

    Mechanical drawings #T559770; r. AF/30726/30726; en-US...

  • Page 109: Ce Declaration Of Conformity

    CE Declaration of conformity #T559770; r. AF/30726/30726; en-US...

  • Page 111: Pin Configurations And Schematics

    1 × opto-isolated, “0” < 2, “1” = 2–40 VDC GPI- GP Input return Cables for the M12 connector are available from FLIR Systems. See the part numbers below. • T127605, Cable M12 pigtail. • T127606, Cable M12 sync. #T559770; r. AF/30726/30726; en-US...

  • Page 112: Pig-Tail End Of Cable

    Pin configurations and schematics 14.2 Pig-tail end of cable Figure 14.2 Mapping table, signal type to cable color. 14.3 SYNC input/output schematics Figure 14.3 Schematics of SYNC input and output. #T559770; r. AF/30726/30726; en-US...

  • Page 113: Gp Input/Output Schematics

    Pin configurations and schematics 14.4 GP input/output schematics Figure 14.4 Schematics of GP input and output. #T559770; r. AF/30726/30726; en-US...

  • Page 114: Cleaning The Camera

    Cleaning the camera 15.1 Camera housing, cables, and other items 15.1.1 Liquids Use one of these liquids: • Warm water • A weak detergent solution 15.1.2 Equipment A soft cloth 15.1.3 Procedure Follow this procedure: 1. Soak the cloth in the liquid. 2.

  • Page 115: About Flir Systems

    • DigitalOptics micro-optics business (2013) Figure 16.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a man- ufacturing plant in Tallinn, Estonia.

  • Page 116: More Than Just An Infrared Camera

    16.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infrared camera systems. We are committed to enabling all users of our infrared camera systems to work more productively by providing them with the most powerful camera–software...

  • Page 117: Supporting Our Customers

    16.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equip- ment and expertise to solve it within the shortest possible time.

  • Page 118: Glossary

    Glossary The amount of radiation absorbed by an object relative to the re- absorption (ab- sorption factor) ceived radiation. A number between 0 and 1. atmosphere The gases between the object being measured and the camera, nor- mally air. autoadjust A function making a camera perform an internal image correction.
  • Page 119 Glossary IFOV Instantaneous field of view: A measure of the geometrical resolution of an IR camera. image correc- A way of compensating for sensitivity differences in various parts of tion (internal or live images and also of stabilizing the camera. external) infrared Non-visible radiation, having a wavelength from about 2–13 μm.
  • Page 120 Glossary relative Relative humidity represents the ratio between the current water va- humidity pour mass in the air and the maximum it may contain in saturation conditions. saturation The areas that contain temperatures outside the present level/span color settings are colored with the saturation colors. The saturation colors contain an ‘overflow’...

  • Page 121: Thermographic Measurement Techniques

    Thermographic measurement techniques 18.1 Introduction An infrared camera measures and images the emitted infrared radiation from an object. The fact that radiation is a function of object surface temperature makes it possible for the camera to calculate and display this temperature. However, the radiation measured by the camera does not only depend on the temperature of the object but is also a function of the emissivity.
  • Page 122 Thermographic measurement techniques 18.2.1.1.1 Method 1: Direct method Follow this procedure: 1. Look for possible reflection sources, considering that the incident angle = reflection an- gle (a = b). Figure 18.1 1 = Reflection source 2. If the reflection source is a spot source, modify the source by obstructing it using a piece if cardboard.
  • Page 123 Thermographic measurement techniques 3. Measure the radiation intensity (= apparent temperature) from the reflecting source us- ing the following settings: • Emissivity: 1.0 • D You can measure the radiation intensity using one of the following two methods: Figure 18.3 1 = Reflection source Using a thermocouple to measure reflected apparent temperature is not recommended for two important reasons: •...
  • Page 124 Thermographic measurement techniques 5. Measure the apparent temperature of the aluminum foil and write it down. Figure 18.4 Measuring the apparent temperature of the aluminum foil. 18.2.1.2 Step 2: Determining the emissivity Follow this procedure: 1. Select a place to put the sample. 2.

