Congratulations on your purchase of our SUNJOY 12'x10' Hardtop Gazebo. Our clear, easy to
follow, step-by-step instructions will guide you through the assembly process from start to
finish.
WARNING:
● This unit is heavy. Do not assemble this item alone. 6-8 people are recommended for safe
assembly.
● Keep all children and pets away from assembly area. Children and pets should be supervised
when they are in the area of the Gazebo construction.
● Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
● Some parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to the
product. Please read all instructions before assembly and use.
● Check all bolts for tightness before use, and periodically check and tighten bolts as necessary.
● Assemble on level ground
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for future reference.
For technical assistance on assembly or replacement parts, call Sunjoy Industries at 1-866-578-6569 from
8:30AM to 5:30PM EST, or email us at customer.care@sunjoydirect.com, or visit
for assistance.
Assembly Instructions
Item# D-GZ841PST-E (PC Top)
.
IMPORTANT
www.sunjoydirect.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the D-GZ841PST-E and is the answer not in the manual?

Questions and answers

Summary of Contents for Sunjoy D-GZ841PST-E

  • Page 1 Assembly Instructions Item# D-GZ841PST-E (PC Top) Congratulations on your purchase of our SUNJOY 12’x10’ Hardtop Gazebo. Our clear, easy to follow, step-by-step instructions will guide you through the assembly process from start to finish. WARNING: ● This unit is heavy. Do not assemble this item alone. 6-8 people are recommended for safe assembly.
  • Page 2 Parts List Post Beam connector Base cover Base Slanting bar connector Lower connector F Lower beam connector Short beam G1 Long beam Supporter bar Long top bar Corner frame Slanting beam Middle beam 1 Middle beam 2 PC piece 1 PC piece 2 PC piece 3 PC piece 4...
  • Page 3 Brace 1 Brace 2 Brace 3 Brace 4 Brace 5 Left rail Right rail Middle rail Center plate Corner plate Hook Small top connector Cover Small slanted beam Netting tube 1 Netting tube 2 Netting tube 3 Netting tube 4 Cover flap 1 Cover flap 2 Cover flap 3...
  • Page 4 Hardware Pack 1 M6X15 Screw 16 PCS M6 Flat washer 144 PCS 16PCS M6X15 Bolt 64 PCS M6X70 Bolt 16 PCS M6X45 Bolt 32 PCS M6 Wrench 2 PCS Fig.3: Attach base (D) to post (A) Fig.1: Fix beam connector (B) to Fig.2: Fix slanting bar connector by using screws (AA) and flat post (A) by using bolts (FF) and...
  • Page 5 Fig.4: Fix lower connector (F) and Fig.5: Connect short beam/long Fig.6: Fix supporter bar (H) to post lower beam connector (F1) onto short beam (G1/G2) to beam connector (A) and short beam/long beam beam / long beam (G1/G2) by using bolts (B) by using bolts (FF) and flat (G1/G2) by using bolts (II) and flat (GG), flat washers (BB), nuts (DD).
  • Page 6 Fig.6-1: Insert long top bar (I1) into corner frame (I2) and fix them by using bolts (AA) and flat washers (BB). Fig.10: Connect cover flap 1 (X1) Fig.7: Fix Slanting Fig.8:Connect cover flap 3 (X3) to Fig.9: Attach middle beam to middle beam 1 (K1), and fix beam (J) to corner the lower end of Slanting beam...
  • Page 7 Hardware Pack 3 M6X15 Screw 14 PCS M6 Flat washer 16 PCS M6X60Bolt 2 PCS Fig.16: Insert the PC piece Fig.17: Insert the Brace 4 / Brace 5 (O1 and Fig.18: Secure the cover (T) to the (M6/M7) into the rail on the O2) into the lower of the PC piece 6/7 (M6 small top connector (S) with bolts small slanted beam (U).
  • Page 8 Hardware Pack 4 Φ8X180 stake 16 PCS Fig.23: Secure the whole gazebo to the ground with stakes (KK).
  • Page 9 IMPORTANT: 1. Keep all children and pets away from assembly area. Children and pets should be supervised while gazebo is being assembled. 2. The assembled gazebo should be located at least 6 feet (2 m) from any obstruction such as a fence, garage, and house, overhanging branches, laundry lines or electrical wires.
  • Page 10 This can be prevented if measure is taken to keep the product from oxidizing. Important: For technical assistance on assembly or replacement parts. Please call Sunjoy Industries at 1(866) 578-6569 from 8:30 AM to 5:30 PM EST Monday to Friday or fax the...
  • Page 11 GAZEBO NETTING AND CURTAIN ASSEMBLY INSTRUCTIONS Netting or Curatin is available separatley ring 104PCS Fig.1: Hang the mosquito net and curtain onto the netting tubes (W1, W2, W3 and W4) by using rings, please put the mosquito net inside.