  • Page 125: Reflected Apparent Temperature

    50%. 18.6 Other parameters In addition, some cameras and analysis programs from FLIR Systems allow you to com- pensate for the following parameters: • Atmospheric temperature – i.e. the temperature of the atmosphere between the camera and the target •...

  • Page 126: History Of Infrared Technology

    History of infrared technology Before the year 1800, the existence of the infrared portion of the electromagnetic spectrum wasn't even suspected. The original significance of the infrared spectrum, or simply ‘the in- frared’ as it is often called, as a form of heat radiation is perhaps less obvious today than it was at the time of its discovery by Herschel in 1800.
  • Page 127 History of infrared technology Moving the thermometer into the dark region beyond the red end of the spectrum, Her- schel confirmed that the heating continued to increase. The maximum point, when he found it, lay well beyond the red end – in what is known today as the ‘infrared wavelengths’. When Herschel revealed his discovery, he referred to this new portion of the electromag- netic spectrum as the ‘thermometrical spectrum’.
  • Page 128 History of infrared technology Figure 19.4 Samuel P. Langley (1834–1906) The improvement of infrared-detector sensitivity progressed slowly. Another major break- through, made by Langley in 1880, was the invention of the bolometer. This consisted of a thin blackened strip of platinum connected in one arm of a Wheatstone bridge circuit upon which the infrared radiation was focused and to which a sensitive galvanometer re- sponded.

  • Page 129: Theory Of Thermography

    Theory of thermography 20.1 Introduction The subjects of infrared radiation and the related technique of thermography are still new to many who will use an infrared camera. In this section the theory behind thermography will be given. 20.2 The electromagnetic spectrum The electromagnetic spectrum is divided arbitrarily into a number of wavelength regions, called bands, distinguished by the methods used to produce and detect the radiation.

  • Page 130: Planck's Law

    Such cavity radiators are commonly used as sources of radiation in temperature refer- ence standards in the laboratory for calibrating thermographic instruments, such as a FLIR Systems camera for example. If the temperature of blackbody radiation increases to more than 525°C (977°F), the source begins to be visible so that it appears to the eye no longer black.

  • Page 131: Wien's Displacement Law

    Theory of thermography where: Blackbody spectral radiant emittance at wavelength λ. λb Velocity of light = 3 × 10 Planck’s constant = 6.6 × 10 Joule sec. Boltzmann’s constant = 1.4 × 10 Joule/K. Absolute temperature (K) of a blackbody. λ...
  • Page 132 Theory of thermography This is Wien’s formula (after Wilhelm Wien, 1864–1928), which expresses mathematically the common observation that colors vary from red to orange or yellow as the temperature of a thermal radiator increases. The wavelength of the color is the same as the wavelength calculated for λ...

  • Page 133: Stefan-Boltzmann's Law

    Theory of thermography 20.3.3 Stefan-Boltzmann's law By integrating Planck’s formula from λ = 0 to λ = ∞, we obtain the total radiant emittance ) of a blackbody: This is the Stefan-Boltzmann formula (after Josef Stefan, 1835–1893, and Ludwig Boltz- mann, 1844–1906), which states that the total emissive power of a blackbody is propor- tional to the fourth power of its absolute temperature.
  • Page 134 Theory of thermography Another factor, called the emissivity, is required to describe the fraction ε of the radiant emittance of a blackbody produced by an object at a specific temperature. Thus, we have the definition: The spectral emissivity ε = the ratio of the spectral radiant power from an object to that λ...

  • Page 135: Infrared Semi-Transparent Materials

    Theory of thermography Figure 20.8 Spectral radiant emittance of three types of radiators. 1: Spectral radiant emittance; 2: Wave- length; 3: Blackbody; 4: Selective radiator; 5: Graybody. Figure 20.9 Spectral emissivity of three types of radiators. 1: Spectral emissivity; 2: Wavelength; 3: Black- body;...
  • Page 136 Theory of thermography When the plate becomes opaque this formula is reduced to the single formula: This last relation is a particularly convenient one, because it is often easier to measure re- flectance than to measure emissivity directly. #T559770; r. AF/30726/30726; en-US...

  • Page 137: The Measurement Formula

    The measurement formula As already mentioned, when viewing an object, the camera receives radiation not only from the object itself. It also collects radiation from the surroundings reflected via the ob- ject surface. Both these radiation contributions become attenuated to some extent by the atmosphere in the measurement path.
  • Page 138 U according to the same equation, and get (Equation 3): Solve Equation 3 for U (Equation 4): This is the general measurement formula used in all the FLIR Systems thermographic equipment. The voltages of the formula are: Table 21.1 Voltages Calculated camera output voltage for a blackbody of temperature T i.e.
  • Page 139 5 volts, the resulting curve would have been very much the same as our real curve extrapolated beyond 4.1 volts, provided the calibration algorithm is based on ra- diation physics, like the FLIR Systems algorithm. Of course there must be a limit to such extrapolations.
  • Page 140 The measurement formula Figure 21.2 Relative magnitudes of radiation sources under varying measurement conditions (SW camera). 1: Object temperature; 2: Emittance; Obj: Object radiation; Refl: Reflected radiation; Atm: atmosphere radia- tion. Fixed parameters: τ = 0.88; T = 20°C (+68°F); T = 20°C (+68°F).

  • Page 141: Emissivity Tables

    Emissivity tables This section presents a compilation of emissivity data from the infrared literature and measurements made by FLIR Systems. 22.1 References 1. Mikaél A. Bramson: Infrared Radiation, A Handbook for Applications, Plenum press, N. 2. William L. Wolfe, George J. Zissis: The Infrared Handbook, Office of Naval Research, Department of Navy, Washington, D.C.
  • Page 142 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Aluminum anodized, light 0.61 gray, dull Aluminum anodized, light 0.97 gray, dull Aluminum as received, plate...
  • Page 143 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Brass dull, tarnished 20–350 0.22 Brass oxidized 0.61 Brass oxidized 0.04–0.09 Brass oxidized...
  • Page 144 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Bronze polished Bronze porous, rough 50–150 0.55 Bronze powder 0.76–0.80 Carbon candle soot 0.95...
  • Page 145 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Emery coarse 0.85 Enamel Enamel lacquer 0.85–0.95 Fiber board hard, untreated 0.85 0.75 Fiber board...
  • Page 146 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Iron and steel oxidized strongly 0.88 Iron and steel oxidized strongly 0.98 Iron and steel polished...
  • Page 147 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Lacquer 3 colors sprayed 0.50–0.53 on Aluminum Lacquer 3 colors sprayed 0.92–0.94 on Aluminum Lacquer...
  • Page 148 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Nickel bright matte 0.041 Nickel commercially 0.045 pure, polished Nickel commercially 200–400 0.07–0.09...
  • Page 149 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Paint oil, black flat 0.94 Paint oil, black gloss 0.92 Paint oil, gray flat 0.97...
  • Page 150 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Platinum 0.05 Platinum 1000–1500 0.14–0.18 Platinum 1094 0.18 Platinum 0.016 Platinum 0.03 Platinum...
  • Page 151 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) sheet, untreated, 0.28 Stainless steel somewhat scratched Stainless steel type 18-8, buffed 0.16 Stainless steel type 18-8, oxi-...
  • Page 152 Emissivity tables Table 22.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3: Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued) Wood 0.962 Wood ground 0.5–0.7 Wood pine, 4 different 0.67–0.75 samples Wood pine, 4 different...
  • Page 154 A note on the technical production of this publication This publication was produced using XML — the eXtensible Markup Language. For more information about XML, please visit http://www.w3.org/XML/ A note on the typeface used in this publication This publication was typeset using Linotype Helvetica™ World. Helvetica™ was designed by Max Miedinger (1910–1980) LOEF (List Of Effective Files) T501003.xml;...
  • Page 156 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T559770...

This manual is also suitable for:

A35A65A5 seriesA5

Table of Contents
